Airports for X-Plane

Tucson - Davis-monthan Afb

Airport details

CountryUnited States of America
StateArizona
RegionK2
AirspaceAlbuquerque Ctr
MunicipalityTucson
Elevation2704ft (824m)
TimezoneGMT -7
Coordinates32.16636, -110.88317
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKDMA
IATA codeDMA
FAA codeDMA

Communication

Davis-Monthan AFB Ground Control121.800
Davis-Monthan AFB Tower118.850

Approach frequencies

ILS-cat-IRW12109.318.00mi
ILS-cat-IRW30109.318.00mi
3° GSRW12109.318.00mi
3° GSRW30109.318.00mi

Runway info

Runway 12 / 30
 length4167m (13671ft)
 bearing133° / 313°
 width61m (200ft)
 surfaceconcrete
 blast zone255m (837ft) / 255m (837ft)

Airport layout - taxiway location A


Taxiway locations

 A  A1  A2  A3  A4  A5  A7  C
Parking locations

 AMARG  EC-130  Helicopter  HOT  NORTH  Ready  S  VISITOR

Nearby beacons

codeidentifierdistbearingfrequency
DMADAVIS-MONTHAN (TUCSON) TACAN0.4161°117.60
TUSTUCSON VORTAC4.5204°116
RYNRYAN (TUCSON) NDB14.2264°338
AVQMARANA NDB22.4306°245
RBJROBLES (TUCSON) NDB24.8259°220
FHULIBBY (FT HUACHUCA) VOR/DME43.8138°113.60
ARHFORT HUACHUCA TACAN44.5137°111.60
OLSNOGALES VOR/DME45.1177°108.20

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
BBALL
 DMA230mi281°
RW12
 MESCA126mi124°
 DMA230mi281°
RW30
 DMA230mi281°
 BBALL157mi323°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12JAMRR (133°)JAMRR 7000ft
BINTT (6mi, 133°) 5000ft
 RNAVBINTT 5000ft
GADGT (7mi, 133°) 4000ft
KDMA (5mi, 133°) 2637ft
(6460mi, 106°) 3300ft
BINTT (6467mi, 286°)
JAMRR (6mi, 313°) 8000ft
JAMRR (turn) 10000ft
RW30NOIZE (313°)NOIZE 7000ft
SEASE (6mi, 313°) 6000ft
 RNAVSEASE 6000ft
BUZRR (6mi, 313°) 4300ft
KDMA (6mi, 313°) 2763ft
(6460mi, 106°) 3104ft
JAMRR (6470mi, 286°) 8000ft
JAMRR (turn) 10000ft
