Maceió - Zumbi Dos Palmares

Airport details

CountryBrazil
StateAlagoas
RegionSB
AirspaceRecife Ctr
MunicipalityRio Largo
Elevation387ft (118m)
TimezoneGMT -3
Coordinates-9.51065, -35.79243
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSBMO
IATA codeMCZ
FAA coden/a

Communication

Zumbi Dos Palmares MACEIO Tower118.250
Zumbi Dos Palmares MACEIO Approach119.250

Approach frequencies

ILS-cat-IRW12109.718.00mi
3° GSRW12109.718.00mi

Runway info

Runway 12 / 30
 length2602m (8537ft)
 bearing101° / 281°
 width45m (148ft)
 surfaceasphalt
 displ threshold0m (0ft) / 113m (371ft)
 blast zone59m (194ft) / 76m (249ft)

Airport layout - taxiway location A


Taxiway locations

 A  B  C  D  E  F  G  H
 I
Parking locations

 GA  Hangar

Nearby beacons

codeidentifierdistbearingfrequency
MCEZUMBI (MACEIO) VOR/DME0.382°115.10

Departure and arrival routes

Transition altitude4000ft
SID end pointsdistanceoutbound heading
RW12
 ESBI1A, UKAR1C48mi32°
 DEND1C58mi221°
 IVSO1C40mi247°
 ENLU1C40mi337°
RW30
 UKAR1A, UKAR1B48mi32°
 KIMA1A60mi208°
 DEND1B, DEND1A58mi221°
 IVSO1A, IVSO1B40mi247°
 ENLU1B, ENLU1A40mi337°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12MO006 (101°)MO006 4000ft
MO004 (5mi, 101°) 2100ft
RW12MO007 (78°)MO007 4000ft
MO004 (6mi, 31°) 2100ft
RW12MO008 (123°)MO008 4000ft
MO004 (6mi, 171°) 2100ft
 RNAVMO004 2100ft
ROMOD (6mi, 101°) 2040ft
SBMO (6mi, 101°) 438ft
(2214mi, 75°) 2000ft
MO008 (2225mi, 255°) 4000ft
MO008 (turn) 4000ft
RW30MO013 (281°)MO013 4000ft
MO011 (6mi, 281°) 2500ft
RW30MO014 (304°)MO014 4000ft
MO011 (6mi, 351°) 2500ft
RW30MO016 (257°)MO016 4000ft
MO011 (6mi, 211°) 2500ft
 RNAVMO011 2500ft
MO009 (5mi, 281°) 2030ft
SBMO (6mi, 281°) 417ft
(2214mi, 75°) 2000ft
MO016 (2200mi, 255°) 4000ft
MO016 (turn) 4000ft
