Airports for X-Plane

Midlothian/waxahachie - Waxahachie/mid-way Regl

Airport details

CountryUnited States of America
StateTexas
RegionK4
AirspaceFt Worth Ctr
MunicipalityMidlothian
Elevation710ft (216m)
TimezoneGMT -6
Coordinates32.45829, -96.91253
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKJWY
IATA coden/a
FAA codeJWY

Communication

Waxahachie/Mid-Way Regl AWOS 3119.575
Waxahachie/Mid-Way Regl CTAF/UNICOM122.975
Waxahachie/Mid-Way Regl REGIONAL Approach/Departure125.200
Nearby Points of Interest:
Chautauqua Auditorium
-
West End Historic District
-
Ellis County Courthouse
-
Joshua Chapel A.M.E. Church
-
William Lewis House
-
Randlett House
-
W. A. Strain Farm-Strain House
-
Medical Dental Building
-
North Bishop Avenue Commercial Historic District
-
Kings Highway Conservation District, Dallas
-
Kessler Park Historic District
-
Lake Cliff
-
Houston Street Viaduct
-
Marrow Bone Spring Archeological Site
-
Ronald Kirk Bridge
-
South Boulevard–Park Row Historic District
-
Wheatley Place, Dallas
-
Dallas County Courthouse
-
Texas School Book Depository
-
Santa Fe Terminal Complex
-
Sanger Harris department store building
-
Dallas Downtown Historic District
-
One Main Place
-
Adolphus Hotel
-
Davis Building

Runway info

Runway 18 / 36
 length1983m (6506ft)
 bearing185° / 5°
 width30m (100ft)
 surfaceasphalt

Airport layout


Parking locations

 Ramp

Nearby beacons

codeidentifierdistbearingfrequency
TTTMAVERICK VOR/DME25.5343°113.10
CVECOWBOY (DALLAS) VOR/DME25.91°116.20
PQFMESQUITE NDB28.648°248
FUZRANGER (DALLAS-FORT WORTH VORTAC29.1328°115.70
NFWNAS JRB FORT WORTH (FT WO TACAN32.6301°108.70
CGQPOWELL (CORSICANA) NDB34.2129°344
FTMUFIN (FORT WORTH) NDB34.9313°365
CRSCORSICANA NDB36.8130°396
CQYCEDAR CREEK VORTAC38.8111°114.80
ACTWACO VORTAC51.1204°115.30
DTPINCK (DENTON) NDB51.5341°257
JENGLEN ROSE TACAN52.1253°115
LXYMEXIA NDB53.2154°329
CSZCROSSROADS NDB53.9112°215
GNLGROESBECK (MEXIA) VOR/DME55.8157°108.80
MJFARVILLA (GREENVILLE) TACAN56.354°109.60
ROBROBINSON (WACO) NDB57.8189°400
GVMAJOR (GREENVILLE) NDB59.951°201

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
ALL
 GARL177mi94°
 KUSSO8175mi94°
 SWABR8123mi272°

STAR starting pointsdistanceinbound heading
ALL
 SWVAY431.073°
 GREGS9, HERBZ1, JFRYE465.8151°
 FINGR7, SLANT356.4216°
 DODJE6, REEKO319.7298°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW36ACT (24°)ACT
KOTSE (39mi, 22°) 3000ft
HERNO (5mi, 93°) 3000ft
RW36ACUFF (313°)ACUFF
GADTE (12mi, 291°) 3000ft
HERNO (5mi, 273°) 3000ft
RW36CELTC (60°)CELTC
KOTSE (20mi, 74°) 3000ft
HERNO (5mi, 93°) 3000ft
 RNAVHERNO 3000ft
MIXTO (6mi, 5°) 2200ft
KJWY (5mi, 5°) 726ft
IMENE (2mi, 5°)
CHMPZ (6mi, 56°) 3000ft
CHMPZ (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
DODJE6CAPTIVHFleft73 (253)°1.0min timedICAO rules
DODJE6CQYNDBleft95 (275)°< 60000ft1.0min timedICAO rules
DODJE6GGGNDBright114 (294)°< 17999ft1.0min timedICAO rules
DODJE6HERRIVHFleft101 (281)°1.0min timedICAO rules
DODJE6WEIRSVHFleft128 (308)°< 17999ft1.0min timedICAO rules
FINGR7BIRLEVHFright35 (215)°1.5min timedICAO rules
FINGR7BYPNDBright45 (225)°< 60000ft1.0min timedICAO rules
FINGR7GAATZVHFright35 (215)°1.0min timedICAO rules
FINGR7GLOVEVHFright64 (244)°18000ft - 45000ft1.5min timedICAO rules
GREGS9ACKMEVHFright15 (195)°1.0min timedICAO rules
GREGS9HEATRVHFleft299 (119)°1.5min timedICAO rules
GREGS9KAJAYVHFright283 (103)°1.5min timedICAO rules
GREGS9MOOSEVHFleft15 (195)°1.0min timedICAO rules
GREGS9PLEBSVHFleft283 (103)°1.0min timedICAO rules
GREGS9SPSNDBleft348 (168)°1.0min timedICAO rules
GREGS9TURKIVHFright266 (86)°1.5min timedICAO rules
GREGS9UKWNDBleft283 (103)°1.0min timedICAO rules
GREGS9ZANTOVHFleft283 (103)°1.5min timedICAO rules
HERBZ1BELYYVHFleft316 (136)°DME 10.0miICAO rules
HERBZ1DEDWTVHFleft279 (99)°DME 10.0miICAO rules
HERBZ1HNKERVHFright274 (94)°DME 10.0miICAO rules
HERBZ1LNDUSVHFleft297 (117)°DME 10.0miICAO rules
HERBZ1POTZYVHFleft356 (176)°DME 10.0miICAO rules
HERBZ1TURKIVHFright266 (86)°1.5min timedICAO rules
JFRYE4BELYYVHFleft316 (136)°DME 10.0miICAO rules
JFRYE4DEDWTVHFleft279 (99)°DME 10.0miICAO rules
JFRYE4HNKERVHFright274 (94)°DME 10.0miICAO rules
JFRYE4LNDUSVHFleft297 (117)°DME 10.0miICAO rules
JFRYE4POTZYVHFleft356 (176)°DME 10.0miICAO rules
JFRYE4TURKIVHFright266 (86)°1.5min timedICAO rules
REEKO3PURRSVHFleft136 (316)°DME 10.0miICAO rules
REEKO3VDUBBVHFleft83 (263)°DME 10.0miICAO rules
SLANT3CUBANVHFright64 (244)°DME 10.0miICAO rules
SLANT3JETTTVHFright66 (246)°DME 10.0miICAO rules
SLANT3KIDDDVHFright65 (245)°DME 10.0miICAO rules
SLANT3SEEVRVHFright45 (225)°DME 10.0miICAO rules
SWVAY4AGAINVHFright195 (15)°DME 10.0miICAO rules
SWVAY4FRSTIVHFright207 (27)°DME 10.0miICAO rules
SWVAY4PUNKYVHFright259 (79)°DME 10.0miICAO rules
SWVAY4SHLLYVHFright268 (88)°DME 10.0miICAO rules
*) magnetic outbound (inbound) holding course
