Country | Haiti |
State | Département du Nord |
Region | MT |
Airspace | Port-au-prince Ctr |
Municipality | Commune Cap-Haïtien |
Elevation | 6ft (2m) |
Timezone | GMT -5 |
Coordinates | 19.73266, -72.19481 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | MTCH |
IATA code | CAP |
FAA code | n/a |
Cap Haitien Intl Tower | 118.700 |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
HCN | CAP HAITIEN VOR/DME | 1.3 | 221° | 113.90 |
Transition altitude | 17000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW05 | |||
RETA1N | 40mi | 47° | |
SEDE1N | 35mi | 184° | |
SAVA1N | 45mi | 212° | |
MEDO1N | 46mi | 273° | |
NOSO1N | 34mi | 310° | |
ALBE1N | 41mi | 355° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW05 | |||
SEDE1N | 34.5 | 4° | |
SAVA1N | 44.9 | 32° | |
MEDO1N | 46.1 | 93° | |
NOSO1F, NOSO1L, NOSO1N | 33.7 | 130° | |
TUMA1N, TUMA1L | 37.1 | 211° | |
RW23 | |||
SEDE1S | 34.5 | 4° | |
SAVA1S | 44.9 | 32° | |
MEDO1S | 46.1 | 93° | |
NOSO1S | 33.7 | 130° | |
TUMA1S | 37.1 | 211° | |
RETA1S | 39.7 | 227° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW05-Y | FOSET (127°) | FOSET 3400ft CH606 (6mi, 133°) CH604 (4mi, 149°) |
RW05-Y | LACUL (139°) | LACUL 3400ft CH604 (10mi, 164°) |
RNAV | CH604 3200ft CH603 (5mi, 164°) 3200ft CH602 (2mi, 164°) CH601 (4mi, 102°) MTCH (4mi, 41°) 64ft CH612 (2mi, 41°) CH614 (5mi, 10°) CH616 (11mi, 338°) LACUL (10mi, 253°) 3400ft LACUL (turn) | |
RW05-Z | CH412 (13°) | CH412 DALCY (5mi, 333°) 6500ft CH406 (9mi, 333°) 5100ft |
RW05-Z | PBORO (61°) | PBORO 5400ft CH406 (7mi, 128°) 5100ft |
RNAV | CH406 5100ft CH408 (5mi, 41°) 4600ft MTCH (14mi, 41°) 64ft CH409 (3mi, 55°) CH410 (11mi, 137°) CH411 (16mi, 199°) CH412 (12mi, 245°) DALCY (5mi, 333°) 6500ft DALCY (turn) 6500ft | |
RW23 | HOCAP (201°) | HOCAP 2500ft PODPE (5mi, 128°) 2500ft |
RW23 | PODPE (221°) | PODPE 2500ft |
RW23 | ZAMMI (241°) | ZAMMI 2500ft PODPE (5mi, 308°) 2500ft |
RNAV | PODPE 2500ft CH508 (6mi, 221°) 2500ft MTCH (8mi, 221°) 60ft CH524 (8mi, 116°) CH525 (17mi, 36°) CH526 (6mi, 308°) PODPE (5mi, 221°) 2500ft PODPE (turn) |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
MEDO1N | PBORO | VHF | left | 319 (139)° | > 5400ft | 1.0min timed | 220 |
NOSO1L | LACUL | VHF | left | 355 (175)° | > 3400ft | 1.0min timed | 220 |
NOSO1N | PBORO | VHF | left | 319 (139)° | > 5400ft | 1.0min timed | 220 |
RETA1S | PODPE | VHF | left | 49 (229)° | > 2500ft | 1.0min timed | 230 |
SAVA1N | DALCY | VHF | right | 164 (344)° | > 6500ft | 1.0min timed | 220 |
SEDE1N | DALCY | VHF | right | 164 (344)° | > 6500ft | 1.0min timed | 220 |
TUMA1L | LACUL | VHF | left | 355 (175)° | > 3400ft | 1.0min timed | 220 |
TUMA1N | PBORO | VHF | left | 319 (139)° | > 5400ft | 1.0min timed | 220 |
TUMA1S | PODPE | VHF | left | 49 (229)° | > 2500ft | 1.0min timed | 230 |
*) magnetic outbound (inbound) holding course |
