Country | Croatia |
State | Primorje-Gorski Kotar |
Region | LD |
Airspace | Zagreb Ctr |
Municipality | Općina Omišalj |
Elevation | 274ft (84m) |
Timezone | GMT +1 |
Coordinates | 45.21689, 14.57027 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | LDRI |
IATA code | RJK |
FAA code | n/a |
Rijeka Tower | 119.000 |
Rijeka Approach | 124.600 |
ILS-cat-I | RW14 | 108.5 | 18.00mi |
3° GS | RW14 | 108.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
RJK | RIJEKA VOR/DME | 0.4 | 335° | 117.80 |
RI | RIJEKA (KRK ISLAND) NDB | 5.9 | 134° | 289 |
KO | KOZALA (RIJEKA) NDB | 8.7 | 314° | 438 |
BRZ | BREZA NDB | 15.6 | 313° | 400 |
CRE | CRES NDB | 19.9 | 206° | 433 |
ILB | BISTRICA VOR/DME | 26.8 | 311° | 114.80 |
KAV | KAVRAN NDB | 30.6 | 240° | 265 |
TNJ | TOUNJ NDB | 33 | 88° | 316 |
PUL | PULA VOR/DME | 33.8 | 244° | 111.25 |
VL | VALTURA NDB | 34.7 | 244° | 320 |
GS | PULA NDB | 36.1 | 246° | 420 |
VRS | VRSAR NDB | 38.9 | 270° | 369 |
NTL | LOSINJ VOR/DME | 39.7 | 195° | 117.35 |
PLA | PULA NDB | 39.8 | 248° | 351 |
LOS | LOSINJ NDB | 41.6 | 188° | 429 |
LSJ | DME | 42.2 | 186° | 108.45 |
PZ | PORTOROZ NDB | 43.2 | 285° | 388 |
POR | PORTOROZ VOR/DME | 43.3 | 285° | 115.15 |
DOL | DOLSKO VOR/DME | 52.8 | 14° | 112.70 |
RK | CERKLJE-RAKA NDB | 53.5 | 50° | 359 |
CL | CERKLJE-HRASTJE NDB | 56.5 | 54° | 463 |
COK | CERKLJE VOR/DME | 57.3 | 54° | 108.25 |
MG | LJUBLJANA NDB | 57.4 | 359° | 296 |
Transition altitude | 9500ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW14 | |||
ALIV3C, ALIV1X, ALIV1W | 20mi | 29° | |
RUGO1X, RUGO1W, RUGO1C | 32mi | 85° | |
CRE4H, CRE1W | 20mi | 206° | |
PUL3R | 34mi | 244° | |
NAKI3C | 48mi | 269° | |
RW32 | |||
ALIV1U, ALIV1V, ALIV3D | 20mi | 29° | |
RUGO1U, RUGO1D, RUGO1V | 32mi | 85° | |
CRE4G, CRE1V | 20mi | 206° | |
PUL3L | 34mi | 244° | |
NAKI3D | 48mi | 269° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
CRE4B, CRE4K | 19.9 | 26° | |
PUL3B, PUL3A | 33.8 | 64° | |
GIRD1G, GIRD1H | 24.0 | 121° | |
KULE4A, KULE3B | 24.0 | 275° | |
RW14 | |||
PUL1Z | 33.8 | 64° | |
ROTA1W | 66.6 | 92° | |
GIRD1X | 24.0 | 121° | |
RW32 | |||
CRE1Y | 19.9 | 26° | |
GIRD1T, GIRD1U | 24.0 | 121° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW14 | GIRDA (121°) | GIRDA 8000ft RI408 (4mi, 104°) 6300ft BRZ (5mi, 104°) 4500ft RI409 (4mi, 129°) 3400ft |
RW14 | IRDAX (164°) | IRDAX 8000ft RI402 (8mi, 311°) 5500ft BRZ (3mi, 240°) 4500ft RI409 (4mi, 129°) 3400ft |
RW14 | SORDO (113°) | SORDO 7000ft RI401 (3mi, 76°) 6000ft BRZ (5mi, 77°) 4500ft RI409 (4mi, 129°) 3400ft |
RNAV | RI409 3400ft NEGVI (3mi, 134°) 2900ft LDRI (9mi, 134°) 316ft RI405 (11mi, 134°) RI406 (7mi, 242°) RI407 (16mi, 314°) 6000ft IRDAX (11mi, 45°) 8000ft IRDAX (turn) 8000ft | |
RW32 | BIMSI (342°) | BIMSI 5000ft RI502 (7mi, 63°) 4600ft |
RW32 | PEMUD (290°) | PEMUD 8000ft RI501 (5mi, 259°) 6300ft RI502 (5mi, 258°) 4600ft |
RNAV | RI502 4600ft NUSKA (7mi, 314°) 3000ft LDRI (9mi, 314°) 296ft RI505 (4mi, 314°) RI504 (7mi, 240°) BIMSI (19mi, 134°) 5000ft BIMSI (turn) 5000ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
CRE1Y | PEMUD | VHF | right | 69 (249)° | > 8000ft | 1.0min timed | 210 |
CRE4B | RI | FIX | right | 320 (140)° | > 5000ft | 1.0min timed | 200 |
CRE4K | BRZ | FIX | right | 324 (144)° | > 6400ft | 1.0min timed | 190 |
CRE4K | RI | FIX | right | 320 (140)° | > 5000ft | 1.0min timed | 200 |
GIRD1G | BRZ | FIX | right | 324 (144)° | > 6400ft | 1.0min timed | 190 |
GIRD1H | BRZ | FIX | right | 324 (144)° | > 6400ft | 1.0min timed | 190 |
GIRD1H | RI | FIX | right | 320 (140)° | > 5000ft | 1.0min timed | 200 |
GIRD1T | PEMUD | VHF | right | 69 (249)° | > 8000ft | 1.0min timed | 210 |
GIRD1U | PEMUD | VHF | right | 69 (249)° | > 8000ft | 1.0min timed | 210 |
GIRD1X | IRDAX | VHF | right | 109 (289)° | > 8000ft | 1.0min timed | 210 |
KULE3B | RI | FIX | right | 320 (140)° | > 5000ft | 1.0min timed | 200 |
KULE4A | BRZ | FIX | right | 324 (144)° | > 6400ft | 1.0min timed | 190 |
LOS1P | PEMUD | VHF | right | 69 (249)° | > 8000ft | 1.0min timed | 210 |
PUL1Z | IRDAX | VHF | right | 109 (289)° | > 8000ft | 1.0min timed | 210 |
PUL3A | BRZ | FIX | right | 324 (144)° | > 6400ft | 1.0min timed | 190 |
PUL3B | RI | FIX | right | 320 (140)° | > 5000ft | 1.0min timed | 200 |
ROTA1W | IRDAX | VHF | right | 109 (289)° | > 8000ft | 1.0min timed | 210 |
*) magnetic outbound (inbound) holding course |
