Country | United States of America |
State | Oregon |
Region | K1 |
Airspace | Seattle Ctr |
Municipality | Deschutes County |
Elevation | 3458ft (1054m) |
Timezone | GMT -8 |
Coordinates | 44.09455, -121.20023 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | KBDN |
IATA code | n/a |
FAA code | BDN |
Bend Muni AWOS 3 | 134.425 |
Bend Muni CTAF/UNICOM | 123.000 |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
DSD | DESCHUTES (REDMOND) VORTAC | 10.4 | 327° | 117.60 |
Transition altitude | 18000ft |
Transition level | 18000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW16 | |||
BDN1 | 10mi | 327° | |
RW34 | |||
BDN1 | 10mi | 327° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW16-Y | DUMMP (195°) | DUMMP DSD (10mi, 238°) 6100ft FOGIV (4mi, 134°) 5400ft |
RW16-Y | EENIE (115°) | EENIE TABSE (5mi, 97°) 7900ft DSD (10mi, 98°) 6100ft FOGIV (4mi, 134°) 5400ft |
RW16-Y | HERBS (166°) | HERBS DSD (10mi, 188°) 6100ft FOGIV (4mi, 134°) 5400ft |
RW16-Y | HORRN (131°) | HORRN BOTTL (10mi, 124°) 9000ft DSD (10mi, 124°) 6100ft FOGIV (4mi, 134°) 5400ft |
RW16-Y | SNOKY (106°) | SNOKY FOSNI (6mi, 86°) 9500ft DSD (10mi, 87°) 6100ft FOGIV (4mi, 134°) 5400ft |
RW16-Y | URBIA (355°) | URBIA DSD (15mi, 335°) 6200ft DSD (turn) 6100ft FOGIV (4mi, 134°) 5400ft |
RNAV | FOGIV 5400ft COMEK (2mi, 134°) 4800ft HONDU (4mi, 163°) 3610ft (6717mi, 110°) 3760ft HITUP (6718mi, 290°) WOTLO (8mi, 86°) HATMO (8mi, 44°) 7600ft HATMO (turn) | |
RW16-Z | DSD (147°) | DSD FOMBO (6mi, 58°) 7000ft FOMBO (turn) 7000ft |
RW16-Z | HERBS (166°) | HERBS FOMBO (7mi, 141°) 7000ft |
RNAV | FOMBO 7000ft HEKIL (7mi, 180°) 5400ft KBDN (6mi, 180°) 3453ft (6717mi, 110°) 3682ft JOGON (6719mi, 290°) SAKKO (19mi, 75°) 9500ft SAKKO (turn) 9500ft | |
RW34 | DSD (147°) | DSD HARBU (27mi, 151°) 8000ft HARBU (turn) 8000ft |
RW34 | POCIT (339°) | POCIT HARBU (8mi, 349°) 8000ft |
RNAV | HARBU 8000ft NALOE (3mi, 322°) 7400ft CODAY (3mi, 322°) 6700ft GUPYE (5mi, 340°) 5100ft FEDKU (5mi, 340°) 3663ft (6717mi, 110°) 3860ft CELVA (6717mi, 290°) DSD (8mi, 326°) 6000ft DSD (turn) |
