Airports for X-Plane

Abilene - Abilene Regl

Airport details

CountryUnited States of America
StateTexas
RegionK4
AirspaceFt Worth Ctr
MunicipalityAbilene
Elevation1791ft (546m)
TimezoneGMT -6
Coordinates32.41133, -99.68189
Magnetic var
Typeland
Available sinceX-Plane v10.30
ICAO codeKABI
IATA codeABI
FAA codeABI

Communication

Abilene Regl ATIS118.250
Abilene Regl UNICOM122.950
Abilene Regl Ground Control121.700
Abilene Regl Tower120.100
Abilene Regl Approach/Departure127.200
Abilene Regl Approach/Departure125.000

Approach frequencies

LOCRW17R109.7518.00mi
ILS-cat-IRW35R110.318.00mi
3° GSRW35R110.318.00mi
Nearby Points of Interest:
Abilene Fire Station No. 2
-
First Presbyterian Church
-
Shackelford County Courthouse Historic District
-
Saint John’s Methodist Church

Runway info

Runway 17L / 35R
 length2200m (7218ft)
 bearing180° / 360°
 width46m (150ft)
 surfaceasphalt
Runway 17R / 35L
 length2201m (7221ft)
 bearing180° / 360°
 width46m (150ft)
 surfaceasphalt
Runway 4 / 22
 length1123m (3684ft)
 bearing57° / 237°
 width30m (100ft)
 surfaceasphalt

Airport layout - taxiway location C1


Taxiway locations

 A  A1  A2  A3  C  C1  C2  C3
 C4  D  D1  D2  D3  M  N  P
 R  S  T
Parking locations

 Abilene  Cargo  Gate

Nearby beacons

codeidentifierdistbearingfrequency
ABTOMHI (ABILENE) NDB6.7176°353
DYSDYESS (ABILENE) TACAN8.8272°133.60
ABIABILENE VORTAC10.1291°113.70
TQATUSCOLA (ABILENE) VOR/DME12.5218°111.60
BWDBROWNWOOD VOR/DME48.2126°108.60

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW17LABI (111°)ABI
ANETY (8mi, 39°) 3900ft
HIZSU (5mi, 90°) 3900ft
RW17LROGEE (227°)ROGEE
EHHAD (20mi, 237°) 3900ft
HIZSU (5mi, 270°) 3900ft
 RNAVHIZSU 3900ft
GOFDO (6mi, 180°) 3400ft
KABI (5mi, 185°) 1845ft
(5895mi, 108°) 2041ft
IBRIF (5896mi, 288°) 4000ft
IBRIF (turn)
RW35RABI (111°)ABI
INECO (17mi, 162°) 4000ft
NILSE (5mi, 90°) 4000ft
RW35RKEYJO (333°)KEYJO
NILSE (5mi, 270°) 4000ft
 RNAVNILSE 4000ft
IBRIF (6mi, 360°) 3400ft
BERUF (3mi, 360°) 2440ft
KABI (3mi, 352°) 1834ft
(5895mi, 108°) 1976ft
GOFDO (5895mi, 288°) 4000ft
GOFDO (turn) 4000ft
