Airports for X-Plane

Phoenix - Williams Gateway

Airport details

CountryUnited States of America
StateArizona
RegionK2
AirspaceAlbuquerque Ctr
MunicipalityMesa
Elevation1378ft (420m)
TimezoneGMT -7
Coordinates33.30783, -111.65547
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKIWA
IATA codeAZA
FAA codeIWA

Communication

Williams Gateway ATIS133.500
Williams Gateway GROUND128.250
Williams Gateway TOWER WEST120.600
Williams Gateway TOWER EAST124.750

Approach frequencies

ILS-cat-IRW30C110.1518.00mi
3° GSRW30C110.1518.00mi

Runway info

Runway 12L / 30R
 length2834m (9298ft)
 bearing131° / 311°
 width46m (151ft)
 surfaceconcrete
Runway 12C / 30C
 length3108m (10197ft)
 bearing131° / 311°
 width46m (151ft)
 surfaceconcrete
Runway 12R / 30L
 length3173m (10410ft)
 bearing131° / 311°
 width46m (151ft)
 surfaceconcrete

Airport layout - taxiway location V


Taxiway locations

 30C  30L  30R  A  B  G  P  V
 Y
Parking locations

 AIRPORT  ATSI  CARGO  GENERAL

Nearby beacons

codeidentifierdistbearingfrequency
IWAWILLIE (PHOENIX) VORTAC0.3139°113.30
PXRPHOENIX VORTAC17.4292°115.60
TFDSTANFIELD (CASA GRANDE) VORTAC28.3211°114.80
LUFLUKE (GLENDALE) TACAN38.8288°113
AVQMARANA NDB58.2154°245
PANDME5919°116.35

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW12 (ALL)
 YOTES6, SNOBL6153mi27°
 LALUZ6142mi66°
 FTHLS6256mi78°
 KATMN6138mi111°
 BNYRD682mi149°
 JUDTH7121mi257°
 IZZZO7111mi283°
 PXR117mi292°
 MAYSA7112mi316°
RW30 (ALL)
 SNOBL6, YOTES6153mi27°
 LALUZ6142mi66°
 FTHLS6256mi78°
 KATMN6138mi111°
 BNYRD682mi149°
 JUDTH7121mi257°
 IZZZO7111mi283°
 PXR117mi292°
 MAYSA7112mi316°

STAR starting pointsdistanceinbound heading
ALL
 ARLIN4, BLH551.789°
 DSERT268.2179°
 HUUTY172.6230°
 SUNSS843.0314°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12CLAKEY (181°)LAKEY
NEVKE (6mi, 254°) 5000ft
OCATU (5mi, 231°) 4200ft
RW12CPXR (112°)PXR
OCATU (7mi, 79°) 4200ft
RW12CTFD (31°)TFD
OCATU (35mi, 8°) 5000ft
OCATU (turn) 4200ft
 RNAVOCATU 4200ft
HICHI (6mi, 130°) 3300ft
KIWA (7mi, 131°) 1398ft
(6484mi, 107°) 1609ft
PADPE (6480mi, 287°)
RIYCO (15mi, 231°) 5000ft
RIYCO (turn)
RW12RLAKEY (181°)LAKEY
GEJRI (11mi, 241°) 4800ft
GEJRI (turn) 4300ft
RW12RPXR (112°)PXR
GEJRI (7mi, 83°) 4300ft
RW12RTFD (31°)TFD
GEJRI (34mi, 8°) 4300ft
GEJRI (turn) 4300ft
 RNAVGEJRI 4300ft
CEPIB (6mi, 130°) 3000ft
KIWA (6mi, 129°) 1385ft
(6484mi, 107°) 1800ft
GEJRI (6491mi, 287°) 4300ft
GEJRI (turn)
RW30CYGICGE (10°)GICGE
COMGU (9mi, 58°) 4300ft
BOBRE (8mi, 35°) 3400ft
 RNAVBOBRE 3400ft
OTRRR (6mi, 311°) 3000ft
ORIYE (3mi, 311°) 2020ft
KIWA (3mi, 310°) 1422ft
(6484mi, 107°) 2800ft
GICGE (6491mi, 286°) 5000ft
GICGE (turn)
RW30CZTYLIK (271°)TYLIK
GYANT (2mi, 180°) 3200ft
 RNAVGYANT 3200ft
ALIEE (3mi, 218°) 3000ft
OTRRR (3mi, 279°) 3000ft
KIWA (6mi, 310°) 1422ft
(6484mi, 107°) 2800ft
GICGE (6491mi, 286°) 5000ft
GICGE (turn)
RW30LTOTEC (358°)TOTEC
BBALL (11mi, 48°) 4000ft
SEZUW (12mi, 358°) 4000ft
 RNAVSEZUW 4000ft
AKYIV (6mi, 311°) 3000ft
OPUYE (3mi, 311°) 2000ft
KIWA (2mi, 315°) 1429ft
(6484mi, 107°) 1782ft
GEJRI (6491mi, 287°) 4300ft
GEJRI (turn)
RW30RGICGE (10°)GICGE
COMGU (9mi, 58°) 4300ft
WOGMA (8mi, 41°) 3500ft
RW30RPEAKS (217°)PEAKS
BAYTA (8mi, 166°) 8000ft
OMGOE (15mi, 175°) 7200ft
WOGMA (8mi, 231°) 3500ft
 RNAVWOGMA 3500ft
WUMIX (7mi, 311°) 3000ft
YADUV (3mi, 311°) 2020ft
KIWA (3mi, 307°) 1439ft
(6484mi, 107°) 2800ft
GICGE (6491mi, 286°) 5000ft
GICGE (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ARLIN4ARLINVHFright256 (76)°1.0min timedICAO rules
ARLIN4HYDRRVHFright215 (35)°1.0min timedICAO rules
BLH5ARLINVHFright256 (76)°1.0min timedICAO rules
BLH5HYDRRVHFright215 (35)°1.0min timedICAO rules
DSERT2DSERTVHFleft345 (165)°DME 10.0miICAO rules
DSERT2SHOCKVHFleft2 (182)°DME 10.0miICAO rules
HUUTY1CHEKRVHFleft16 (196)°< 14000ftDME 7.0miICAO rules
HUUTY1INWNDBright248 (68)°1.0min timedICAO rules
HUUTY1ROSEEVHFright39 (219)°< 14000ftDME 7.0miICAO rules
HUUTY1ZUNNDBleft73 (253)°18000ft - 45000ft1.5min timedICAO rules
SUNSS8BAYBIVHFleft120 (300)°DME 9.0miICAO rules
SUNSS8ITEMMVHFleft93 (273)°DME 10.0miICAO rules
SUNSS8SQUEZVHFleft120 (300)°DME 7.0miICAO rules
*) magnetic outbound (inbound) holding course
