Airports for X-Plane

Houston - Houston George Bush Intl

Airport details

CountryUnited States of America
StateTexas
RegionK4
AirspaceHouston Oceanic Ctr
MunicipalityHouston
Elevation97ft (30m)
TimezoneGMT -6
Coordinates29.96658, -95.35114
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKIAH
IATA codeIAH
FAA codeIAH

Communication

Houston George Bush Intl ATIS124.050
Houston George Bush Intl UNICOM122.950
Houston George Bush Intl Clearance DEL128.100
Houston George Bush Intl Ground 15/33121.700
Houston George Bush Intl Ramp N130.825
Houston George Bush Intl Ground119.950
Houston George Bush Intl Ramp W121.625
Houston George Bush Intl Ground 8/26 09/27118.575
Houston George Bush Intl Ramp E131.275
Houston George Bush Intl Tower 08R/26L125.350
Houston George Bush Intl Tower 15/33127.300
Houston George Bush Intl Tower 08L/26R120.725
Houston George Bush Intl Tower 09/27135.150
Houston George Bush Intl Approach W124.350
Houston George Bush Intl Approach119.625
Houston George Bush Intl Approach119.175
Houston George Bush Intl Approach E120.050
Houston George Bush Intl Departure N119.700
Houston George Bush Intl Departure132.250
Houston George Bush Intl Departure E133.600
Houston George Bush Intl Departure126.675
Houston George Bush Intl Departure W123.800
Houston George Bush Intl Departure127.125

Approach frequencies

ILS-cat-IIIRW26R111.5518.00mi
ILS-cat-IIIRW26L109.718.00mi
ILS-cat-IIIRW27110.918.00mi
ILS-cat-IIIRW08L111.5518.00mi
ILS-cat-IIRW09110.918.00mi
ILS-cat-IIRW08R109.718.00mi
ILS-cat-IRW33R111.918.00mi
ILS-cat-IRW15R111.1518.00mi
3° GSRW09110.918.00mi
3° GSRW26L109.718.00mi
3° GSRW26R111.5518.00mi
3° GSRW08R109.718.00mi
3° GSRW15R111.1518.00mi
3° GSRW27110.918.00mi
3° GSRW33R111.918.00mi
3° GSRW08L111.5518.00mi
Nearby Points of Interest:
Ben C. and Jenetter Cyrus House
-
Charles Johnson House
-
Oscar Lindsay House
-
Allbach House
-
Houston Heights Woman's Club
-
Banta House
-
Houston Heights Waterworks Reservoir
-
Burge House
-
Barker House
-
Gillette House
-
David A. Carden House
-
Houston Heights Fire Station
-
Webber House
-
Otto H. Baring House
-
All Saints Catholic Church
-
John W. Anderson House
-
Isbell House
-
James Bute Company Warehouse
-
McKee Street Bridge
-
Heights State Bank Building
-
Merchants and Manufacturers Building
-
Houston Cotton Exchange Building
-
1879 Houston Waterworks
-
San Jacinto Street Bridge over Buffalo Bayou
-
W. L. Foley Building

Runway info

Runway 15L / 33R
 length3666m (12028ft)
 bearing149° / 329°
 width46m (151ft)
 surfaceconcrete
 blast zone122m (400ft) / 122m (400ft)
Runway 9 / 27
 length3043m (9984ft)
 bearing90° / 270°
 width46m (151ft)
 surfaceasphalt
 blast zone120m (394ft) / 120m (394ft)
Runway 15R / 33L
 length3054m (10020ft)
 bearing149° / 329°
 width46m (151ft)
 surfaceconcrete
 blast zone122m (400ft) / 122m (400ft)
Runway 8R / 26L
 length2860m (9383ft)
 bearing90° / 270°
 width46m (151ft)
 surfaceconcrete
 blast zone122m (400ft) / 122m (400ft)
Runway 8L / 26R
 length2739m (8986ft)
 bearing90° / 270°
 width46m (151ft)
 surfaceconcrete
 blast zone122m (400ft) / 122m (400ft)

