Airports for X-Plane

Kaunas - Kaunas International

Airport details

CountryLithuania
StateKaunas County
RegionEY
AirspaceVilnius Ctr
MunicipalityKarmėlavos seniūnija
Elevation254ft (77m)
TimezoneGMT +2
Coordinates54.96389, 24.08472
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeEYKA
IATA codeKUN
FAA coden/a

Communication

Kaunas International Kaunas ATIS129.055
Kaunas International Kaunas Tower124.205

Approach frequencies

ILS-cat-IIRW26109.918.00mi
ILS-cat-IRW08109.518.00mi
3° GSRW08109.518.00mi
3° GSRW26109.918.00mi

Runway info

Runway 08 / 26
 length3240m (10630ft)
 bearing87° / 267°
 width45m (148ft)
 surfaceasphalt
 displ threshold297m (974ft) / 297m (974ft)
 blast zone75m (246ft) / 75m (246ft)

Airport layout - parking location 21


Taxiway locations

 A  B  C  D
Parking locations

 1  10  11  12  13  14  15  16
 16R  17  18  19  2  20  21  22
 23  3  3L  4  40  5  6  7
 8  9

Nearby beacons

codeidentifierdistbearingfrequency
KNAKAUNAS VOR/DME0.6259°114.40
KUSKAUNAS INTL NDB1.287°343
SMLDME27.2115°112.50
VLKDME44.4130°116.70
SAUSIAULIAI VOR/DME59.4324°115.20
SQQSIAULIAI TACAN60.3324°116.30

Departure and arrival routes

Transition altitude5000ft
SID end pointsdistanceoutbound heading
RW08
 ELEK1A23mi105°
 KAZL1A, KAZL1C39mi239°
 AKUM1A48mi280°
 UGNI1A31mi331°
RW26
 ELEK1C, ELEK1B23mi105°
 KAZL1B, KAZL1D39mi239°
 AKUM1B48mi280°
 UGNI1B31mi331°

STAR starting pointsdistanceinbound heading
RW08
 KAZL2A38.759°
 AKUM2A47.8100°
 PELU2A33.4136°
 ELEK2A23.0285°
RW26
 KAZL2B38.759°
 AKUM2B47.8100°
 PELU2B33.4136°
 IKAM3B29.6235°
 ELEK2B23.0285°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW08KNA (79°)KNA 4000ft
KA354 (9mi, 296°)
KA355 (4mi, 267°)
KA352 (6mi, 171°) 3000ft
RW08MATAM (82°)MATAM 4000ft
KA352 (6mi, 73°) 3000ft
RW08VEBUS (101°)VEBUS 4000ft
KA352 (6mi, 143°) 3000ft
 RNAVKA352 3000ft
KA351 (4mi, 87°) 2200ft
EYKA (7mi, 87°) 290ft
KA353 (8mi, 87°)
KNA (9mi, 267°) 4000ft
RW26KNA (79°)KNA 4000ft
KA454 (9mi, 111°)
KA455 (4mi, 87°)
KA452 (6mi, 352°) 3000ft
RW26NASAP (253°)NASAP 5000ft
KA456 (3mi, 130°) 4000ft
KA457 (4mi, 201°)
KA452 (4mi, 278°) 3000ft
RW26REGLU (286°)REGLU 4000ft
KA452 (7mi, 333°) 3000ft
 RNAVKA452 3000ft
KA451 (4mi, 267°) 2200ft
EYKA (7mi, 267°) 310ft
KA453 (9mi, 267°)
KNA (8mi, 88°) 4000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
AKUM2AVEBUSVHFleft283 (103)°> 4000ft1.0min timed230
AKUM2BNASAPVHFright54 (234)°5000ft - 9000ft1.0min timed230
ELEK2AMATAMVHFleft250 (70)°> 4000ft1.0min timed230
ELEK2BREGLUVHFleft107 (287)°4000ft - 9000ftDME 4.1mi230
IKAM3BNASAPVHFright54 (234)°5000ft - 9000ft1.0min timed230
KAZL2AMATAMVHFleft250 (70)°> 4000ft1.0min timed230
KAZL2BREGLUVHFleft107 (287)°4000ft - 9000ftDME 4.1mi230
PELU2AVEBUSVHFleft283 (103)°> 4000ft1.0min timed230
PELU2BNASAPVHFright54 (234)°5000ft - 9000ft1.0min timed230
*) magnetic outbound (inbound) holding course
