Airports for X-Plane

Teterboro

Airport details

CountryUnited States of America
StateNew Jersey
RegionK6
AirspaceNew York Ctr
MunicipalityTeterboro
Elevation4ft (1m)
TimezoneGMT -5
Coordinates40.85011, -74.06084
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKTEB
IATA codeTEB
FAA codeTEB

Communication

Teterboro ATIS132.850
Teterboro Clearance DEL128.050
Teterboro Ground Control121.900
Teterboro Tower119.500
Teterboro NEW YORK Approach127.600
Teterboro NEW YORK Departure126.700

Approach frequencies

ILS-cat-IRW06108.918.00mi
ILS-cat-IRW19110.1518.00mi
3° GSRW06108.918.00mi
3° GSRW19110.1518.00mi
Nearby Points of Interest:
Brinkerhoff House
-
Fridolin Arnault House
-
John Hopper House
-
Paulison-Christie House
-
Bergen County Court House
-
First Reformed Dutch Church, Hackensack
-
Richard Outwater House
-
Bogert House
-
Kip Homestead
-
Caspar Westervelt House
-
Dutch Reformed Church in the English Neighborhood
-
Anderson Outkitchen
-
William Carlos Williams House
-
Yereance-Kettel house
-
Iviswold
-
Zabriskie-Kipp-Cadmus House
-
Brinkerhoff-Demarest House
-
James Vandelinda House
-
Adam Vandelinda House
-
Cornelius Demarest House
-
Yereance-Berry House
-
Civil War Drill Hall and Armory
-
Aycrigg Mansion
-
Banta-Coe House
-
Botany Worsted Mills Historic District

Runway info

Runway 1 / 19
 length2137m (7011ft)
 bearing4° / 184°
 width46m (150ft)
 surfaceasphalt
 displ threshold235m (771ft) / 235m (771ft)
 blast zone12m (39ft) / 30m (98ft)
Runway 6 / 24
 length1832m (6010ft)
 bearing56° / 236°
 width46m (150ft)
 surfaceasphalt
 blast zone12m (39ft) / 15m (49ft)

Airport layout


Taxiway locations

 A  B  C  D  E  F  G  H
 J  K  L  P  Q  R
Parking locations

 Atlantic  Dassault  GAMA  Gen  Jet  Meridian  One  Rop
 Signature  U.S.

Nearby beacons

codeidentifierdistbearingfrequency
TEBTETERBORO VOR/DME0.1225°108.40
TETORBY (TETERBORO) NDB4.2237°214
LGALA GUARDIA (NEW YORK) VOR/DME9.6109°113.10
MMMOREE (MORRISTOWN) NDB12.5276°392
CRICANARSIE VOR/DME16.1145°112.30
CATCHATHAM NDB18254°254
JFKKENNEDY (NEW YORK) VOR/DME18.5127°115.90
SAXSPARTA VORTAC25.2294°115.70
FRFRIKK (FARMINGDALE) NDB26.697°407
COLCOLTS NECK VOR/DME32.6190°115.40
CMKCARMEL VOR/DME33.748°116.60
DPKDEER PARK VOR/DME34.594°117.70
BWZBROADWAY (SCHOOLEY'S MT) VOR/DME34.7266°114.20
SBJSOLBERG VOR/DME34.9249°112.90
STWSTILLWATER VOR/DME37.7280°109.60
SWNEELY (NEWBURGH) NDB38.9345°335
SKUSTANWYCK (NEWBURGH) NDB40.71°261
HUOHUGUENOT VOR/DME41.3317°116.10
RBVROBBINSVILLE VORTAC43.6214°113.80
BDRBRIDGEPORT VOR/DME46.372°108.80
NELLAKEHURST NDB49.9199°396
IGNKINGSTON VOR/DME50.116°117.60
NELLAKEHURST TACAN50.6200°111.80
ARDYARDLEY VOR/DME52.7235°108.20
GXUMC GUIRE (WRIGHTSTOWN) VORTAC56.1213°110.60
PWLPAWLING (POUGHKEEPSIE) VOR/DME5927°114.30

