Country | Romania |
State | Sibiu |
Region | LR |
Airspace | Bucharest Ctr |
Elevation | 1520ft (463m) |
Timezone | GMT +2 |
Coordinates | 45.78583, 24.08556 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | LRSB |
IATA code | SBZ |
FAA code | n/a |
Sibiu ATIS | 126.950 |
Sibiu Tower ALTN | 122.700 |
Sibiu Tower | 121.305 |
Sibiu NAPOC Approach | 126.430 |
Sibiu NAPOC North Approach | 126.430 |
Sibiu NAPOC South Approach | 119.680 |
ILS-cat-II | RW27 | 110.7 | 18.00mi |
3° GS | RW27 | 110.7 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
SBI | SIBIU VOR/DME | 0.3 | 155° | 114 |
SIB | SIBIU NDB | 2.8 | 91° | 381 |
CHU | CIUHII DME | 38.8 | 62° | 109.20 |
TGM | TARGU MURES NDB | 40.7 | 18° | 428 |
D | TARGU MURES NDB | 42.4 | 24° | 373 |
TGJ | TARGU JIU VOR/DME | 53.8 | 226° | 115.30 |
BAI | DME | 55.1 | 310° | 117.95 |
Transition altitude | 7000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW09 | |||
DOKU1P, DOKU1J | 55mi | 52° | |
ULMI1J, ULMI1P | 29mi | 272° | |
RW27 | |||
DOKU1Q, DOKU1W | 55mi | 52° | |
ULMI1Q, ULMI1W | 29mi | 272° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW09 | |||
IBIN1R | 34.6 | 99° | |
AKUP1R | 74.1 | 194° | |
DOKU1R | 54.7 | 232° | |
MOBR1R | 31.0 | 264° | |
EDET1R | 35.4 | 271° | |
RW27 | |||
IBIN2S, IBIN1Z | 34.6 | 99° | |
AKUP2S, AKUP1Z | 74.1 | 194° | |
DOKU1Z, DOKU2S | 54.7 | 232° | |
MOBR1S, MOBR1Z | 31.0 | 264° | |
EDET1S, EDET1Z | 35.4 | 271° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
AKUP1R | PIKUV | VHF | right | 346 (166)° | > 9000ft | 1.0min timed | ICAO rules |
AKUP1Z | PIKUV | VHF | right | 346 (166)° | > 9000ft | 1.0min timed | ICAO rules |
AKUP2S | PIKUV | VHF | right | 346 (166)° | > 9000ft | 1.0min timed | ICAO rules |
DOKU1R | PIKUV | VHF | right | 346 (166)° | > 9000ft | 1.0min timed | ICAO rules |
DOKU1Z | PIKUV | VHF | right | 346 (166)° | > 9000ft | 1.0min timed | ICAO rules |
DOKU2S | PIKUV | VHF | right | 346 (166)° | > 9000ft | 1.0min timed | ICAO rules |
EDET1R | MOBRA | VHF | left | 76 (256)° | > 11000ft | 1.0min timed | ICAO rules |
EDET1S | EDETA | VHF | right | 87 (267)° | > 11000ft | 1.0min timed | ICAO rules |
EDET1Z | EDETA | VHF | right | 87 (267)° | > 11000ft | 1.0min timed | ICAO rules |
IBIN1R | IBINU | VHF | right | 277 (97)° | > 11000ft | 1.0min timed | ICAO rules |
IBIN2S | IBINU | VHF | right | 277 (97)° | > 11000ft | 1.0min timed | ICAO rules |
MOBR1R | MOBRA | VHF | left | 76 (256)° | > 11000ft | 1.0min timed | ICAO rules |
MOBR1S | MOBRA | VHF | left | 76 (256)° | > 11000ft | 1.0min timed | ICAO rules |
MOBR1Z | MOBRA | VHF | left | 76 (256)° | > 11000ft | 1.0min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