Airport layout


Taxiway locations

 CC  EA  EB  EC  ED  EE  FA  FD
 FE  FG  FH  FK  NA  NB  NC  ND
 NE  NH  NJ  NK  NN  NP  NR  R2
 RA  RB  SA  SB  SC  SF  SG  SH
 SJ  SK  WA  WB  WC  WD  WE  WF
 WG  WH  WJ  WK  WL  WM  WN  WP
 WQ  WR  WS  WT  WU  WV  WW  WZ
Parking locations

 B6  C14W  CA  CA1  CA3  CA4  CB1  CB2
 CB3  CB4  CC1  CC2  CC3  CC4  CD1  CD2
 CD3  CD4  CE1  CE2  CE3  CE4  CE5  Central
 Conoco  Cooper  FedEx  Gate  General  Landmark  Marathon  Mesa
 New  Ramp  Terminal  United

Nearby beacons

codeidentifierdistbearingfrequency
IAHHUMBLE (HOUSTON) VORTAC0.6151°116.60
BVPNIXIN (HOUSTON) NDB7.279°326
EFDELLINGTON (HOUSTON) TACAN23.8152°109.40
CXALIBI (HOUSTON) NDB28.7345°281
DASDAISETTA VORTAC3972°116.90
MHFTRINITY (SMITH POINT) VOR/DME40.3125°113.60
TNVNAVASOTA VOR/DME41.5294°115.90
UTSHUNTSVILLE NDB48.1343°308
VUHSCHOLES (GALVESTON) VOR/DME48.8145°113
ELAEAGLE LAKE VOR/DME53.5253°116.40
CLROWDY (COLLEGE STATION) NDB60.1298°260

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
ALL
 GIFFA185mi4°
 ELD1238mi38°
 AEX3275mi75°
 LCH5213mi83°
 IDU1261mi239°
 PSX2163mi264°
 LOA4199mi328°
 CRIED1141mi339°
RW08 (ALL)
 INDIE8207mi32°
 LURIC8205mi45°
 STRYA8224mi72°
 GUMBY3156mi96°
 HOODO7105mi120°
 FLYZA5125mi146°
 RITAA6152mi222°
 PITZZ464mi263°
 STYCK8140mi339°
 BLTWY785mi347°
 WYLSN894mi352°
RW09
 INDIE8207mi32°
 LURIC8205mi45°
 STRYA8224mi72°
 GUMBY3156mi96°
 HOODO7105mi120°
 FLYZA5125mi146°
 RITAA6152mi222°
 PITZZ464mi263°
 STYCK8140mi339°
 BLTWY785mi347°
 WYLSN894mi352°
RW15 (ALL)
 INDIE8207mi32°
 LURIC8205mi45°
 STRYA8224mi72°
 GUMBY3, MMUGS4156mi96°
 HOODO7105mi120°
 FLYZA5125mi146°
 RITAA6152mi222°
 PITZZ4, BNDTO564mi263°
 STYCK8140mi339°
 BLTWY785mi347°
 WYLSN894mi352°
RW26 (ALL)
 INDIE8207mi32°
 LURIC8205mi45°
 STRYA8224mi72°
 MMUGS4156mi96°
 HOODO7105mi120°
 FLYZA5125mi146°
 RITAA6152mi222°
 BNDTO564mi263°
 STYCK8140mi339°
 BLTWY785mi347°
 WYLSN894mi352°
RW27
 INDIE8207mi32°
 LURIC8205mi45°
 STRYA8224mi72°
 MMUGS4156mi96°
 HOODO7105mi120°
 FLYZA5125mi146°
 RITAA6152mi222°
 BNDTO564mi263°
 STYCK8140mi339°
 BLTWY785mi347°
 WYLSN894mi352°
RW33 (ALL)
 INDIE8207mi32°
 LURIC8205mi45°
 STRYA8224mi72°
 MMUGS4156mi96°
 HOODO7105mi120°
 FLYZA5125mi146°
 RITAA6152mi222°
 BNDTO564mi263°
 STYCK8140mi339°
 BLTWY785mi347°
 WYLSN894mi352°

