Country | Cabo Verde |
State | Barlavento Islands |
Region | GV |
Airspace | Sal Oceanic Ctr |
Municipality | Mindelo |
Elevation | 63ft (19m) |
Timezone | GMT -1 |
Coordinates | 16.83361, -25.05472 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | GVSV |
IATA code | VXE |
FAA code | n/a |
Sao Pedro SAO VICENTE Tower | 118.400 |
Sao Pedro SAO VICENTE Approach | 118.400 |
LOC | RW06 | 109.7 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
SVT | SAO VICENTE NDB | 0.6 | 246° | 333 |
NCL | S. NICOLAU NDB | 47.2 | 109° | 357 |
Transition altitude | 7000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW06 | |||
KESI1U | 80mi | 6° | |
LINI1U | 81mi | 13° | |
MOPA2G, MOPA1U | 97mi | 38° | |
NEMD2G, NEMD1U | 116mi | 50° | |
NINA1U, NINA2G | 46mi | 90° | |
SISA1U | 50mi | 124° | |
SNT2G | 146mi | 140° | |
DENE1U | 91mi | 205° | |
EDIP1U, EDIP2G | 82mi | 240° | |
EVKA2G, EVKA1U | 80mi | 315° | |
RW24 | |||
KESI1X | 80mi | 6° | |
LINI1X | 81mi | 13° | |
MOPA2H, MOPA1X | 97mi | 38° | |
NEMD2H, NEMD1X | 116mi | 50° | |
NINA2H, NINA1X | 46mi | 90° | |
SISA1X, SISA2H | 50mi | 124° | |
SNT2H | 146mi | 140° | |
DENE1X | 91mi | 205° | |
EDIP2H, EDIP1X | 82mi | 240° | |
EVKA2H, EVKA1X | 80mi | 315° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
DENE2V | 90.5 | 25° | |
EVKA2V | 80.2 | 135° | |
LINI2V | 80.9 | 193° | |
NEMD2V | 115.7 | 230° | |
NINA2V | 45.5 | 270° | |
SISA2V | 50.3 | 304° | |
SNT2V | 145.5 | 320° | |
RW06 | |||
DENE1Y | 90.5 | 25° | |
EDIP1Y | 81.5 | 60° | |
EVKA1Y | 80.2 | 135° | |
NEMD1Y | 115.7 | 230° | |
NINA1Y | 45.5 | 270° | |
SISA1Y | 50.3 | 304° | |
SNT1Y | 145.5 | 320° | |
RW24 | |||
DENE1Z | 90.5 | 25° | |
EDIP1Z | 81.5 | 60° | |
EVKA1Z | 80.2 | 135° | |
NEMD1Z | 115.7 | 230° | |
NINA1Z | 45.5 | 270° | |
SISA1Z | 50.3 | 304° | |
SNT1Z | 145.5 | 320° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW06 | SV401 (67°) | SV401 2500ft SV12W (6mi, 69°) 2500ft |
RW06 | SV402 (46°) | SV402 2500ft SV12W (6mi, 359°) 2500ft |
RW06 | SV403 (88°) | SV403 5300ft SV12W (6mi, 138°) 2500ft |
RNAV | SV12W 2500ft SV07W (5mi, 69°) 2300ft SV02W (5mi, 69°) 704ft SV404 (6mi, 69°) SV405 (5mi, 19°) SV406 (5mi, 308°) SV403 (19mi, 241°) 5300ft SV403 (turn) 5300ft | |
RW24 | SV501 (257°) | SV501 4000ft SV11E (6mi, 303°) 2500ft |
RW24 | SV502 (235°) | SV502 2500ft SV11E (6mi, 235°) 2500ft |
RNAV | SV11E 2500ft SV06E (5mi, 235°) 2100ft GVSV (7mi, 235°) 151ft SV504 (2mi, 235°) SV505 (6mi, 143°) SV506 (7mi, 74°) SV501 (10mi, 38°) 4000ft SV501 (turn) 4000ft |
