Grand Prairie - Grand Prairie Muni
Airport details
| Country | United States of America |
| State | Texas |
| Region | K4 |
| Airspace | Ft Worth Ctr |
| Municipality | Grand Prairie |
| Elevation | 585ft (178m) |
| Timezone | GMT -6 |
| Coordinates | 32.70217, -97.04781 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | KGPM |
| IATA code | n/a |
| FAA code | GPM |
Communication
| GRAND PRAIRIE MUNI AWOS 3 | 118.475 |
| GRAND PRAIRIE MUNI CTAF/UNICOM | 128.550 |
| GRAND PRAIRIE MUNI Ground Control | 121.150 |
| GRAND PRAIRIE MUNI Tower | 128.550 |
| GRAND PRAIRIE MUNI RGNL Approach/Departure | 135.975 |
Nearby Points of Interest:
Marrow Bone Spring Archeological Site
-Ruth Paine Home
-Kessler Park Historic District
-Kings Highway Conservation District, Dallas
-North Bishop Avenue Commercial Historic District
-Medical Dental Building
-Lake Cliff
-Ronald Kirk Bridge
-Parkland Memorial Hospital
-Houston Street Viaduct
-Texas School Book Depository
-Dallas County Courthouse
-Sanger Harris department store building
-Santa Fe Terminal Complex
-One Main Place
-Dallas Downtown Historic District
-Davis Building
-Elm Place
-Adolphus Hotel
-Kirby Building
-Mosaic Dallas
-Republic Center
-Wilson Building
-Alfred Horatio Belo House
-Titche-Goettinger Building
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| TTT | MAVERICK VOR/DME | 10 | 3° | 113.10 |
| FUZ | RANGER (DALLAS-FORT WORTH VORTAC | 13 | 325° | 115.70 |
| CVE | COWBOY (DALLAS) VOR/DME | 13.4 | 37° | 116.20 |
| FT | MUFIN (FORT WORTH) NDB | 20 | 300° | 365 |
| NFW | NAS JRB FORT WORTH (FT WO TACAN | 20.2 | 280° | 108.70 |
| PQF | MESQUITE NDB | 26.9 | 78° | 248 |
| DT | PINCK (DENTON) NDB | 35.6 | 346° | 257 |
| MQP | MILLSAP (MINERAL WELLS) VORTAC | 48 | 271° | 117.70 |
| CGQ | POWELL (CORSICANA) NDB | 49.6 | 136° | 344 |
| CQY | CEDAR CREEK VORTAC | 52.2 | 122° | 114.80 |
| CRS | CORSICANA NDB | 52.2 | 136° | 396 |
| JEN | GLEN ROSE TACAN | 53.2 | 237° | 115 |
| MJF | ARVILLA (GREENVILLE) TACAN | 54.3 | 70° | 109.60 |
| GV | MAJOR (GREENVILLE) NDB | 56.6 | 65° | 201 |
| UKW | BOWIE VORTAC | 63.4 | 317° | 117.15 |
| BYP | BONHAM VORTAC | 64.7 | 44° | 114.60 |
Departure and arrival routes
| Transition altitude | 18000ft |
| Transition level | 18000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW18 | |||
| TEX1 | 101mi | 2° | |
| DALL8 | 157mi | 75° | |
| KUSSO8 | 183mi | 98° | |
| GARL1 | 86mi | 102° | |
| JPOOL3 | 70mi | 182° | |
| SWABR8 | 116mi | 266° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| ALL | |||
| SWVAY4 | 33.7 | 46° | |
| WESAT2, MOTZA1 | 48.3 | 129° | |
| SASIE6, TRUUK2 | 50.3 | 211° | |
| DODJE6, REEKO3 | 34.4 | 312° | |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| DODJE6 | CAPTI | VHF | left | 73 (253)° | 1.0min timed | ICAO rules | |
| DODJE6 | CQY | NDB | left | 95 (275)° | < 60000ft | 1.0min timed | ICAO rules |
| DODJE6 | GGG | NDB | right | 114 (294)° | < 17999ft | 1.0min timed | ICAO rules |
| DODJE6 | HERRI | VHF | left | 101 (281)° | 1.0min timed | ICAO rules | |
| DODJE6 | WEIRS | VHF | left | 128 (308)° | < 17999ft | 1.0min timed | ICAO rules |
| MOTZA1 | ACKME | VHF | right | 15 (195)° | 1.0min timed | ICAO rules | |
| MOTZA1 | HEATR | VHF | left | 299 (119)° | 1.5min timed | ICAO rules | |
| MOTZA1 | KAJAY | VHF | right | 283 (103)° | 1.5min timed | ICAO rules | |
| MOTZA1 | MOOSE | VHF | left | 15 (195)° | 1.0min timed | ICAO rules | |
| MOTZA1 | PLEBS | VHF | left | 283 (103)° | 1.0min timed | ICAO rules | |
| MOTZA1 | SPS | NDB | left | 348 (168)° | 1.0min timed | ICAO rules | |
| MOTZA1 | TURKI | VHF | right | 266 (86)° | 1.5min timed | ICAO rules | |
| MOTZA1 | UKW | NDB | left | 283 (103)° | 1.0min timed | ICAO rules | |
| MOTZA1 | ZANTO | VHF | left | 283 (103)° | 1.5min timed | ICAO rules | |
| REEKO3 | PURRS | VHF | left | 136 (316)° | DME 10.0mi | ICAO rules | |
| REEKO3 | VDUBB | VHF | left | 83 (263)° | DME 10.0mi | ICAO rules | |
| SASIE6 | BIRLE | VHF | right | 35 (215)° | 1.5min timed | ICAO rules | |
| SASIE6 | BYP | NDB | right | 45 (225)° | < 60000ft | 1.0min timed | ICAO rules |
| SASIE6 | GAATZ | VHF | right | 35 (215)° | 1.0min timed | ICAO rules | |
| SASIE6 | GLOVE | VHF | right | 64 (244)° | 18000ft - 45000ft | 1.5min timed | ICAO rules |
| SASIE6 | ROBEY | VHF | left | 64 (244)° | 1.0min timed | ICAO rules | |
| SWVAY4 | AGAIN | VHF | right | 195 (15)° | DME 10.0mi | ICAO rules | |
| SWVAY4 | FRSTI | VHF | right | 207 (27)° | DME 10.0mi | ICAO rules | |
| SWVAY4 | PUNKY | VHF | right | 259 (79)° | DME 10.0mi | ICAO rules | |
| SWVAY4 | SHLLY | VHF | right | 268 (88)° | DME 10.0mi | ICAO rules | |
| TRUUK2 | PRIZZ | VHF | left | 38 (218)° | DME 10.0mi | ICAO rules | |
| WESAT2 | FAWNT | VHF | right | 360 (180)° | DME 10.0mi | ICAO rules | |
| WESAT2 | FLOWN | VHF | left | 285 (105)° | DME 10.0mi | ICAO rules | |
| WESAT2 | GREKE | VHF | left | 287 (107)° | DME 10.0mi | ICAO rules | |
| WESAT2 | ROTTR | VHF | left | 355 (175)° | DME 10.0mi | ICAO rules | |
| WESAT2 | TURKI | VHF | right | 266 (86)° | 1.5min timed | ICAO rules | |
| *) magnetic outbound (inbound) holding course | |||||||