STAR starting pointsdistanceinbound heading
ALL
 DUUUK336.663°
 HTOWN250.964°
 TTORO342.6120°
 GUSHR341.5135°
 DOOBI255.5245°
 HUDZY429.3256°
RW08 (ALL)
 RIICE839.4134°
 OHIIO417.2237°
RW08L
 GESNR142.7236°
 SKNRD439.1244°
 NNCEE128.0292°
 SOULL148.5300°
RW08R
 GESNR142.7236°
 SKNRD439.1244°
 NNCEE128.0292°
 SOULL148.5300°
RW09
 RIICE839.4134°
 GESNR142.7236°
 OHIIO417.2237°
 SKNRD439.1244°
 NNCEE128.0292°
 SOULL148.5300°
RW15 (ALL)
 RIICE839.4134°
 OHIIO417.2237°
RW26 (ALL)
 RIICE839.4134°
 OHIIO417.2237°
RW26L
 TEJAS433.363°
 DRLLR5, MSCOT410.2134°
 ZEEKK243.4241°
 LINKK145.3290°
 SOULL148.5300°
RW26R
 TEJAS433.363°
 DRLLR5, MSCOT410.2134°
 ZEEKK243.4241°
 LINKK145.3290°
 SOULL148.5300°
RW27
 TEJAS433.363°
 RIICE839.4134°
 MSCOT4, DRLLR510.2134°
 OHIIO417.2237°
 ZEEKK243.4241°
 LINKK145.3290°
 SOULL148.5300°
RW33 (ALL)
 RIICE839.4134°
 OHIIO417.2237°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW08LYGUSHR (118°)GUSHR 6000ft
BEPEA (8mi, 173°) 4000ft
LIMEE (3mi, 174°) 3000ft
KABBY (4mi, 122°) 3000ft
KICKM (4mi, 90°) 3000ft
FLIBZ (8mi, 90°) 3000ft
RW08LYMAAKO (94°)MAAKO 3000ft
KABBY (5mi, 90°) 3000ft
KICKM (4mi, 90°) 3000ft
FLIBZ (8mi, 90°) 3000ft
 RNAVFLIBZ 3000ft
JACEN (3mi, 90°) 2000ft
KIAH (7mi, 109°) 150ft
(5683mi, 107°) 580ft
CLEEP (5673mi, 288°) 4000ft
CLEEP (turn)
RW08LZGUSHR (118°)GUSHR 6000ft
BEPEA (8mi, 173°) 4000ft
LIMEE (3mi, 174°) 3000ft
KABBY (4mi, 122°) 3000ft
KICKM (4mi, 90°) 3000ft
RW08LZMAAKO (94°)MAAKO
KABBY (5mi, 90°) 3000ft
KICKM (4mi, 90°) 3000ft
 RNAVKICKM 3000ft
FLIBZ (8mi, 90°) 3000ft
JACEN (3mi, 90°) 2000ft
KIAH (7mi, 109°) 150ft
(5683mi, 107°) 580ft
CLEEP (5673mi, 288°) 4000ft
CLEEP (turn)
RW08RYLASSY (93°)LASSY
DPLOY (5mi, 90°) 7000ft
JELLI (4mi, 90°) 5000ft
RW08RYTTORO (106°)TTORO 8000ft
BGBUK (7mi, 160°) 7000ft
LASSY (3mi, 122°) 7000ft
DPLOY (5mi, 90°) 7000ft
JELLI (4mi, 90°) 5000ft
RW08RYWDLNS (80°)WDLNS 7000ft
POLLN (8mi, 38°) 7000ft
DPLOY (2mi, 72°) 7000ft
JELLI (4mi, 90°) 5000ft
 RNAVJELLI 5000ft
REIGN (4mi, 90°) 4000ft
EELPO (4mi, 90°) 3000ft
MATON (4mi, 90°) 2000ft
KIAH (6mi, 103°) 149ft
MKAYE (23mi, 87°) 3000ft
MKAYE (turn)
RW08RZLASSY (93°)LASSY
DPLOY (5mi, 90°) 7000ft
JELLI (4mi, 90°) 5000ft
RW08RZTTORO (106°)TTORO 8000ft
BGBUK (7mi, 160°) 7000ft
LASSY (3mi, 122°) 7000ft
