Airports for X-Plane

Porto Velho - Porto Velho Intl

Airport details

CountryBrazil
StateRondônia
RegionSB
AirspaceAmazonica Ctr
MunicipalityPorto Velho
Elevation291ft (89m)
TimezoneGMT -4
Coordinates-8.71361, -63.90278
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSBPV
IATA codePVH
FAA coden/a

Communication

Porto Velho Intl Tower118.700
Porto Velho Intl Approach119.100

Approach frequencies

ILS-cat-IRW19109.318.00mi
3° GSRW19109.318.00mi

Runway info

Runway 01 / 19
 length2417m (7930ft)
 bearing357° / 177°
 width46m (151ft)
 surfaceasphalt

Airport layout


Taxiway locations

 A  B  C
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
PVHPORTO VELHO VOR/DME0239°112.70

Departure and arrival routes

Transition altitude3000ft
Transition level30ft
SID end pointsdistanceoutbound heading
RW01
 MUPE2A, MUPE3A33mi34°
 ISUR2A, ISUR3A40mi42°
 ANBU1A145mi112°
 PVH1A40mi112°
 ITAG2A40mi138°
 GUIM2A40mi214°
 OSAT2A39mi253°
 ANAM1A, ANAM1C40mi254°
 OGLA2A40mi305°
 NELI3A, NELI2A40mi340°
RW19
 MUPE1C33mi34°
 ISUR3B40mi42°
 KOGV3B40mi112°
 ILTA1B145mi112°
 ITAG3B, ITAG2B40mi138°
 DIKA3B, DIKA2B53mi142°
 ILSO2B, ILSO3B41mi154°
 GUIM3B, GUIM2B40mi214°
 OSAT2B39mi253°
 ANAM1B, ANAM1D40mi254°
 OGLA2B40mi305°
 NELI2B, PVH1B40mi340°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW01-YPV381 (356°)PV381 3000ft
PV369 (6mi, 357°) 2000ft
RW01-YPV382 (332°)PV382 3000ft
PV369 (6mi, 286°) 2000ft
RW01-YPV383 (21°)PV383 3000ft
PV369 (6mi, 67°) 2000ft
 RNAVPV369 2000ft
PV378 (5mi, 357°) 1930ft
PVH12 (3mi, 357°) 1037ft
SBPV (3mi, 356°) 337ft
(3857mi, 82°) 3000ft
(turn) 3000ft
RW01-ZPV381 (356°)PV381 3000ft
PV369 (6mi, 357°) 2000ft
RW01-ZPV382 (332°)PV382 3000ft
PV369 (6mi, 286°) 2000ft
RW01-ZPV383 (21°)PV383 3000ft
PV369 (6mi, 67°) 2000ft
 RNAVPV369 2000ft
PV378 (5mi, 357°) 1930ft
PVH12 (3mi, 357°) 1038ft
SBPV (3mi, 356°) 337ft
PV003 (17mi, 357°) 3000ft
PV003 (turn) 3000ft
RW19-YPV001 (148°)PV001 3000ft
ASBOS (6mi, 87°) 2000ft
RW19-YPV002 (206°)PV002 3000ft
ASBOS (6mi, 267°) 2000ft
RW19-YPV003 (177°)PV003 3000ft
ASBOS (6mi, 177°) 2000ft
 RNAVASBOS 2000ft
DETOK (5mi, 177°) 1930ft
PVH11 (3mi, 177°) 1024ft
SBPV (3mi, 177°) 337ft
(3857mi, 82°) 3000ft
(turn) 3000ft
RW19-ZPV001 (148°)PV001 3000ft
ASBOS (6mi, 87°) 2000ft
RW19-ZPV002 (206°)PV002 3000ft
ASBOS (6mi, 267°) 2000ft
RW19-ZPV003 (177°)PV003 3000ft
ASBOS (6mi, 177°) 2000ft
 RNAVASBOS 2000ft
DETOK (5mi, 177°) 1930ft
PVH11 (3mi, 177°) 1025ft
SBPV (3mi, 177°) 337ft
PV381 (16mi, 176°) 3000ft
PV381 (turn) 3000ft
