Airports for X-Plane

Afton - Afton Muni

Airport details

CountryUnited States of America
StateWyoming
RegionK1
AirspaceSalt Lake City Ctr
MunicipalityAfton
Elevation6221ft (1896m)
TimezoneGMT -7
Coordinates42.70878, -110.94217
Magnetic var
Typeland
Available sinceX-Plane v10.30
ICAO codeKAFO
IATA codeAFO
FAA codeAFO

Communication

Afton Muni AWOS 3119.025
Afton Muni CTAF/UNICOM122.800
Nearby Points of Interest:
John A. Bagley House
-
Montpelier Historic District
-
Montepelier Odd Fellows Hall

Runway info

Runway 16 / 34
 length2144m (7034ft)
 bearing180° / 0°
 width23m (75ft)
 surfaceasphalt

Airport layout - parking location New


Taxiway locations

 34  A1
Parking locations

 New  Ramp

Nearby beacons

codeidentifierdistbearingfrequency
BPIBIG PINEY VOR/DME37.699°116.50
JACJACKSON VOR/DME55.513°115.40

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW16
 LUNDI241mi269°
RW34
 AFTON433mi332°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW16BPI (279°)BPI
COTEG (45mi, 305°) 13000ft
WARPU (10mi, 253°) 11700ft
NIKSE (5mi, 151°) 10400ft
RW16GIGSE (152°)GIGSE
WARPU (13mi, 141°) 11700ft
NIKSE (5mi, 151°) 10400ft
RW16TUVOC (219°)TUVOC
COTEG (18mi, 246°) 13500ft
WARPU (10mi, 253°) 11700ft
NIKSE (5mi, 151°) 10400ft
RW16WARPU (159°)WARPU 11700ft
NIKSE (5mi, 151°) 10400ft
 RNAVNIKSE 10400ft
THAYN (5mi, 151°) 9400ft
HSKEE (6mi, 167°) 7520ft
ZASGO (4mi, 167°) 6394ft
(6319mi, 111°) 6621ft
GIGSE (6324mi, 291°) 11700ft
GIGSE (turn)
RW34BPI (279°)BPI
SISLE (30mi, 251°) 12600ft
CAALL (10mi, 270°) 11500ft
RW34CAALL (0°)CAALL 11500ft
RW34GRIPS (317°)GRIPS
SISLE (44mi, 313°) 12400ft
CAALL (10mi, 270°) 11500ft
RW34MLD (71°)MLD
IVAYU (58mi, 82°) 11700ft
CAALL (10mi, 90°) 11500ft
 RNAVCAALL 11500ft
ALLRD (10mi, 0°) 10100ft
POKEE (2mi, 0°) 9300ft
PITSZ (2mi, 0°) 8660ft
KAFO (7mi, 0°) 6266ft
(6320mi, 111°) 6621ft
IVAYU (6334mi, 291°) 11500ft
IVAYU (turn)
