Country | Syrian Arab Republic |
State | Rif Dimashq Governorate |
Region | OS |
Airspace | Damascus Ctr |
Municipality | Harran Al-Awamid Sudsitrict |
Elevation | 2020ft (616m) |
Timezone | GMT +2 |
Coordinates | 33.41072, 36.51333 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | OSDI |
IATA code | DAM |
FAA code | n/a |
Damascus Intl ATIS | 128.225 |
Damascus Intl Tower | 121.900 |
Damascus Intl Tower | 118.075 |
Damascus Intl Approach | 121.300 |
Damascus Intl Approach | 120.000 |
ILS-cat-II | RW05R | 111.1 | 18.00mi |
ILS-cat-II | RW23R | 109.9 | 18.00mi |
3° GS | RW05R | 111.1 | 18.00mi |
3° GS | RW23R | 109.9 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
DAM | DAMASCUS VOR/DME | 3.5 | 224° | 116 |
ABD | ABYAD (DAMASCUS) NDB | 6.2 | 228° | 264 |
DAL | DAMASCUS NDB | 6.3 | 49° | 342 |
MEZ | MEZZEH (DAMASCUS) NDB | 15 | 285° | 358 |
BAR | BAYSUR VOR | 52.5 | 291° | 113.90 |
ROP | ROSH-PINA VOR/DME | 53.8 | 246° | 115.30 |
KTN | KARIATAIN NDB | 60.7 | 41° | 372 |
KTN | KARIATAIN VOR/DME | 61 | 43° | 117.70 |
CAK | CHEKA VOR/DME | 67 | 318° | 116.20 |
Transition altitude | 13000ft |
Transition level | 15000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW05L | |||
LEB2 | 51mi | 5° | |
TAN22, TAN21 | 107mi | 88° | |
SLF22, SLF21 | 83mi | 88° | |
ABS22, ABS21 | 61mi | 89° | |
BUS2 | 65mi | 175° | |
RW05R | |||
LEB2 | 51mi | 5° | |
SLF22, SLF21 | 83mi | 88° | |
TAN22, TAN21 | 107mi | 88° | |
ABS22, ABS21 | 61mi | 89° | |
BUS2 | 65mi | 175° | |
RW23 (ALL) | |||
LEB1 | 51mi | 5° | |
SLF1, SLF2 | 83mi | 88° | |
TAN1, TAN2 | 107mi | 88° | |
ABS1, ABS2 | 61mi | 89° | |
BUS1 | 65mi | 175° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
LIMA1C | 51.4 | 185° | |
TANG1C | 107.3 | 268° | |
SIER1C | 94.6 | 278° | |
BRAV1C | 64.9 | 355° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW23R | SOFIA (275°) | SOFIA SD523 (5mi, 319°) 5000ft SD524 (7mi, 309°) 4000ft SD525 (4mi, 233°) 3600ft |
RNAV | SD525 3600ft OSDI (7mi, 229°) 2045ft (2875mi, 228°) 2420ft SD526 (2871mi, 48°) 5000ft SD526 (turn) |
