Airports for X-Plane

Dakhla

Airport details

CountryEgypt
StateNew Valley
RegionHE
AirspaceCairo Ctr
Elevation611ft (186m)
TimezoneGMT +2
Coordinates25.41167, 29.00167
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeHEDK
IATA codeDAK
FAA coden/a

Communication

Dakhla CTAF119.800
Dakhla Tower118.300

Runway info

Runway 15 / 33
 length2495m (8186ft)
 bearing147° / 327°
 width45m (148ft)
 surfaceasphalt
 blast zone60m (197ft) / 64m (210ft)

Airport layout - parking location Civil


Parking locations

 Civil  General  Military

Nearby beacons

codeidentifierdistbearingfrequency
MBDAKHLA NDB0.5358°387

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW15DK511 (183°)DK511 4000ft
DK514 (7mi, 242°) 3000ft
RW15DK512 (147°)DK512 4000ft
DK514 (5mi, 147°) 3000ft
RW15DK513 (122°)DK513 4000ft
DK514 (5mi, 62°) 3000ft
 RNAVDK514 3000ft
DK516 (5mi, 147°) 2200ft
HEDK (6mi, 147°) 624ft
DK517 (6mi, 146°) 2000ft
DK518 (7mi, 62°) 2200ft
DK511 (17mi, 327°) 3000ft
DK511 (turn) 4000ft
RW33DK611 (3°)DK611 4000ft
DK614 (7mi, 62°) 3000ft
RW33DK612 (327°)DK612 4000ft
DK614 (5mi, 327°) 3000ft
RW33DK613 (302°)DK613 4000ft
DK614 (5mi, 241°) 3000ft
 RNAVDK614 3000ft
DK615 (4mi, 327°) 2500ft
HEDK (7mi, 326°) 663ft
DK617 (6mi, 327°) 2000ft
DK618 (7mi, 242°) 2500ft
DK611 (17mi, 147°) 3000ft
DK611 (turn) 4000ft
