Airports for X-Plane

Salzburg - Salzburg Maxglan

Airport details

CountryAustria
StateSalzburg
RegionLO
AirspaceVienna Ctr
Elevation1411ft (430m)
TimezoneGMT +1
Coordinates47.79598, 12.99777
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeLOWS
IATA codeSZG
FAA coden/a

Communication

Salzburg Maxglan ATIS133.330
Salzburg Maxglan Ground Control121.750
Salzburg Maxglan Tower118.100
Salzburg Maxglan Departure123.725

Approach frequencies

ILS-cat-IIIRW15109.918.00mi
3° GSRW15109.918.00mi
Nearby Points of Interest:
Römische Villa Loig
-
Pfarrkirche Maxglan
-
Church of the Nativity of the Virgin Mary
-
Johannsspitalkirche
-
Lürzerhof
-
Pfarrkirche zum heiligen Georg
-
Schloss Schönleiten
-
University Hospital Salzburg
-
Herz-Jesu-Asylkirche
-
Müllegger Tor, Salzburg
-
Johannesschlössl
-
Marketenderschlössl
-
Literaturhaus Salzburg
-
USFA Wohnhaussiedlung General-Keyes-Straße
-
Augustiner Bräu Kloster Mülln Salzburg
-
Pfarrkirche Mülln
-
Sigmundstor
-
Schlossbauerngut
-
Altstadt (Salzburg)
-
Kupelwieser-Schlössl, Salzburg
-
Grasmayr-Villa
-
Lehen parish church
-
Edmundsburg
-
Alte Universität
-
Freyschlössl

Runway info

Runway 15 / 33
 length2747m (9012ft)
 bearing148° / 328°
 width45m (148ft)
 surfaceconcrete
 displ threshold198m (650ft) / 240m (787ft)
 blast zone125m (410ft) / 0m (0ft)

Airport layout - taxiway location B


Taxiway locations

 B  C  D  E  F  L  S
Parking locations

 E1  E2  E3  E4  E5  E6  E7  E8
 E9  G21  G22  G23  G24  G31  G32  G33
 G34  G81  G82  G83  G84  G85  G86  G87
 G88  Helipad  W1  W2  W3  W4  W5  W6
 W7  W8

Nearby beacons

codeidentifierdistbearingfrequency
SISALZBURG NDB1.4336°410
GSBDME4.685°109.45
SBGSALZBURG NDB11.1329°382
SBGSALZBURG VOR/DME13.1333°113.80

Departure and arrival routes

Transition altitude6000ft
SID end pointsdistanceoutbound heading
RW15
 INRO1B, INRO1X15mi42°
 NEMA3B21mi76°
 VERD1Y, VERD2B, VERD1X21mi128°
 DETS2B66mi216°
 RTT4B48mi251°
 TRAU8V, TRAU3B, TRAU1X20mi294°
 TITI3B24mi301°
RW33
 INRO1A, INRO1S15mi42°
 NEMA3A21mi76°
 VERD1A21mi128°
 DETS1A66mi216°
 RTT3A48mi251°
 TRAU2A, TRAU7S20mi294°
 TITI2A24mi301°
 SBG1S, SBG2A11mi329°

STAR starting pointsdistanceinbound heading
ALL
 UNKE1R16.094°
 TRAU1R19.7114°
 TITI1R23.6121°
 BADI1R23.0156°
 MATI1R26.9244°
 NUBR2R38.0273°
 RAST1R23.8308°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW15-EWS813 (125°)WS813 5000ft
WS815 (5mi, 74°) 4000ft
WS816 (5mi, 148°) 4000ft
RW15-EWS814 (178°)WS814 5000ft
WS815 (5mi, 254°) 4000ft
WS816 (5mi, 148°) 4000ft
RW15-EWS815 (149°)WS815 4000ft
WS816 (5mi, 148°) 4000ft
 RNAVWS816 4000ft
LOWS (8752mi, 123°) 1467ft
WS818 (8748mi, 302°)
WS815 (15mi, 328°) 6000ft
WS815 (turn)
RW15-XWS813 (125°)WS813 5000ft
WS815 (5mi, 74°) 4000ft
WS816 (5mi, 148°) 4000ft
RW15-XWS814 (178°)WS814 5000ft
WS815 (5mi, 254°) 4000ft
WS816 (5mi, 148°) 4000ft
RW15-XWS815 (149°)WS815 4000ft
WS816 (5mi, 148°) 4000ft
 RNAVWS816 4000ft
WS817 (4mi, 148°) 2659ft
(2953mi, 195°) 2659ft
WS815 (2960mi, 15°) 6000ft
WS815 (turn)
RW33-VWS831 (151°)WS831 5000ft
WS833 (5mi, 96°) 5000ft
RW33-VWS832 (208°)WS832 5000ft
WS833 (5mi, 248°) 5000ft
 RNAVWS833 5000ft
WS834 (6mi, 163°) 5000ft
WS835 (3mi, 163°) 3980ft
WS831 (12mi, 314°) 6000ft
WS831 (turn)
RW33-YWS831 (151°)WS831 5000ft
WS833 (5mi, 96°) 5000ft
RW33-YWS832 (208°)WS832 5000ft
WS833 (5mi, 248°) 5000ft
 RNAVWS833 5000ft
WS834 (6mi, 163°) 5000ft
WS836 (6mi, 163°)
WS837 (2mi, 258°)
LOWS (8747mi, 122°) 1461ft
WS831 (8753mi, 303°) 6000ft
WS831 (turn)
RW33-ZETROK (304°)ETROK 10000ft
WS806 (7mi, 286°) 7400ft
WS805 (5mi, 310°) 5500ft
RW33-ZKONUG (338°)KONUG 11500ft
WS811 (3mi, 358°) 10500ft
WS810 (3mi, 358°) 9500ft
WS809 (3mi, 358°) 8500ft
WS808 (2mi, 18°) 7900ft
WS807 (4mi, 350°) 6500ft
WS805 (3mi, 344°) 5500ft
 RNAVWS805 5500ft
WS804 (4mi, 332°) 4000ft
WS803 (2mi, 308°)
WS802 (1mi, 289°)
WS801 (turn)
WS800 (turn)
LOWS (8747mi, 122°) 1461ft
WS823 (8752mi, 303°)
SBG (turn) 6000ft
SBG (turn) 6000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BADI1RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
MATI1RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
NUBR2RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
RAST1RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
TITI1RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
TRAU1RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
UNKE1RSBGNDBleft355 (175)°> 4000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
