Country | United States of America |
State | Florida |
Region | K7 |
Airspace | Jacksonville Ctr |
Municipality | DeLand |
Elevation | 79ft (24m) |
Timezone | GMT -5 |
Coordinates | 29.06703, -81.28375 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | KDED |
IATA code | n/a |
FAA code | DED |
Deland Muni AWOS 3 | 119.575 |
Deland Muni CTAF/UNICOM | 123.075 |
Deland Muni DAYTONA Approach/Departure | 125.350 |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
OMN | ORMOND BEACH VORTAC | 16.7 | 36° | 112.60 |
ORL | ORLANDO VORTAC | 31.6 | 186° | 112.20 |
OR | HERNY (ORLANDO) NDB | 34.5 | 195° | 221 |
OCF | OCALA VORTAC | 49.8 | 277° | 113.70 |
SGJ | SAINT AUGUSTINE VOR/DME | 53.4 | 357° | 109.40 |
RYD | REYNOLDS (GREEN COVE SPRINGS) NDB | 57.4 | 337° | 338 |
GN | WYNDS (GAINESVILLE) NDB | 58.9 | 304° | 269 |
COF | PATRICK (COCOA) TACAN | 61.1 | 141° | 115 |
GNV | GATORS VORTAC | 63.9 | 302° | 116.20 |
MLB | MELBOURNE VOR/DME | 67.1 | 146° | 115.85 |
Transition altitude | 18000ft |
Transition level | 18000ft |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
TTHOR2 | 35.9 | 185° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW05 | MAMBO (47°) | MAMBO UFIPI (14mi, 42°) 2000ft |
RNAV | UFIPI 2000ft RUXZO (6mi, 52°) 2000ft SEVAE (3mi, 52°) 900ft KDED (3mi, 50°) 118ft (4948mi, 110°) 385ft HOSOK (4945mi, 290°) BARBS (15mi, 314°) 3000ft BARBS (turn) | |
RW12 | BARBS (153°) | BARBS XEHMO (10mi, 205°) 1600ft |
RNAV | XEHMO 1600ft IDROF (6mi, 114°) 1600ft KDED (5mi, 115°) 114ft (4948mi, 110°) 404ft CUGAK (4937mi, 290°) OAKIE (11mi, 130°) 2000ft OAKIE (turn) | |
RW23 | OMN (216°) | OMN WEKLU (7mi, 184°) 1600ft |
RNAV | WEKLU 1600ft HOSOK (6mi, 232°) 1600ft KDED (5mi, 234°) 108ft (4948mi, 110°) 374ft RUXZO (4952mi, 290°) MAMBO (20mi, 225°) 3000ft MAMBO (turn) | |
RW30 | OAKIE (301°) | OAKIE CUGAK (11mi, 310°) 2000ft |
RW30 | SMYRA (282°) | SMYRA CUGAK (5mi, 252°) 2000ft |
RNAV | CUGAK 2000ft YEBBU (7mi, 294°) 1600ft KDED (5mi, 293°) 110ft (4948mi, 110°) 480ft XEHMO (4959mi, 290°) BARBS (10mi, 25°) 3000ft BARBS (turn) |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
TTHOR2 | LPERD | VHF | right | 14 (194)° | DME 10.0mi | ICAO rules | |
TTHOR2 | WEEEK | VHF | left | 2 (182)° | DME 10.0mi | ICAO rules | |
*) magnetic outbound (inbound) holding course |
