Airports for X-Plane

Sao Roque - Sao Paulo Catarina Executivo

Airport details

CountryBrazil
StateSão Paulo
RegionSB
AirspaceCuritiba Ctr
MunicipalitySão Roque
Elevation2548ft (777m)
TimezoneGMT -3
Coordinates-23.42682, -47.16592
Magnetic var
Typeland
Available sinceX-Plane v11.50
ICAO codeSBJH
IATA coden/a
FAA coden/a

Communication

No airport communication available for SBJH
Nearby Points of Interest:
Mairinque station
-
Figueira Centenária
-
Serra do Japi
-
House at Sítio do Mandu
-
House at Sítio do Padre Inácio
-
Biblioteca Municipal Nelson Foot
-
Loja Maçônica Amor e Concórdia
-
Gabinete de Leitura Ruy Barbosa
-
Solar do Barão de Jundiaí
-
Complexo FEPASA
-
Jaraguá State Park
-
Brazilian Portland Cement
-
Perus train station
-
Juqueri Psychiatric Hospital
-
Franco da Rocha train station
-
Freguesia do Ó
-
Sertanista house
-
Tendal da Lapa
-
Edifício da Sociedade Beneficente União Fraterna
-
Casa da Fazenda do Morumbi
-
Monumento à Aldeia de Nossa Senhora dos Pinheiros
-
Chácara Tangará
-
Jockey Club de São Paulo
-
Antiga Sede da TV Tupi
-
Reservatório do Araçá

Runway info

Runway 12 / 30
 length2472m (8110ft)
 bearing94° / 274°
 width33m (108ft)
 surfaceasphalt
 displ threshold184m (604ft) / 0m (0ft)

Airport layout - parking location Ramp


Taxiway locations

 A
Parking locations

 Ramp

Nearby beacons

codeidentifierdistbearingfrequency
SCBSOROCABA (SAO PAULO TMA) VOR/DME12.6249°115.20
STNSANTANA (SAO PAULO TMA) VOR/DME13.8104°114.30
CPNCAMPINAS VOR/DME25.15°112
IKBENTO (CAMPINAS) NDB28.2355°370
CGOCONGONHAS (SAO PAULO) VOR/DME30.6111°116.90
EMBEMBUGUACU (SAO PAULO) NDB31.9140°525
IGTUCA (SAO PAULO) NDB32.793°410
DADDIADEMA (SAO PAULO) NDB35.3116°200
BCOBONSUCESSO (SAO PAULO) VOR/DME4389°116
BGCBRAGANCA (BRAGANCA PAULIS VOR/DME43.551°116.20
RDEREDE (SAO PAULO) VOR/DME44.8126°116.70
RCLRIO CLARO NDB63.7338°280

Departure and arrival routes

SID end pointsdistanceoutbound heading
RW12
 OMNI28mi207°
RW30
 OMNI28mi207°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12JH003 (94°)JH003 6000ft
JH002 (6mi, 94°) 4500ft
RW12JH004 (117°)JH004 6000ft
JH002 (5mi, 163°) 4500ft
 RNAVJH002 4500ft
JH001 (4mi, 94°) 3870ft
JH006 (2mi, 94°) 3234ft
SBJH (3mi, 94°) 2597ft
(3087mi, 64°) 3100ft
JH004 (3095mi, 244°) 6000ft
JH004 (turn) 6000ft
RW30-YJH019 (21°)JH019 6000ft
JH021 (5mi, 94°) 5000ft
JH022 (6mi, 45°) 4500ft
JH024 (2mi, 333°) 4100ft
 RNAVJH024 4100ft
JH026 (2mi, 295°) 3590ft
SBJH (4mi, 274°) 2564ft
JH016 (6mi, 274°)
JH017 (7mi, 310°) 6000ft
JH017 (turn) 6000ft
RW30-ZJH011 (33°)JH011 6000ft
JH012 (5mi, 94°) 4700ft
 RNAVJH012 4700ft
JH013 (5mi, 37°) 4160ft
JH014 (3mi, 302°) 3201ft
SBJH (3mi, 274°) 2564ft
JH016 (6mi, 274°)
JH017 (7mi, 310°)
JH017 (turn) 6000ft
