Airports for X-Plane

Campbeltown

Airport details

CountryUnited Kingdom
StateScotland
RegionEG
AirspaceScottish Ctr
MunicipalityArgyll and Bute
Elevation41ft (12m)
TimezoneGMT +0
Coordinates55.43762, -5.68810
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeEGEC
IATA codeCAL
FAA coden/a

Communication

Campbeltown AFIS125.900
Nearby Points of Interest:
Campbeltown Library and Museum
-
Kilchousland Chapel
-
Davaar Lighthouse
-
Glenlussa Lodge,standing stone
-
Dun Ugadale
-
Mull of Kintyre Lighthouse
-
Airds Castle
-
Doll’s Houses
-
Torr a'Chaisteal
-
Achamore House
-
Aucheleffan, stone setting 550m NW of
-
Kildalton Cross
-
Kildalton Small Cross
-
1–27 Hamilton Terrace
-
Ardpatrick House
-
High Corrie
-
Corrie Harbour

Runway info

Runway 11 / 29
 length1963m (6440ft)
 bearing99° / 279°
 width46m (151ft)
 surfaceasphalt
 displ threshold156m (512ft) / 406m (1332ft)

Airport layout - parking location Light


Taxiway locations

 N
Parking locations

 Apron  Light  Passenger

Nearby beacons

codeidentifierdistbearingfrequency
CBLCAMPBELTOWN NDB0.1179°380
MACMACHRIHANISH VOR/DME1.3101°116
ISYDME-ILS24294°109.95
LAYISLAY NDB24294°395
TRNTURNBERRY VOR/DME31.798°117.50
OYBELFAST/ALDERGROVE NDB46.7208°332
HBBELFAST CITY NDB49.4193°420
BELBELFAST VOR/DME50.2215°117.20

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW11AKELO (113°)AKELO 3000ft
ERUBO (5mi, 169°) 2000ft
RW11UNISU (85°)UNISU 3000ft
ERUBO (5mi, 50°) 2000ft
 RNAVERUBO 2000ft
EC11F (3mi, 98°) 2000ft
EGEC (6mi, 98°) 80ft
ECM01 (6mi, 98°)
ECM02 (5mi, 23°)
ERUBO (16mi, 268°) 2000ft
ERUBO (turn) 2000ft
RW29IBISO (279°)IBISO 3500ft
EC29I (5mi, 279°) 2600ft
RW29OLIXO (293°)OLIXO 3000ft
EC29I (5mi, 353°) 2600ft
RW29XEBAB (267°)XEBAB 4000ft
EC29I (5mi, 232°) 2600ft
 RNAVEC29I 2600ft
EC29F (5mi, 279°) 2000ft
EGEC (6mi, 279°) 88ft
ECM03 (7mi, 279°)
ECM04 (5mi, 207°)
IBISO (23mi, 92°) 3500ft
IBISO (turn)