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
STAR starting pointsdistanceinbound heading
ALL
 JAIKE395.356°
 MAZIE357.363°
 LVZ477.9105°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW06-XCOATE (114°)COATE
ELIZE (13mi, 175°) 3000ft
ALIDA (14mi, 113°) 3000ft
FRNKI (8mi, 102°) 2000ft
RW06-XSBJ (69°)SBJ
JERSE (19mi, 69°) 3400ft
FRNKI (6mi, 73°) 2000ft
RW06-XSTW (100°)STW
ELIZE (10mi, 113°) 3000ft
ALIDA (14mi, 113°) 3000ft
FRNKI (8mi, 102°) 2000ft
 RNAVFRNKI 2000ft
PESME (3mi, 71°) 1700ft
TBERN (3mi, 71°) 1300ft
JEBUV (3mi, 58°) 402ft
(4686mi, 119°) 408ft
FEREP (4688mi, 299°) 2000ft
FEREP (turn)
RW06-YCOATE (114°)COATE
ELIZE (13mi, 175°) 3000ft
ALIDA (14mi, 113°) 3000ft
DWURF (4mi, 104°) 3000ft
JUGGY (6mi, 113°) 2000ft
RW06-YSBJ (69°)SBJ
ALIDA (20mi, 57°) 3000ft
DWURF (4mi, 104°) 3000ft
JUGGY (6mi, 113°) 2000ft
RW06-YSTW (100°)STW
ELIZE (10mi, 113°) 3000ft
ALIDA (14mi, 113°) 3000ft
DWURF (4mi, 104°) 3000ft
JUGGY (6mi, 113°) 2000ft
 RNAVJUGGY 2000ft
DANDY (4mi, 56°) 1500ft
STICC (2mi, 56°) 1300ft
KTEB (4mi, 57°) 58ft
(4685mi, 119°) 369ft
YABUL (4684mi, 299°)
ANGLE (4mi, 47°) 2000ft
ANGLE (turn)
RW06-ZCOATE (114°)COATE
ELIZE (13mi, 175°) 3000ft
GUZTI (20mi, 121°) 3000ft
RW06-ZSBJ (69°)SBJ
GUZTI (20mi, 73°) 3000ft
RW06-ZSTW (100°)STW
ELIZE (10mi, 113°) 3000ft
GUZTI (20mi, 121°) 3000ft
 RNAVGUZTI 3000ft
CATXO (6mi, 50°) 2000ft
HOLUR (3mi, 68°) 1700ft
EVEGE (2mi, 84°) 1500ft
AWKEB (turn)
OFFEC (1mi, 71°)
KTEB (3mi, 58°) 59ft
PIXDY (4mi, 54°)
ANGLE (2mi, 34°) 2000ft
ANGLE (turn)
RW19-XCUROK (158°)CUROK
WHOLN (4mi, 142°) 2300ft
MOOGZ (4mi, 148°) 1700ft
 RNAVMOOGZ 1700ft
DUUNE (3mi, 174°) 1500ft
COFFS (4mi, 167°) 218ft
(4685mi, 119°) 408ft
BUBGE (4691mi, 299°) 1500ft
EXAMM (6mi, 264°) 3000ft
EXAMM (turn) 3000ft
RW19-YSTRAD (142°)STRAD
SKUBY (5mi, 113°) 2800ft
NIPIE (5mi, 113°) 2600ft
UNVIL (6mi, 130°) 2100ft
 RNAVUNVIL 2100ft
TUGGZ (6mi, 184°) 1500ft
KTEB (5mi, 185°) 60ft
(4685mi, 119°) 500ft
BUBGE (4691mi, 299°) 1500ft
EXAMM (6mi, 264°) 3000ft
EXAMM (turn) 3000ft
RW19-ZCOATE (114°)COATE
LELME (14mi, 109°) 3000ft
COMOK (12mi, 85°) 3000ft
HOOTH (6mi, 135°) 2000ft
RW19-ZSBJ (69°)SBJ
SHOTT (20mi, 39°) 3000ft
LELME (11mi, 31°) 3000ft
COMOK (12mi, 85°) 3000ft
HOOTH (6mi, 135°) 2000ft
RW19-ZSTW (100°)STW
LELME (21mi, 85°) 3000ft
COMOK (12mi, 85°) 3000ft
HOOTH (6mi, 135°) 2000ft
 RNAVHOOTH 2000ft
ALSIW (3mi, 165°) 1500ft
JAPIR (4mi, 184°) 284ft
FOXIB (8mi, 245°) 1500ft
MORNS (6mi, 288°) 3000ft
MORNS (turn)
RW24STRAD (142°)STRAD
SKUBY (5mi, 113°) 2800ft
NIPIE (5mi, 113°) 2600ft
WHEZY (6mi, 121°) 2200ft
SHREW (6mi, 121°) 2000ft
 RNAVSHREW 2000ft
ANGLE (4mi, 219°) 1700ft
BAITH (5mi, 229°) 137ft
(4685mi, 119°) 408ft
BUBGE (4691mi, 299°) 1500ft
CODOL (14mi, 254°) 2000ft
CODOL (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
JAIKE3MAZIEVHFleft237 (57)°< 17999ft1.0min timed210
JAIKE3PALEOVHFleft232 (52)°< 45000ft1.5min timedICAO rules
JAIKE3SPNCRVHFright227 (47)°6001ft - 14000ftDME 4.0mi210
LVZ4HARTYVHFleft305 (125)°18000ft - 45000ft1.5min timedICAO rules
LVZ4HOXIEVHFleft295 (115)°18000ft - 45000ftDME 6.0miICAO rules
LVZ4MUGZYVHFleft305 (125)°6001ft - 14000ft1.0min timed210
MAZIE3BACKYVHFright216 (36)°DME 7.0miICAO rules
MAZIE3MAZIEVHFleft237 (57)°< 17999ft1.0min timed210
MAZIE3RAZERVHFright229 (49)°< 60000ftDME 6.0mi210
*) magnetic outbound (inbound) holding course
