Airports for X-Plane

Rawson - Almirante Zar

Airport details

CountryArgentina
StateChubut Province
RegionSA
AirspaceComodoro Rivadavia Ctr
MunicipalityTrelew
Elevation141ft (43m)
TimezoneGMT -3
Coordinates-43.21056, -65.27028
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSAVT
IATA codeREL
FAA coden/a

Communication

Almirante Zar Tower/Approach120.650
Almirante Zar Tower/Approach118.700

Approach frequencies

ILS-cat-IRW25109.518.00mi
3° GSRW25109.518.00mi
Nearby Points of Interest:
Trelew train station
-
Capel Seion

Runway info

Runway 07 / 25
 length2551m (8369ft)
 bearing74° / 254°
 width45m (147ft)
 surfaceasphalt
 blast zone61m (200ft) / 61m (200ft)

Airport layout - taxiway location E


Taxiway locations

 07  25  A  A1  A2  A3  AEROPUERTO  B
 B1  BASE|AERON  C  E  F
Parking locations

 Gate  Mil  New

Nearby beacons

codeidentifierdistbearingfrequency
TRETRELEW VOR/DME1.171°115.10
TTRELEW NDB1.574°280
DRYMADRYN (PUERTO MADRYN) VOR/DME2821°116.10
YEL TEHUELCHE (PUERTO MADRYN) NDB29.123°300

Departure and arrival routes

Transition altitude3000ft
SID end pointsdistanceoutbound heading
RW07
 ORAM2K57mi10°
 LOMU1K156mi35°
 OPSI1K55mi190°
 GATU2K54mi218°
 EKAT2K54mi272°
 SILA2K54mi288°
RW25
 ORAM2C57mi10°
 LOMU1C156mi35°
 OPSI1C55mi190°
 GATU2C54mi218°
 EKAT2C54mi272°
 SILA2C54mi288°

STAR starting pointsdistanceinbound heading
RW07
 OPSI1U55.010°
 GATU2U54.138°
 EKAT2U54.092°
 SILA2U54.3108°
 ORAM2U56.6190°
 LOMU1U155.6215°
 KIGI2U143.2224°
RW25
 OPSI1Q55.010°
 GATU2Q54.138°
 EKAT2Q54.092°
 SILA2Q54.3108°
 ORAM2Q56.6190°
 LOMU1Q155.6215°
 KIGI2Q143.2224°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW07KAKOG (75°)KAKOG 3000ft
GUVUM (5mi, 75°) 1800ft
RW07ROKAB (93°)ROKAB 3000ft
GUVUM (5mi, 153°) 1800ft
RW07VURPI (53°)VURPI 3000ft
GUVUM (5mi, 333°) 1800ft
 RNAVGUVUM 1800ft
MAMGO (5mi, 75°) 1760ft
SAVT (6mi, 75°) 164ft
VT620 (4mi, 74°)
ROKAB (16mi, 268°) 3000ft
ROKAB (turn) 3000ft
RW25BOBIM (254°)BOBIM 3000ft
GILNA (5mi, 254°) 1760ft
RW25MATMU (273°)MATMU 3000ft
GILNA (5mi, 332°) 1760ft
RW25PUMUG (233°)PUMUG 3000ft
GILNA (5mi, 152°) 1760ft
 RNAVGILNA 1760ft
VULEB (5mi, 254°) 1760ft
SAVT (6mi, 254°) 160ft
VT610 (2mi, 255°)
MATMU (14mi, 90°) 3000ft
MATMU (turn) 3000ft