DPLOY (5mi, 90°) 7000ft
JELLI (4mi, 90°) 5000ft
RW08RZWDLNS (80°)WDLNS 7000ft
POLLN (8mi, 38°) 7000ft
DPLOY (2mi, 72°) 7000ft
JELLI (4mi, 90°) 5000ft
 RNAVJELLI 5000ft
REIGN (4mi, 90°) 4000ft
EELPO (4mi, 90°) 3000ft
MATON (4mi, 90°) 2000ft
KIAH (6mi, 103°) 149ft
(5683mi, 107°) 295ft
MKAYE (5661mi, 288°) 3000ft
MKAYE (turn)
RW09-YHOWLN (57°)HOWLN 6000ft
TEXXN (4mi, 270°) 6000ft
HHOOG (3mi, 305°) 4900ft
SAYNO (4mi, 43°) 3000ft
RW09-YURANG (91°)URANG
CHILT (5mi, 90°) 5000ft
MEDIC (4mi, 90°) 4000ft
DOHNN (4mi, 90°) 4000ft
SAYNO (4mi, 90°) 3000ft
 RNAVSAYNO 3000ft
HYWAY (5mi, 90°) 2000ft
KIAH (5mi, 97°) 140ft
(5683mi, 107°) 580ft
JEBOX (5671mi, 287°) 3000ft
JEBOX (turn)
RW09-ZURANG (91°)URANG 5000ft
CHILT (5mi, 90°) 5000ft
MEDIC (4mi, 90°) 4000ft
 RNAVMEDIC 4000ft
DOHNN (4mi, 90°) 4000ft
SAYNO (4mi, 90°) 3000ft
HYWAY (5mi, 90°) 2000ft
KIAH (5mi, 97°) 140ft
(5683mi, 107°) 580ft
JEBOX (5671mi, 287°) 3000ft
JEBOX (turn)
RW15RDUCOZ (149°)DUCOZ 3000ft
GRAAF (5mi, 148°) 3000ft
 RNAVGRAAF 3000ft
VETTE (2mi, 148°) 3000ft
JAKPO (5mi, 148°) 2000ft
KIAH (7mi, 150°) 149ft
(5683mi, 107°) 295ft
JINIP (5682mi, 287°)
COSBI (20mi, 83°) 2000ft
COSBI (turn)
RW26LYBOZZZ (266°)BOZZZ 8000ft
VANNN (3mi, 253°) 7000ft
MKAYE (5mi, 270°) 7000ft
GRIEG (4mi, 270°) 5000ft
RW26LYGARRR (269°)GARRR 7000ft
VANNN (3mi, 288°) 7000ft
MKAYE (5mi, 270°) 7000ft
GRIEG (4mi, 270°) 5000ft
RW26LYMKAYE (267°)MKAYE 7000ft
GRIEG (4mi, 270°) 5000ft
 RNAVGRIEG 5000ft
KERNS (7mi, 270°) 3000ft
NEEKO (2mi, 270°) 2600ft
JEPNI (2mi, 270°) 2000ft
KIAH (7mi, 259°) 148ft
LUCEP (23mi, 273°) 3000ft
LUCEP (turn)
RW26LZBOZZZ (266°)BOZZZ 8000ft
VANNN (3mi, 253°) 7000ft
MKAYE (5mi, 270°) 7000ft
GRIEG (4mi, 270°) 5000ft
RW26LZGARRR (269°)GARRR 7000ft
VANNN (3mi, 288°) 7000ft
MKAYE (5mi, 270°) 7000ft
GRIEG (4mi, 270°) 5000ft
RW26LZVANNN (267°)VANNN 7000ft
MKAYE (5mi, 270°) 7000ft
GRIEG (4mi, 270°) 5000ft
 RNAVGRIEG 5000ft
KERNS (7mi, 270°) 3000ft
JEPNI (4mi, 270°) 2000ft
KIAH (7mi, 259°) 148ft
(5683mi, 107°) 293ft
LUCEP (5706mi, 287°) 3000ft
LUCEP (turn)
RW26RYHOOTI (257°)HOOTI 6000ft
GRIZL (5mi, 206°) 6000ft
ZAPPO (3mi, 242°) 5000ft
NEWLY (5mi, 270°) 5000ft
RAIDS (4mi, 270°) 4000ft
CHUBS (7mi, 270°) 3000ft
SOOPR (2mi, 270°) 2600ft
RW26RYSKLER (225°)SKLER 6000ft
DRKAR (3mi, 90°) 5100ft
