Airports for X-Plane

Arad

Airport details

CountryRomania
StateArad
RegionLR
AirspaceBucharest Ctr
Elevation352ft (107m)
TimezoneGMT +2
Coordinates46.17667, 21.26194
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeLRAR
IATA codeARW
FAA coden/a

Communication

ARAD ATIS123.125
ARAD Tower130.200
ARAD Approach127.250

Approach frequencies

ILS-cat-IIRW27110.718.00mi
3° GSRW27110.718.00mi

Runway info

Runway 09 / 27
 length1994m (6542ft)
 bearing94° / 274°
 width45m (148ft)
 surfaceconcrete
 displ threshold0m (0ft) / 180m (591ft)

Airport layout - parking location 1A


Taxiway locations

 A
Parking locations

 1  1A  2  2A  3  3A  4  5
 6  7  GA

Nearby beacons

codeidentifierdistbearingfrequency
ARDARAD NDB4.8274°517
ARDARAD VOR/DME4.9274°109
TATIMISOARA NDB20.4185°378
TSRTRAIAN VUIA (TIMISOARA) NDB21.6173°408
TIMTRAIAN VUIA (TIMISOARA) NDB23164°338
BCBEKESCSABA NDB29.5349°400
CNIDME31.3218°115.60
BKSBEKES VOR/DME38.2343°115.80
LGJLUGOJ TACAN41.1122°134
OORADEA NDB58.537°360
ORAORADEA NDB61.836°418

Departure and arrival routes

Transition altitude9000ft
SID end pointsdistanceoutbound heading
RW09
 NOPT2P, NOPT2H32mi79°
 DITA2H, DITA2P62mi123°
 MAVI2P, MAVI2H56mi177°
 MOPU2H, MOPU2P23mi269°
RW27
 NOPT2N, NOPT3G32mi79°
 DITA3G, DITA2N62mi123°
 MAVI3G, MAVI2N56mi177°
 MOPU2N, MOPU3G23mi269°

STAR starting pointsdistanceinbound heading
ALL
 ROMU2K32.863°
 VASI2K49.6281°
 NEKU2K68.1296°
 MAVI2K56.2357°
RW09
 ROMU2D32.863°
 VASI2D49.6281°
 NEKU2D68.1296°
 MAVI2D56.2357°
RW27
 ROMU2C32.863°
 VASI2C49.6281°
 NEKU2C68.1296°
 MAVI2C56.2357°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
MAVI2CDIVELVHFleft175 (355)°> 7000ft1.0min timedICAO rules
MAVI2DDIVELVHFleft175 (355)°> 7000ft1.0min timedICAO rules
MAVI2KARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
MAVI2KTSRFIXleft285 (105)°> 3000ft1.0min timed230
NEKU2CDIPUXVHFright105 (285)°> 7000ft1.0min timedICAO rules
NEKU2DDIPUXVHFright105 (285)°> 7000ft1.0min timedICAO rules
NEKU2KAGASUVHFright119 (299)°> 7000ft1.0min timedICAO rules
NEKU2KARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
ROMU2KARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
TEGR2CARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
TEGR2DARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
TEGR2KARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
VASI2CDIPUXVHFright105 (285)°> 7000ft1.0min timedICAO rules
VASI2DDIPUXVHFright105 (285)°> 7000ft1.0min timedICAO rules
VASI2KAGASUVHFright119 (299)°> 7000ft1.0min timedICAO rules
VASI2KARDNDBright270 (90)°> 3000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
