Country | Guernsey |
State | Guernsey |
Region | EG |
Airspace | Brest Ctr |
Municipality | St Saviour |
Elevation | 333ft (101m) |
Timezone | GMT +0 |
Coordinates | 49.43493, -2.60280 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | EGJB |
IATA code | GCI |
FAA code | n/a |
Guernsey Guernsey Ground | 121.800 |
Guernsey Guernsey Tower | 119.950 |
Guernsey Guernsey Approach | 128.650 |
ILS-cat-I | RW27 | 108.1 | 18.00mi |
ILS-cat-I | RW09 | 108.1 | 18.00mi |
3° GS | RW27 | 108.1 | 18.00mi |
3° GS | RW09 | 108.1 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
GUR | GUERNSEY VOR/DME | 0.1 | 335° | 109.40 |
JW | JERSEY NDB | 20.3 | 121° | 329 |
ALD | ALDERNEY NDB | 22.7 | 56° | 383 |
JSY | JERSEY VOR/DME | 25.2 | 111° | 112.20 |
LN | LANNION NDB | 51.1 | 225° | 345 |
SB | SAINT BRIEUC NDB | 52.5 | 192° | 353 |
DIN | DINARD PLEURTUIT SAINT MA VOR/DME | 54.9 | 148° | 114.30 |
BHD | BERRY HEAD VOR/DME | 67.3 | 317° | 112.05 |
Transition altitude | 5000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW09 | |||
ORTA3E | 41mi | 47° | |
ORIS1F | 45mi | 53° | |
GULD1E | 27mi | 94° | |
LUSI1E | 34mi | 105° | |
ORVA1E | 39mi | 117° | |
DIN2E | 55mi | 148° | |
LERA1F | 26mi | 155° | |
SKER3E | 41mi | 315° | |
RW27 | |||
ORTA3W | 41mi | 47° | |
ORIS1X | 45mi | 53° | |
GULD1W | 27mi | 94° | |
LUSI1W | 34mi | 105° | |
ORVA1W | 39mi | 117° | |
DIN2W | 55mi | 148° | |
LERA1X | 26mi | 155° | |
SKER3W | 41mi | 315° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
SKER1G | 40.5 | 135° | |
BIGN1G | 35.0 | 159° | |
ALD1G | 22.7 | 236° | |
BEVA1G | 42.0 | 292° | |
DIN1G | 54.9 | 328° | |
RW09 | |||
LELN1V | 38.1 | 222° | |
ORTA1V | 41.0 | 227° | |
RW27 | |||
LELN1B | 38.1 | 222° | |
ORTA1B | 41.0 | 227° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW09 | ABDUS (71°) | ABDUS 2000ft REMLO (5mi, 356°) 2000ft |
RW09 | RUTOK (106°) | RUTOK 2000ft REMLO (5mi, 176°) 2000ft |
RNAV | REMLO 2000ft JB09F (5mi, 88°) 2000ft EGJB (6mi, 88°) 352ft JBM01 (5mi, 88°) JBM02 (3mi, 176°) JBM03 (3mi, 268°) GUR (4mi, 318°) 3000ft GUR (turn) | |
RW27 | AMIBA (286°) | AMIBA 2000ft JB27I (5mi, 357°) 2000ft |
RW27 | OTMIS (251°) | OTMIS 2000ft JB27I (5mi, 177°) 2000ft |
RW27 | PELOM (269°) | PELOM 2000ft JB27I (5mi, 269°) 2000ft |
RNAV | JB27I 2000ft JB27F (5mi, 269°) 2000ft EGJB (5mi, 268°) 386ft JBM04 (6mi, 268°) JBM05 (4mi, 356°) JBM06 (3mi, 88°) GUR (4mi, 134°) 3000ft GUR (turn) |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
ALD1G | ALD | FIX | left | 259 (79)° | > 2000ft | 1.0min timed | ICAO rules |
ALD1G | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
BEVA1G | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
BIGN1G | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
DIN1G | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
LELN1B | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
LELN1V | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
ORTA1B | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
ORTA1V | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
SKER1G | GUR | NDB | left | 268 (88)° | > 2000ft | 1.0min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
