Airports for X-Plane

La Isabela - La Isabela Intl

Airport details

CountryDominican Republic
StateSanto Domingo
RegionMD
AirspaceSanto Domingo Ctr
MunicipalitySanto Domingo Norte
Elevation98ft (30m)
TimezoneGMT -4
Coordinates18.57920, -69.97909
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeMDJB
IATA codeJBQ
FAA coden/a

Communication

La Isabela Intl HIGUERO Tower121.700

Runway info

Runway 01 / 19
 length1660m (5446ft)
 bearing7° / 187°
 width31m (102ft)
 surfaceasphalt
 blast zone32m (105ft) / 34m (112ft)

Airport layout


Taxiway locations

 A  B  C  D
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
DHGHIGUERO VOR/DME0.5209°116.60
HIJSAN ISIDRO NDB12.7107°220
SISSAN ISIDRO VOR/DME12.9110°112.40
LASGUERRA NDB14.490°200
CDOPUNTA CAUCEDO (SANTO DOMI VOR/DME19.7115°114.70
DCYEL CATEY (SAMANA) VOR/DME43.619°115.80
SGOSANTIAGO VOR/DME61323°114.90

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW01AIDAS (24°)AIDAS
JB122 (5mi, 68°) 2500ft
RW01ELSYS (341°)ELSYS
JB122 (5mi, 286°) 2500ft
 RNAVJB122 2500ft
SOTOS (5mi, 357°) 1700ft
MDJB (6mi, 11°) 90ft
JB124 (turn)
JB125 (8mi, 97°) 3000ft
JB126 (6mi, 180°) 3000ft
ELSYS (7mi, 215°) 3000ft
ELSYS (turn) 3000ft
RW19EUDIS (209°)EUDIS
JB112 (5mi, 258°) 2500ft
RW19KODIX (164°)KODIX
JB111 (16mi, 164°) 5000ft
LOTFI (6mi, 164°) 3000ft
JB112 (5mi, 116°) 2500ft
 RNAVJB112 2500ft
MAYTE (5mi, 187°) 1700ft
MDJB (5mi, 184°) 131ft
JB114 (turn)
EUDIS (14mi, 28°) 3000ft
EUDIS (turn) 3000ft
