Airports for X-Plane

Erzurum

Airport details

CountryTurkey
StateErzurum Province
RegionLT
AirspaceAnkara Ctr
MunicipalityErzurum
Elevation5763ft (1757m)
TimezoneGMT +3
Coordinates39.95419, 41.18719
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeLTCE
IATA codeERZ
FAA coden/a

Communication

Erzurum Ground Control121.950
Erzurum Tower118.100
Erzurum Tower122.100
Erzurum Approach122.100
Erzurum Approach118.100

Approach frequencies

ILS-cat-IIIRW26R110.518.00mi
ILS-cat-IRW08L110.718.00mi
3.2° GSRW26R110.518.00mi
3° GSRW08L110.718.00mi

Runway info

Runway 08R / 26L
 length3813m (12510ft)
 bearing89° / 269°
 width30m (98ft)
 surfaceconcrete
 blast zone149m (489ft) / 149m (489ft)
Runway 08L / 26R
 length3814m (12513ft)
 bearing89° / 269°
 width45m (148ft)
 surfaceconcrete
 blast zone163m (535ft) / 144m (472ft)
Runway 05 / 23
 length922m (3025ft)
 bearing56° / 236°
 width15m (49ft)
 surfaceasphalt

Airport layout


Taxiway locations

 D  D1  E  F  G  G1  H
Parking locations

 Heli  Mil  RS

Nearby beacons

codeidentifierdistbearingfrequency
ERZERZURUM NDB0.983°354

Departure and arrival routes

Transition altitude15000ft
SID end pointsdistanceoutbound heading
RW08 (ALL)
 VIRA1L26mi72°
 ALVA1L26mi86°
 TAVU1L26mi99°
 SUSU1L25mi123°
 TURN1L25mi157°
 GELI1L24mi237°
 DAMA1L24mi270°
 HOCA1L24mi308°
RW08L
 VIRA1Y26mi72°
 ALVA1Y26mi86°
 TAVU1Y26mi99°
 SUSU1Y25mi123°
 TURN1Y25mi157°
 GELI1Y24mi237°
 DAMA1Y24mi270°
 HOCA1Y24mi308°
RW26 (ALL)
 VIRA1H26mi72°
 ALVA1H26mi86°
 TAVU1H26mi99°
 SUSU1H25mi123°
 TURN1H25mi157°
 GELI1H24mi237°
 DAMA1H24mi270°
 HOCA1H24mi308°
RW26R
 VIRA1K26mi72°
 ALVA1K26mi86°
 TAVU1K26mi99°
 SUSU1K25mi123°
 TURN1K25mi157°
 GELI1K24mi237°
 DAMA1K24mi270°
 HOCA1K24mi308°

STAR starting pointsdistanceinbound heading
RW08 (ALL)
 GELI1D24.057°
 DAMA1D24.090°
 HOCA1D24.3128°
 VIRA1D25.6252°
 ALVA1D25.7266°
 TAVU1D25.7279°
 SUSU1D25.4303°
 TURN1D25.0337°
RW08L
 GELI1T24.057°
 DAMA1T24.090°
 HOCA1T24.3128°
 VIRA1T25.6252°
 ALVA1T25.7266°
 TAVU1T25.7279°
 SUSU1T25.4303°
 TURN1T25.0337°
RW26 (ALL)
 GELI1E24.057°
 DAMA1E24.090°
 HOCA1E24.3128°
 VIRA1E25.6252°
 ALVA1E25.7266°
 TAVU1E25.7279°
 SUSU1E25.4303°
 TURN1E25.0337°
RW26R
 GELI1J24.057°
 DAMA1J24.090°
 HOCA1J24.3128°
 VIRA1J25.6252°
 ALVA1J25.7266°
 TAVU1J25.7279°
 SUSU1J25.4303°
 TURN1J25.0337°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ALVA1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
ALVA1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
DAMA1DDAMATVHFleft264 (84)°> 12000ft1.0min timedICAO rules
DAMA1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
DAMA1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
GELI1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
GELI1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
GELI1JGELINVHFleft186 (6)°> 12000ft1.0min timedICAO rules
GELI1TGELINVHFleft186 (6)°> 12000ft1.0min timedICAO rules
HOCA1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
HOCA1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
SUSU1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
SUSU1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
TAVU1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
TAVU1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
TURN1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
TURN1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
VIRA1DERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
VIRA1EERZNDBright83 (263)°> 13000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
