Airports for X-Plane

Altamira

Airport details

CountryBrazil
StatePará
RegionSB
AirspaceAmazonica Ctr
MunicipalityAltamira
Elevation368ft (112m)
TimezoneGMT -3
Coordinates-3.25083, -52.25222
Magnetic var
Typeland
Available sinceX-Plane v10.32
ICAO codeSBHT
IATA codeATM
FAA coden/a

Communication

Altamira RDO125.850

Runway info

Runway 07 / 25
 length2006m (6581ft)
 bearing52° / 232°
 width33m (108ft)
 surfaceasphalt

Airport layout - taxiway location A


Taxiway locations

 A
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
ATMALTAMIRA VOR0.272°113.20
ATMALTAMIRA NDB0.3166°295

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW07HT007 (31°)HT007 4000ft
HT011 (5mi, 342°) 2200ft
RW07HT008 (52°)HT008 4000ft
HT011 (5mi, 52°) 2200ft
RW07HT009 (72°)HT009 4000ft
HT011 (5mi, 122°) 2200ft
 RNAVHT011 2200ft
HT012 (5mi, 52°) 2010ft
ATM02 (2mi, 52°) 1436ft
SBHT (4mi, 51°) 418ft
(3142mi, 86°) 2500ft
HT007 (3150mi, 266°) 4000ft
HT007 (turn) 4000ft
RW25HT001 (211°)HT001 4000ft
HT004 (5mi, 162°) 2200ft
RW25HT002 (232°)HT002 4000ft
HT004 (5mi, 232°) 2200ft
RW25HT003 (253°)HT003 4000ft
HT004 (5mi, 302°) 2200ft
 RNAVHT004 2200ft
HT006 (5mi, 232°) 2000ft
ATM01 (2mi, 232°) 1521ft
SBHT (4mi, 233°) 406ft
(3142mi, 86°) 2500ft
HT003 (3130mi, 266°) 4000ft
HT003 (turn) 4000ft