SOOPR (5mi, 180°) 2600ft
RW26RYZAPPO (266°)ZAPPO
NEWLY (5mi, 270°) 5000ft
RAIDS (4mi, 270°) 4000ft
CHUBS (7mi, 270°) 3000ft
SOOPR (2mi, 270°) 2600ft
 RNAVSOOPR 2600ft
OWELL (3mi, 270°) 2000ft
KIAH (7mi, 253°) 153ft
(5683mi, 107°) 600ft
PEPBI (5686mi, 288°) 3000ft
PEPBI (turn)
RW26RZHOOTI (257°)HOOTI 6000ft
GRIZL (5mi, 206°) 6000ft
ZAPPO (3mi, 242°) 5000ft
NEWLY (5mi, 270°) 5000ft
RAIDS (4mi, 270°) 4000ft
RW26RZZAPPO (266°)ZAPPO 5000ft
NEWLY (5mi, 270°) 5000ft
RAIDS (4mi, 270°) 4000ft
 RNAVRAIDS 4000ft
CHUBS (7mi, 270°) 3000ft
OWELL (4mi, 270°) 2000ft
KIAH (7mi, 253°) 153ft
(5683mi, 107°) 600ft
PEPBI (5686mi, 288°) 3000ft
PEPBI (turn)
RW27-YCLSIK (267°)CLSIK 4000ft
GRUNG (4mi, 251°) 4000ft
SILLS (6mi, 270°) 4000ft
TRANN (5mi, 270°) 3000ft
DENTO (4mi, 270°) 2000ft
RW27-YRDFSH (282°)RDFSH 6000ft
GEYGR (7mi, 312°) 4000ft
SYYKO (4mi, 312°) 3000ft
TRANN (3mi, 288°) 3000ft
DENTO (4mi, 270°) 2000ft
RW27-YSILLS (269°)SILLS 4000ft
TRANN (5mi, 270°) 3000ft
DENTO (4mi, 270°) 2000ft
 RNAVDENTO 2000ft
FESTA (7mi, 270°) 2000ft
REDOC (4mi, 270°) 1500ft
KIAH (7mi, 265°) 139ft
(5683mi, 107°) 560ft
TICOY (5697mi, 287°) 3000ft
TICOY (turn)
RW27-ZCLSIK (267°)CLSIK 4000ft
GRUNG (4mi, 251°) 4000ft
SILLS (6mi, 270°) 4000ft
TRANN (5mi, 270°) 3000ft
DENTO (4mi, 270°) 2000ft
RW27-ZRDFSH (282°)RDFSH 6000ft
GEYGR (7mi, 312°) 4000ft
SYYKO (4mi, 312°) 3000ft
TRANN (3mi, 288°) 3000ft
DENTO (4mi, 270°) 2000ft
 RNAVDENTO 2000ft
FESTA (7mi, 270°) 2000ft
REDOC (4mi, 270°) 1500ft
KIAH (7mi, 265°) 139ft
(5683mi, 107°) 560ft
TICOY (5697mi, 287°) 3100ft
TICOY (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
DOOBI2DOOBIVHFright59 (239)°DME 10.0miICAO rules
DOOBI2JERNYVHFright60 (240)°DME 20.0miICAO rules
DRLLR5ARNNEVHFright315 (135)°DME 20.0miICAO rules
DRLLR5CHMPZVHFright340 (160)°1.0min timedICAO rules
DRLLR5DPLANVHFright328 (148)°DME 10.0miICAO rules
DRLLR5MPORTVHFright328 (148)°DME 10.0miICAO rules
DRLLR5TORNNVHFright334 (154)°< 17999ft1.0min timedICAO rules
DUUUK3CHVRNVHFright236 (56)°DME 10.0miICAO rules
DUUUK3GMANNVHFright236 (56)°DME 10.0miICAO rules
GESNR1DLAKEVHFright45 (225)°DME 20.0miICAO rules
GESNR1ZEEKKVHFright46 (226)°DME 10.0miICAO rules
GILCO5JEPEGVHFleft90 (270)°DME 10.0miICAO rules
GILCO5KUGLEVHFleft88 (268)°< 17999ftDME 10.0miICAO rules
