Airports for X-Plane

[ (cagayan De Oro) - Laguindingan Airport

Airport details

CountryPhilippines
StateMisamis Oriental
RegionRP
AirspaceManila Ctr
MunicipalityEl Salvador
Elevation189ft (58m)
TimezoneGMT +8
Coordinates8.61220, 124.45650
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeRPMY
IATA codeCGY
FAA coden/a

Communication

Laguindingan Airport Laguindingan Tower118.600

Approach frequencies

ILS-cat-IRW27111.318.00mi
3° GSRW27111.318.00mi

Runway info

Runway 09 / 27
 length2096m (6877ft)
 bearing86° / 266°
 width45m (148ft)
 surfaceconcrete
 blast zone60m (197ft) / 60m (197ft)

Airport layout - taxiway location C


Taxiway locations

 B  C
Parking locations

 1  2  3  4  5  GA1  GA2  GA3
 GA4  GA5

Nearby beacons

codeidentifierdistbearingfrequency
LGDLAGUINDINGAN VOR/DME0.2288°116.10
OZOZAMIS NDB45.4235°267
BHLPANGLAO VOR/DME70.6324°116.20

Departure and arrival routes

Transition altitude11000ft
Transition level13000ft
SID end pointsdistanceoutbound heading
RW09
 ANKI5A49mi141°
 NADU5A41mi159°
 MAUR5A39mi179°
 SIKI5A33mi318°
 LIRY5A28mi334°
RW27
 ANKI7A49mi141°
 NADU7A41mi159°
 MAUR7A39mi179°
 SIKI7A33mi318°
 LIRY7A28mi334°

STAR starting pointsdistanceinbound heading
RW09
 SIKI4A33.4138°
 SAGO4A24.9174°
 ANKI4A49.3321°
 NADU4A41.3339°
 MAUR4A38.6359°
RW27
 SIKI6A, SIK2C33.4138°
 SGL2C, SAGO6A24.9174°
 GON2C37.3295°
 ANKI6A, ANK2C49.3321°
 NAD2C, NADU6A41.3339°
 MAUR6A, MAU2C38.6359°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09JONAS (113°)JONAS 3300ft
MY09A (6mi, 176°) 1900ft
RW09REBBY (57°)REBBY 3900ft
MY09A (8mi, 16°) 1900ft
 RNAVMY09A 1900ft
MY09B (6mi, 86°) 1900ft
RPMY (6mi, 86°) 239ft
(7448mi, 266°) 1000ft
GARED (7447mi, 86°)
JONAS (13mi, 246°) 3300ft
JONAS (turn)
RW27LALAH (294°)LALAH 3900ft
MY27A (6mi, 356°) 1900ft
RW27MATTE (235°)MATTE 3400ft
MY27A (7mi, 176°) 1900ft
 RNAVMY27A 1900ft
MY27B (5mi, 266°) 1900ft
RPMY (6mi, 266°) 239ft
(7448mi, 266°) 1000ft
OLGAR (7447mi, 86°)
MATTE (10mi, 96°) 3400ft
MATTE (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ANKI4AREBBYVHFleft196 (16)°3900ft - 13000ft1.0min timed230
ANKI6ALALAHVHFleft176 (356)°3900ft - 8000ft1.0min timed230
MAUR4AREBBYVHFleft196 (16)°3900ft - 13000ft1.0min timed230
MAUR6ALALAHVHFleft176 (356)°3900ft - 8000ft1.0min timed230
NADU4AREBBYVHFleft196 (16)°3900ft - 13000ft1.0min timed230
NADU6ALALAHVHFleft176 (356)°3900ft - 8000ft1.0min timed230
SAGO4AJONASVHFright356 (176)°3300ft - 13000ft1.0min timed230
SAGO4ASAGOLVHFleft342 (162)°13000ft - 19000ft1.5min timed250
SAGO6AMATTEVHFright324 (144)°3400ft - 13000ft1.0min timed230
SAGO6ASAGOLVHFleft342 (162)°13000ft - 19000ft1.5min timed250
SIKI4AJONASVHFright356 (176)°3300ft - 13000ft1.0min timed230
SIKI6AMATTEVHFright324 (144)°3400ft - 13000ft1.0min timed230
*) magnetic outbound (inbound) holding course
