Airports for X-Plane

Palanga - Palanga Intl

Airport details

CountryLithuania
StateKlaipeda County
RegionEY
AirspaceVilnius Ctr
MunicipalityPalanga
Elevation33ft (10m)
TimezoneGMT +2
Coordinates55.97333, 21.09389
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeEYPA
IATA codePLQ
FAA coden/a

Communication

Palanga Intl ATIS127.805
Palanga Intl Tower124.305
Palanga Intl Dep124.305

Approach frequencies

ILS-cat-IRW19110.118.00mi
3° GSRW19110.118.00mi

Runway info

Runway 01 / 19
 length2277m (7470ft)
 bearing22° / 202°
 width44m (145ft)
 surfaceasphalt
 displ threshold151m (495ft) / 150m (492ft)
 blast zone31m (102ft) / 29m (95ft)

Airport layout


Taxiway locations

 A
Parking locations

 1  10  11  12  13  14  15  16
 17  18  2  3  4  5  6  7
 8  9  North

Nearby beacons

codeidentifierdistbearingfrequency
PLGDME1202°114.80
PNPALANGA INTL NDB1202°407
KLPKLAIPEDA VOR/DME16.2150°115
LEPLIEPAJA VOR/DME32.3359°116.95
RDBDME4850°110.80

Departure and arrival routes

Transition altitude5000ft
SID end pointsdistanceoutbound heading
RW01
 ASKO1C56mi75°
 XARI1C, XARI1A33mi75°
 MANU1A, MANU1C36mi108°
 VALU1C, VALU1A37mi254°
 TIRI1C, TIRI1A13mi285°
RW19
 XARI1B, XARI1D33mi75°
 MANU1D, MANU1B36mi108°
 TIGN1D48mi254°
 VALU1B, VALU1D37mi254°
 TIRI1D, TIRI1B13mi285°

STAR starting pointsdistanceinbound heading
RW01
 VALU2A36.574°
 TIRI2A12.9105°
 XARI2A33.1255°
 MANU2A36.4288°
RW19
 VALU2B36.574°
 TIRI2B12.9105°
 MANU2B36.4288°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW01LAPKO (32°)LAPKO 4000ft
PA352 (6mi, 47°) 2000ft
RW01ONIFA (337°)ONIFA 4000ft
PA352 (6mi, 288°) 2000ft
RW01SOMPU (60°)SOMPU 3500ft
PA352 (6mi, 96°) 2000ft
 RNAVPA352 2000ft
PA351 (4mi, 22°) 1700ft
EYPA (6mi, 22°) 83ft
PA353 (2mi, 22°)
SOMPU (13mi, 236°) 3500ft
SOMPU (turn) 3500ft
RW19NAPUS (250°)NAPUS 3000ft
PA453 (4mi, 278°) 1700ft
PA452 (2mi, 277°) 1500ft
 RNAVPA452 1500ft
PA451 (2mi, 202°) 1300ft
EYPA (4mi, 202°) 82ft
PA454 (6mi, 202°) 1500ft
NAPUS (14mi, 54°) 3000ft
NAPUS (turn) 3000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
MANU2AONIFAVHFleft114 (294)°> 4000ft1.0min timed230
MANU2BNAPUSVHFright99 (279)°> 3000ft1.0min timed230
TIRI2ASOMPUVHFright276 (96)°> 3500ft1.0min timed230
TIRI2BNAPUSVHFright99 (279)°> 3000ft1.0min timed230
TIRI2BPA405VHFleft271 (91)°> 5000ft1.0min timed230
VALU2APA304VHFright260 (80)°> 5000ft1.0min timed230
VALU2BNAPUSVHFright99 (279)°> 3000ft1.0min timed230
VALU2BPA405VHFleft271 (91)°> 5000ft1.0min timed230
XARI2AONIFAVHFleft114 (294)°> 4000ft1.0min timed230
XARI2BNAPUSVHFright99 (279)°> 3000ft1.0min timed230
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