GILCO5LAURLVHFleft139 (319)°< 17999ftDME 10.0miICAO rules
GILCO5POLNDVHFleft95 (275)°< 17999ftDME 10.0miICAO rules
GILCO5SNYDEVHFleft64 (244)°< 17999ftDME 10.0miICAO rules
GILCO5WOLDEVHFleft85 (265)°DME 6.0miICAO rules
GUSHR3ARNNEVHFright315 (135)°DME 20.0miICAO rules
GUSHR3CHMPZVHFright340 (160)°1.0min timedICAO rules
GUSHR3DPLANVHFright328 (148)°DME 10.0miICAO rules
GUSHR3MPORTVHFright328 (148)°DME 10.0miICAO rules
GUSHR3TORNNVHFright334 (154)°< 17999ft1.0min timedICAO rules
HTOWN2BRRNSVHFleft217 (37)°DME 10.0miICAO rules
HTOWN2CATTTVHFleft218 (38)°DME 10.0miICAO rules
HUDZY4BRWCKVHFleft55 (235)°DME 20.0miICAO rules
HUDZY4WAPPLVHFleft55 (235)°DME 10.0miICAO rules
LINKK1HRVNDBright52 (232)°DME 10.0miICAO rules
LINKK1JEPEGVHFleft90 (270)°DME 10.0miICAO rules
LINKK1LEVNDBleft103 (283)°DME 10.0miICAO rules
LINKK1LINKKVHFleft89 (269)°DME 10.0miICAO rules
LINKK1MULLTVHFright135 (315)°DME 10.0miICAO rules
LINKK1POLNDVHFleft95 (275)°< 17999ftDME 10.0miICAO rules
MSCOT4SUUNRVHFright329 (149)°DME 10.0miICAO rules
NNCEE1HRVNDBright52 (232)°DME 10.0miICAO rules
NNCEE1JEPEGVHFleft90 (270)°DME 10.0miICAO rules
NNCEE1LEVNDBleft103 (283)°DME 10.0miICAO rules
NNCEE1LINKKVHFleft89 (269)°DME 10.0miICAO rules
NNCEE1MULLTVHFright135 (315)°DME 10.0miICAO rules
NNCEE1POLNDVHFleft95 (275)°< 17999ftDME 10.0miICAO rules
OHIIO4LYMBOVHFright71 (251)°DME 20.0miICAO rules
OHIIO4ZEEKKVHFright46 (226)°DME 10.0miICAO rules
RIICE8BAZBLVHFleft313 (133)°< 17999ft1.0min timedICAO rules
RIICE8CHMPZVHFright340 (160)°1.0min timedICAO rules
RIICE8HOMRNVHFright313 (133)°< 17999ft1.0min timedICAO rules
RIICE8RIICEVHFright313 (133)°< 60000ftDME 10.0miICAO rules
RIICE8TORNNVHFright334 (154)°< 17999ft1.0min timedICAO rules
SKNRD4DOOBIVHFright59 (239)°DME 10.0miICAO rules
SKNRD4JERNYVHFright60 (240)°DME 20.0miICAO rules
SOULL1KCEEEVHFleft88 (268)°DME 10.0miICAO rules
SOULL1LEVNDBleft103 (283)°DME 10.0miICAO rules
SOULL1SHLLLVHFleft133 (313)°DME 10.0miICAO rules
TEJAS4BRRNSVHFleft217 (37)°DME 10.0miICAO rules
TEJAS4CATTTVHFleft218 (38)°DME 10.0miICAO rules
TTORO3SUUNRVHFright329 (149)°DME 10.0miICAO rules
ZEEKK2DLAKEVHFright45 (225)°DME 20.0miICAO rules
ZEEKK2ZEEKKVHFright46 (226)°DME 10.0miICAO rules
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
