Campo Grande
Airport details
| Country | Brazil |
| State | Mato Grosso do Sul |
| Region | SB |
| Airspace | Curitiba Ctr |
| Municipality | Campo Grande |
| Elevation | 1833ft (559m) |
| Timezone | GMT -4 |
| Coordinates | -20.46712, -54.66751 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | SBCG |
| IATA code | CGR |
| FAA code | n/a |
Communication
| Campo Grande Ground Control | 121.900 |
| Campo Grande Tower | 118.100 |
| Campo Grande Approach | 120.200 |
Approach frequencies
| ILS-cat-I | RW06 | 110.3 | 18.00mi |
| 3° GS | RW06 | 110.3 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| GRD | CAMPO GRANDE VOR/DME | 1.5 | 232° | 112.80 |
Departure and arrival routes
| Transition altitude | 5000ft |
| Transition level | 50ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW06 | |||
| UKEV1A | 76mi | 56° | |
| POTK1A | 71mi | 343° | |
| RW24 | |||
| MIDE1B | 76mi | 56° | |
| EPDA1B | 71mi | 343° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW06 | |||
| IRIP2A | 60.0 | 115° | |
| KOXA2A | 70.8 | 163° | |
| VURO2A | 75.8 | 236° | |
| DUNC2A | 89.3 | 310° | |
| RW24 | |||
| IRIP2B | 60.0 | 115° | |
| KOXA2B | 70.8 | 163° | |
| VURO2B | 75.8 | 236° | |
| DUNC2B | 89.3 | 310° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW06-Z | CG033 (45°) | CG033 5000ft CG032 (6mi, 44°) 4000ft |
| RW06-Z | CG034 (72°) | CG034 5000ft CG032 (6mi, 131°) 4000ft |
| RW06-Z | CG036 (15°) | CG036 5000ft CG032 (6mi, 311°) 4000ft |
| RNAV | CG032 4000ft CG031 (5mi, 44°) 3450ft SBCG (6mi, 45°) 1853ft OGMOG (15mi, 43°) 5000ft OGMOG (turn) 5000ft | |
| RW24-Y | CG029 (253°) | CG029 5000ft CG053 (6mi, 310°) 4000ft |
| RW24-Y | CG048 (192°) | CG048 5000ft CG053 (6mi, 131°) 4000ft |
| RW24-Y | CG057 (223°) | CG057 5000ft CG053 (6mi, 224°) 4000ft |
| RNAV | CG053 4000ft CG054 (5mi, 224°) 3480ft CG056 (3mi, 224°) 2520ft SBCG (2mi, 220°) 1884ft CG362 (11mi, 225°) 5000ft CG362 (turn) 5000ft |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| DUNC2A | CG042 | VHF | left | 139 (319)° | 1.0min timed | ICAO rules | |
| DUNC2B | CG042 | VHF | left | 139 (319)° | 1.0min timed | ICAO rules | |
| IRIP2A | CG046 | VHF | right | 313 (133)° | 1.0min timed | ICAO rules | |
| IRIP2B | CG046 | VHF | right | 313 (133)° | 1.0min timed | ICAO rules | |
| KOXA2A | CG049 | VHF | left | 2 (182)° | 1.0min timed | ICAO rules | |
| KOXA2B | CG049 | VHF | left | 2 (182)° | 1.0min timed | ICAO rules | |
| VURO2A | CG051 | VHF | right | 66 (246)° | 1.0min timed | ICAO rules | |
| VURO2B | CG051 | VHF | right | 66 (246)° | 1.0min timed | ICAO rules | |
| *) magnetic outbound (inbound) holding course | |||||||
