Airports for X-Plane

Sevilla - Sevilla San Pablo

Airport details

CountrySpain
StateAndalusia
RegionLE
AirspaceMadrid Ctr
MunicipalitySeville
Elevation105ft (32m)
TimezoneGMT +1
Coordinates37.41806, -5.89889
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeLEZL
IATA codeSVQ
FAA coden/a

Communication

Sevilla San Pablo Seville ATIS118.175
Sevilla San Pablo Seville Ground121.700
Sevilla San Pablo Seville Tower118.100
Sevilla San Pablo Seville Approach128.500
Sevilla San Pablo Seville Approach120.800

Approach frequencies

ILS-cat-IRW09111.118.00mi
ILS-cat-IRW27110.118.00mi
3° GSRW09111.118.00mi
3° GSRW27110.118.00mi
Nearby Points of Interest:
Lugar del Fusilamiento de Blas Infante
-
Yacimiento arqueológico del Cortijo de Miraflores y Huerta de la Albarrana
-
Casa Duclós
-
Antigua Universidad Laboral
-
Monastery of San Jerónimo de Buenavista, Seville
-
Templete de San Jerónimo
-
Convento de Capuchinos
-
Casa del Rey Moro
-
Iglesia de San Julián
-
Hospital de las Cinco Llagas
-
Palacio del Pumarejo
-
iglesia de San Gil (Sevilla)
-
Real Fábrica de Artillería of Seville
-
Palacio de Villapanes (Sevilla)
-
Corral del Conde
-
Palacio de Mañara
-
Archivo Histórico Provincial de Sevilla
-
La Carbonería
-
Convento de Madre de Dios
-
Viviendas y Estación de Autobuses del Prado de San Sebastián
-
City walls of Seville
-
Casa de las Sirenas
-
Hospital de los Venerables
-
casa natal de Luis Cernuda
-
Iglesia del Convento de la Asunción

Runway info

Runway 09 / 27
 length3363m (11033ft)
 bearing90° / 270°
 width45m (148ft)
 surfaceasphalt

Airport layout


Taxiway locations

 A1  A2  A4  E1  E3  E5  G6  HP1
 HP2  HP3  HP4  S2
Parking locations

 Business  Cargo  GA  Gate  Mil  Ryanair

Nearby beacons

codeidentifierdistbearingfrequency
SPPSEVILLE NDB4.990°420
SVLSEVILLE VOR/DME6.586°113.70
EECEL COPERO (SEVILLA) NDB8224°327
MRNMORON (SEVILLE) VOR/DME19.7131°115.50
JERJEREZ NDB35.4191°433
JRZJEREZ VOR/DME36.7192°113
MARMARTIN VOR/DME50.7111°112.60
AOGROTA TACAN51210°108.60

Departure and arrival routes

Transition altitude6000ft
SID end pointsdistanceoutbound heading
RW09
 HIJ2R76mi36°
 BUDI2R165mi81°
 VIBA2R108mi91°
 VJF3R71mi184°
 JRZ2R37mi192°
 CLAN3R68mi222°
 ONUB3R42mi259°
 SANT3R24mi302°
RW27
 HIJ4G101mi25°
 HIJ1P76mi36°
 BUDI3G165mi81°
 VIBA3G108mi91°
 VJF2G71mi184°
 JRZ2G37mi192°
 CLAN3G68mi222°
 ONUB2G42mi259°
 SANT2P, SANT4G24mi302°

STAR starting pointsdistanceinbound heading
RW09
 VJF4F70.84°
 OSLE2F63.679°
 SANT4F24.2122°
 HIJ4F75.6216°
 BLN2K, BLN3F116.5252°
 MAMI1F146.3260°
 VIBA4F108.2271°
RW27
 VJF4E, VJF3M70.84°
 OSLE2E, OSLE2M63.679°
 SANT3E24.2122°
 HIJ4E75.6216°
 BLN3E116.5252°
 MAMI1E, MAMI1M146.3260°
 VIBA3E, VIBA2M108.2271°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BLN2KTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
BLN3ERUVENVHFright43 (223)°> 6000ftDME 5.0miICAO rules
BLN3FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
HIJ4ERUVENVHFright43 (223)°> 6000ftDME 5.0miICAO rules
HIJ4FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
MAMI1ESPPFIXright91 (271)°> 2000ft1.0min timed210
MAMI1FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
MAMI1MRUVENVHFright43 (223)°> 6000ftDME 5.0miICAO rules
MAR3MSVLNDBright84 (264)°> 3000ftDME 5.0mi220
MAR4ESPPFIXright91 (271)°> 2000ft1.0min timed210
MAR5FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
OSLE2ESPPFIXright91 (271)°> 2000ft1.0min timed210
OSLE2FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
OSLE2MSVLNDBright84 (264)°> 3000ftDME 5.0mi220
SANT3ESVLNDBright84 (264)°> 3000ftDME 5.0mi220
SANT4FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
VIBA2MSVLNDBright84 (264)°> 3000ftDME 5.0mi220
VIBA3ESPPFIXright91 (271)°> 2000ft1.0min timed210
VIBA4FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
VJF3MSVLNDBright84 (264)°> 3000ftDME 5.0mi220
VJF4ESPPFIXright91 (271)°> 2000ft1.0min timed210
VJF4FTENDUVHFleft270 (90)°> 2000ftDME 5.0miICAO rules
*) magnetic outbound (inbound) holding course
