Airports for X-Plane

Aswan - Aswan Intl

Airport details

CountryEgypt
StateAswan
RegionHE
AirspaceCairo Ctr
Elevation647ft (197m)
TimezoneGMT +2
Coordinates23.96445, 32.82000
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeHESN
IATA codeASW
FAA coden/a

Communication

Aswan Intl HESN TOWER118.300
Aswan Intl HESN RADAR120.300

Approach frequencies

ILS-cat-IIRW35109.518.00mi
3° GSRW35109.518.00mi
Nearby Points of Interest:
Philae obelisk
-
Qubbet el-Hawa

Runway info

Runway 17 / 35
 length3418m (11214ft)
 bearing170° / 350°
 width45m (148ft)
 surfaceconcrete
 blast zone60m (197ft) / 57m (187ft)

Airport layout - taxiway location D


Taxiway locations

 A  B  C  D  E  F  J  K
 L
Parking locations

 22  9

Nearby beacons

codeidentifierdistbearingfrequency
ASNASWAN VOR/DME0.4337°112.30

Departure and arrival routes

Transition altitude4000ft
Transition level5500ft
SID end pointsdistanceoutbound heading
RW17
 ULOL1B20mi218°
 VEDU1B21mi331°
RW35
 ULOL1A20mi218°
 VEDU1A21mi331°

STAR starting pointsdistanceinbound heading
RW17
 TUBA1B19.855°
 TULB1B22.5178°
RW35
 TUBA1A19.855°
 TULB1A22.5178°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW17SN711 (126°)SN711
SN714 (10mi, 82°) 3200ft
RW17SN712 (170°)SN712
SN714 (8mi, 170°) 3200ft
 RNAVSN714 3200ft
SN715 (5mi, 170°) 2300ft
HESN (6mi, 170°) 671ft
SN716 (6mi, 170°) 1800ft
SN717 (10mi, 262°) 3300ft
SN711 (17mi, 350°)
SN711 (turn)
RW35SN301 (350°)SN301
SN304 (7mi, 350°) 3300ft
RW35SN302 (35°)SN302
SN304 (10mi, 82°) 3300ft
 RNAVSN304 3300ft
SN305 (5mi, 350°) 2300ft
HESN (6mi, 350°) 712ft
SN306 (7mi, 350°) 2000ft
SN307 (10mi, 262°) 3500ft
SN302 (18mi, 170°)
SN302 (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
TUBA1ASN123VHFleft257 (77)°> 7000ft1.0min timedICAO rules
TUBA1BSN113VHFright257 (77)°> 7000ft1.0min timedICAO rules
TULB1ASN123VHFleft257 (77)°> 7000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
