Airports for X-Plane

Cozumel - Cozumel Intl

Airport details

CountryMexico
StateQuintana Roo
RegionMM
AirspaceMerida Ctr
MunicipalitySan Miguel de Cozumel
Elevation15ft (5m)
TimezoneGMT -5
Coordinates20.52269, -86.93699
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeMMCZ
IATA codeCZM
FAA coden/a

Communication

Cozumel Intl Tower118.000
Cozumel Intl CANCUN Approach124.700
Cozumel Intl CANCUN Departure124.200

Runway info

Runway 05 / 23
 length3167m (10390ft)
 bearing57° / 237°
 width45m (148ft)
 surfaceasphalt
 displ threshold595m (1952ft) / 145m (476ft)
Runway 12 / 30
 length2702m (8865ft)
 bearing114° / 294°
 width45m (148ft)
 surfaceasphalt
 displ threshold198m (650ft) / 0m (0ft)
 blast zone0m (0ft) / 60m (197ft)

Airport layout - parking location South


Taxiway locations

 A  B  C  D  E  F
Parking locations

 1  10  11  12  13  14  15  2
 3  4  5  6  7  8  9  East
 South

Nearby beacons

codeidentifierdistbearingfrequency
CZMCOZUMEL VOR/DME1.6121°112.50
CUNCANCUN VOR/DME30.49°113.60
NCPNICHUPTE VOR/DME31.39°114.50

Departure and arrival routes

Transition altitude18500ft
Transition level19500ft
SID end pointsdistanceoutbound heading
RW12
 NOSU1C80mi0°
 ROTG1C81mi11°
 NUKA1C89mi51°
 BOTO2F24mi54°
 NUDA1C86mi61°
 AVSE1B41mi102°
 GOSUL227mi102°
 ITAKU227mi147°
 SIGM1A63mi148°
 OBTA1D, OBTA2A26mi176°
 ITPI1C, ITPI2A26mi188°
 DAXU2A, DAXU1C25mi202°
 OTED2A25mi212°
 PAUL1C50mi214°
 AVSI1A49mi259°
 XOSI1A48mi274°
RW30
 NOSU1D80mi0°
 ROTG1D81mi11°
 LIDE2E15mi12°
 NUKA1D89mi51°
 NUDA1D86mi61°
 AVSE1C41mi102°
 SIGM1B63mi148°
 OBTA2B, OBTA1C26mi176°
 ITPI2B, ITPI1D26mi188°
 DAXU1D, DAXU2B25mi202°
 OTED2B25mi212°
 PAUL1D50mi214°
 OKUVA224mi257°
 AVSI1B49mi259°
 DUPIX223mi273°
 XOSI1B48mi274°
 VOBE2E30mi326°

STAR starting pointsdistanceinbound heading
RW12
 PAUL1E50.134°
 AVSI1C48.779°
 VIGT1A68.6145°
 EMOS1A97.0218°
 ILUB1C92.0282°
 SIGM1C63.1328°
RW30
 PAUL1F50.134°
 AVSI1D48.779°
 VIGT1B68.6145°
 EMOS1B97.0218°
 ILUB1D92.0282°
 SIGM1D63.1328°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12ONGAV (88°)ONGAV 4000ft
CZ519 (5mi, 27°) 2500ft
RW12VIBLA (140°)VIBLA 4000ft
CZ519 (5mi, 207°) 2500ft
RW12XUBLI (114°)XUBLI 4000ft
CZ519 (5mi, 114°) 2500ft
 RNAVCZ519 2500ft
CALHO (5mi, 114°) 1600ft
MMCZ (5mi, 112°) 60ft
CZ403 (5mi, 117°)
DURGA (28mi, 131°) 4000ft
DURGA (turn) 4000ft
RW30BEREB (319°)BEREB 4000ft
CZ705 (5mi, 27°) 2500ft
RW30EMPAM (295°)EMPAM 4000ft
CZ705 (5mi, 294°) 2500ft
 RNAVCZ705 2500ft
CZ706 (5mi, 294°) 1600ft
MMCZ (6mi, 296°) 65ft
CZ600 (2mi, 288°)
EBLOD (32mi, 143°) 4000ft
EBLOD (turn) 4000ft
