Rio De Janeiro - Campo Delio Jardim De Mattos
Airport details
| Country | Brazil |
| State | Rio de Janeiro |
| Region | SB |
| Airspace | Curitiba Ctr |
| Elevation | 106ft (32m) |
| Timezone | GMT -3 |
| Coordinates | -22.87556, -43.38445 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | SBAF |
| IATA code | n/a |
| FAA code | n/a |
Communication
| Campo Delio Jardim de Mattos AFONSOS | 121.850 |
| Campo Delio Jardim de Mattos AFONSOS Tower | 118.900 |
| Campo Delio Jardim de Mattos RIO Approach | 119.350 |
Nearby Points of Interest:
Colônia Juliano Moreira
-Fazenda do Engenho d’ Água
-House of the Viegas Estate
-Fortim de Caetano Madeira
-Pedregulho Housing Complex
-Maracanã Village
-Casa da Marquesa de Santos
-Fazenda de São Bento
-Bishop’s House
-Chapel of Our Lady of Cabeça
-Morro Dois Irmãos
-Hospital da Lagoa (building)
-Carioca River
-Palácio Duque de Caxias
-Palace of Itamaraty
-Pedra do Sal
-Lagoa Rodrigo de Freitas
-Fortaleza de Nossa Senhora da Conceição
-Palácio Episcopal (Rio de Janeiro)
-Palacete Modesto Leal
-Casa Cavé
-Santa Teresa Tram
-Avenida Rio Branco
-Automóvel Clube do Brasil
-Clube Naval
Runway info
| Runway 08 / 26 | ||
| length | 1992m (6535ft) | |
| bearing | 63° / 243° | |
| width | 52m (171ft) | |
| surface | concrete | |
| blast zone | 24m (79ft) / 0m (0ft) | |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| CAX | CAXIAS (RIO DE JANEIRO) NDB | 7.2 | 23° | 400 |
| CXI | GALEAO (RIO DE JANEIRO) VOR/DME | 7.7 | 65° | 112.30 |
| NOA | NOVA (RIO DE JANEIRO TMA) NDB | 10.8 | 329° | 215 |
| PP | PAIOL (RIO DE JANEIRO) NDB | 12.1 | 89° | 415 |
| YLA | ILHA (RIO DE JANEIRO) NDB | 13.1 | 68° | 330 |
| IH | RASA (RIO DE JANEIRO TMA) NDB | 17.3 | 128° | 315 |
| SCR | SANTA CRUZ (RIO) VOR/DME | 19.4 | 258° | 113.60 |
| MIA | MARICA VOR/DME | 27.8 | 101° | 114.80 |
| PCX | PORTO (RIO DE JANEIRO TMA VOR/DME | 30.7 | 73° | 114.60 |
| PAI | PIRAI VOR/DME | 35.7 | 313° | 115 |
Departure and arrival routes
| Transition altitude | 7000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW08 | |||
| PUMS1A | 133mi | 43° | |
| NEPO1A | 47mi | 278° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RWNVA | EGDUT (120°) | EGDUT 6300ft RJ001 (5mi, 68°) 4700ft EGBAT (4mi, 68°) 3300ft |
| RWNVA | UTBOM (150°) | UTBOM 6300ft DOOPK (3mi, 124°) 5000ft EGBAT (5mi, 124°) 3300ft |
| RNAV | EGBAT 3300ft AF002 (6mi, 126°) 1500ft AF003 (3mi, 203°) 760ft AF004 (9mi, 252°) DONGI (5mi, 258°) SCR (9mi, 246°) 5100ft SCR (turn) 5100ft | |
| RWNVB | AF012 (71°) | AF012 6000ft AF006 (5mi, 352°) 4500ft |
| RWNVB | AF013 (88°) | AF013 6000ft AF006 (5mi, 83°) 4500ft |
| RWNVB | AF014 (108°) | AF014 6000ft AF006 (5mi, 172°) 4500ft |
| RNAV | AF006 4500ft AF007 (5mi, 83°) 2900ft AF009 (5mi, 97°) 1310ft (2884mi, 62°) 2100ft AF011 (2885mi, 242°) 3600ft AF012 (11mi, 280°) 6000ft AF012 (turn) 6000ft |
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
