Airports for X-Plane

Guaratinguetá - Guaratingueta

Airport details

CountryBrazil
StateSão Paulo
RegionSB
AirspaceCuritiba Ctr
MunicipalityGuaratinguetá
Elevation1761ft (537m)
TimezoneGMT -3
Coordinates-22.79716, -45.20321
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSBGW
IATA codeGUJ
FAA coden/a

Communication

Guaratingueta GUARA Tower125.900
Guaratingueta GUARA Tower122.800
Guaratingueta GUARA Approach122.800
Nearby Points of Interest:
Casa Térrea à Rua Frei Galvão
-
Estação Ferroviária de Cachoeira Paulista
-
Palacete Palmeira
-
Sobrado do Capitão Silveira
-
Sobrado na Rua Nove de Julho, 136
-
Fazenda Pau d'Alho
-
Santa Casa de Misericórdia de Paraty

Runway info

Runway 02 / 20
 length1558m (5112ft)
 bearing359° / 179°
 width31m (102ft)
 surfaceasphalt

Airport layout - taxiway location A


Taxiway locations

 A  B  C  D
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
GGTGUARATINGUETA NDB0.8307°275
PNDVIBASA (PINDAMONHANGABA) NDB9.9241°205
TAUTAUBATE VOR/DME22.3232°112.60
TBETAUBATE NDB22.8232°430
SCPSAO JOSE (SAO JOSE DOS CA VOR/DME44.7236°115.40

Departure and arrival routes

Transition altitude7000ft
SID end pointsdistanceoutbound heading
RW02
 IMDA1A40mi125°
 GGT3B, SCP1B45mi236°
 OMNI46mi244°
RW20
 IMDA1B, IMDA1C40mi125°
 SCP1A, SCP1C45mi236°
 OMNI46mi244°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW20-AOPTOD (244°)OPTOD 7000ft
GW018 (5mi, 302°) 4700ft
 RNAVGW018 4700ft
GW019 (5mi, 242°) 3260ft
GW021 (3mi, 223°) 2400ft
(2970mi, 63°) 4000ft
OPTOD (2959mi, 243°) 7000ft
OPTOD (turn) 7000ft
RWNVBOPTOD (244°)OPTOD 7000ft
GW018 (5mi, 302°) 4700ft
 RNAVGW018 4700ft
GW019 (5mi, 242°) 3890ft
GW021 (3mi, 223°) 2940ft
GW022 (2mi, 223°) 2400ft
(2971mi, 63°) 4000ft
OPTOD (2959mi, 243°) 7000ft
OPTOD (turn) 7000ft
