Airports for X-Plane

St Petersburg-clearwater - St Pete Clearwater Intl

Airport details

CountryUnited States of America
StateFlorida
RegionK7
AirspaceMiami Oceanic Ctr
MunicipalityFeather Sound
Elevation3ft (1m)
TimezoneGMT -5
Coordinates27.90869, -82.68649
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKPIE
IATA codePIE
FAA codePIE

Communication

St Pete Clearwater Intl ATIS134.500
St Pete Clearwater Intl CTAF118.300
St Pete Clearwater Intl UNICOM122.950
St Pete Clearwater Intl Clearance DEL120.600
St Pete Clearwater Intl Ground Control121.900
St Pete Clearwater Intl Tower128.400
St Pete Clearwater Intl Tower118.300
St Pete Clearwater Intl TAMPA Approach125.300
St Pete Clearwater Intl TAMPA Departure125.300

Approach frequencies

ILS-cat-IIRW18109.118.00mi
ILS-cat-IRW36108.718.00mi
3° GSRW36108.718.00mi
3° GSRW18109.118.00mi

Runway info

Runway 18 / 36
 length2976m (9764ft)
 bearing170° / 350°
 width46m (150ft)
 surfaceasphalt
 displ threshold0m (0ft) / 283m (928ft)
 blast zone46m (151ft) / 122m (400ft)
Runway 4 / 22
 length1831m (6007ft)
 bearing43° / 223°
 width46m (150ft)
 surfaceasphalt
 blast zone8m (26ft) / 68m (223ft)

Airport layout - parking location East


Taxiway locations

 A  A1  A2  A3  A4  A5  A6  A7
 F  G  G1  G2  T
Parking locations

 CLearwater  Coast  East  GA  Gate  Hangers  Helicopter  National
 SheltAir  Signature  Spot  US

Nearby beacons

codeidentifierdistbearingfrequency
PIESAINT PETERSBURG VORTAC0.1113°116.40
PICAPOK(ST PETERSBURG-CLEARWATER NDB5.2349°360
MCFMACDILL (TAMPA) TACAN9.6105°111
TPCOSME (TAMPA) NDB13.642°368
SRQSARASOTA VOR/DME30.8166°117
LALLAKELAND VORTAC35.983°116
PGDPUNTA GORDA VOR70.1145°110.20

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW04
 MAEKO191mi360°
RW18
 ENDED141mi349°
 BAYPO1, MAEKO191mi360°
RW22
 MAEKO191mi360°
RW36
 ENDED141mi349°
 BAYPO1, MAEKO191mi360°

STAR starting pointsdistanceinbound heading
ALL
 RAYZZ225.591°
 TEEGN331.1122°
 DARBS319.9148°
 DADES835.6224°
 LZARD630.7224°
 BRDGE840.1310°
RW04
 BLFRG140.0311°
RW18
 BLFRG140.0311°
RW22
 BLFRG140.0311°
RW36
 BLFRG140.0311°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW18DONHU (169°)DONHU
DETSE (4mi, 168°) 2600ft
RW18PIE (293°)PIE
DETSE (12mi, 349°) 2600ft
DETSE (turn) 2600ft
 RNAVDETSE 2600ft
SAUND (6mi, 170°) 1600ft
WIGUS (3mi, 170°) 560ft
KPIE (3mi, 168°) 60ft
(5017mi, 109°) 207ft
RONXI (5015mi, 289°) 2600ft
RONXI (turn)
RW36PIE (293°)PIE
RONXI (13mi, 171°) 2000ft
RONXI (turn) 2000ft
RW36SRQ (346°)SRQ
RONXI (18mi, 343°) 2000ft
 RNAVRONXI 2000ft
SONES (6mi, 350°) 2000ft
SAWGA (4mi, 350°) 720ft
KPIE (3mi, 352°) 65ft
(5017mi, 109°) 210ft
DETSE (5020mi, 289°) 2600ft
DETSE (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BLFRG1BLFRGVHFright137 (317)°DME 10.0miICAO rules
BLFRG1COSARVHFleft148 (328)°DME 10.0miICAO rules
BRDGE8BRDGEVHFright138 (318)°< 17999ft1.0min timedICAO rules
DADES8EDISNVHFleft359 (179)°DME 10.0miICAO rules
DADES8OLENEVHFleft3 (183)°< 17999ft1.0min timedICAO rules
DADES8ZINGRVHFleft75 (255)°DME 10.0miICAO rules
DARBS3TABIRVHFright336 (156)°< 17999ft1.0min timedICAO rules
LZARD6LZARDVHFright45 (225)°< 17999ft1.0min timedICAO rules
LZARD6OLENEVHFleft3 (183)°< 17999ft1.0min timedICAO rules
RAYZZ2DAAWGVHFright272 (92)°DME 10.0miICAO rules
RAYZZ2RAYZZVHFright270 (90)°DME 10.0miICAO rules
TEEGN3AVTARVHFright347 (167)°DME 7.0miICAO rules
*) magnetic outbound (inbound) holding course
