Odate - Odate Noshiro
Airport details
| Country | Japan |
| State | Akita Prefecture |
| Region | RJ |
| Airspace | Fukuoka Ctr |
| Municipality | Kitaakita |
| Elevation | 291ft (89m) |
| Timezone | GMT +9 |
| Coordinates | 40.19194, 140.37167 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | RJSR |
| IATA code | ONJ |
| FAA code | n/a |
Communication
| Odate Noshiro Odate Remote | 118.750 |
| Odate Noshiro Sapporo Control | 120.575 |
| Odate Noshiro Sapporo Control | 127.575 |
Approach frequencies
| ILS-cat-I | RW11 | 110.15 | 18.00mi |
| 3° GS | RW11 | 110.15 | 18.00mi |
Nearby Points of Interest:
Horikoshi Castle
-Ōmori Katsuyama Site
-Nakachō
-Nakamachi Komise Street
-Akita Kantō
-Akita City Akarenga-kan Museum
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| ODE | ODATE VOR/DME | 0.5 | 303° | 114.75 |
| UWE | YUWA (AKITA) VOR/DME | 35.5 | 198° | 110.65 |
| MRE | AOMORI VOR/DME | 36.2 | 31° | 114.10 |
| HPE | HANAMAKI VOR/DME | 57.5 | 135° | 112.80 |
Departure and arrival routes
| Transition altitude | 14000ft |
| Transition level | 14000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW11 | |||
| LAGON3 | 36mi | 198° | |
| RW29 | |||
| LAGON3 | 36mi | 198° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW29 | |||
| NOSSY | 12.7 | 20° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW29-Y | NOSSY (98°) | NOSSY 4000ft SR950 (15mi, 81°) 3500ft |
| RNAV | SR950 3500ft SR951 (4mi, 118°) 3500ft SR952 (5mi, 234°) 1694ft RJSR (5mi, 278°) 342ft NOSSY (10mi, 278°) 4000ft NOSSY (turn) | |
| RW29-Z | MAGGY (10°) | MAGGY 6000ft SR960 (9mi, 33°) 3900ft |
| RNAV | SR960 3900ft SR961 (2mi, 33°) 3500ft SR962 (4mi, 33°) 2296ft SR963 (3mi, 327°) 1031ft RJSR (3mi, 278°) 342ft NOSSY (10mi, 278°) 4000ft NOSSY (turn) |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| NOSSY | BONJI | VHF | left | 202 (22)° | > 6000ft | DME 6.0mi | 230 |
| *) magnetic outbound (inbound) holding course | |||||||
