Airports for X-Plane

Three Rivers - Three Rivers Muni Dr Haines

Airport details

CountryUnited States of America
StateMichigan
RegionK5
AirspaceChicago Ctr
MunicipalityThree Rivers
Elevation824ft (251m)
TimezoneGMT -5
Coordinates41.95975, -85.59306
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKHAI
IATA codeHAI
FAA codeHAI

Communication

THREE RIVERS MUNI DR HAINES AWOS 3119.975
THREE RIVERS MUNI DR HAINES CTAF/UNICOM122.800
THREE RIVERS MUNI DR HAINES KALAMAZOO Approach/Departure121.200

Runway info

Runway 9 / 27
 length1216m (3990ft)
 bearing90° / 270°
 width23m (75ft)
 surfaceasphalt
Runway 5 / 23
 length827m (2713ft)
 bearing53° / 233°
 width18m (60ft)
 surfaceasphalt
 blast zone124m (407ft) / 76m (249ft)

Airport layout - taxiway location B


Taxiway locations

 A  B  C  D
Parking locations

 New

Nearby beacons

codeidentifierdistbearingfrequency
AZAUSTN (KALAMAZOO) NDB10.620°371
IRSSTURGIS NDB11.3133°382
AZOKALAMAZOO VOR/DME16.78°109
ELXKEELER VOR/DME26289°116.60
BTBATOL (BATTLE CREEK) NDB30.245°272
SBMISHA (SOUTH BEND) NDB31.8248°341
GSHGOSHEN VORTAC32.5225°113.70
GIJGIPPER (NILES) VORTAC34.4255°115.40
LFDLITCHFIELD VOR/DME37.483°111.20
PMMPULLMAN VOR/DME37.9315°112.10
OLKWEBSTER LAKE VOR43172°110.40
GWSHENK (AUBURN) NDB48.7135°227
VIOVICTORY VOR/DME49.87°115.95
GRKNOBS (GRAND RAPIDS) NDB5713°263
FWAFORT WAYNE VORTAC61.6158°117.80

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW27IJYEP (270°)IJYEP 3000ft
RW27LUPXA (250°)LUPXA 3000ft
IJYEP (5mi, 180°) 3000ft
RW27OBMUY (289°)OBMUY 3000ft
IJYEP (5mi, 360°) 3000ft
 RNAVIJYEP 3000ft
ERZEH (5mi, 270°) 2500ft
15THR (4mi, 270°) 1320ft
KHAI (2mi, 269°) 873ft
(5208mi, 116°) 1224ft
IJJUB (5219mi, 296°) 3000ft
IJJUB (turn)
