Country | Ecuador |
State | Galápagos |
Region | SE |
Airspace | Guayaquil Ctr |
Municipality | Cantón Santa Cruz |
Elevation | 207ft (63m) |
Timezone | GMT -6 |
Coordinates | -0.45389, -90.26583 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | SEGS |
IATA code | GPS |
FAA code | n/a |
Galapagos/Baltra - Seymour Baltra Tower | 122.200 |
Galapagos/Baltra - Seymour Galapagos Approach | 126.000 |
ILS-cat-I | RW14 | 110.9 | 18.00mi |
3° GS | RW14 | 110.9 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
GLV | GALAPAGOS (ISLA BALTRA) VOR/DME | 0.6 | 135° | 112.30 |
SCV | SAN CRISTOBAL VOR/DME | 47.3 | 125° | 113.10 |
IBL | ISABELA NDB | 50.8 | 235° | 246 |
Transition altitude | 4000ft |
Transition level | 4000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW14 | |||
EKOT2A, REDU2A, REDUS1 | 143mi | 88° | |
EKOTI1 | 80mi | 101° | |
SCV1 | 47mi | 125° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW14-Y | GS105 (305°) | GS105 8000ft GS101 (11mi, 296°) 5600ft GS266 (6mi, 301°) 4000ft GS264 (5mi, 301°) 3500ft |
RNAV | GS264 3500ft GEMDU (4mi, 42°) 1490ft SEGS (5mi, 143°) 195ft GS963 (1mi, 143°) GS965 (6mi, 58°) GS242 (5mi, 334°) 3000ft GS242 (turn) 3000ft | |
RW14-Z | GS105 (305°) | GS105 8000ft GS255 (9mi, 316°) 5000ft GS253 (11mi, 324°) 2800ft GS240 (1mi, 303°) 2500ft |
RW14-Z | GS224 (269°) | GS224 8000ft GS242 (27mi, 282°) 3000ft GS240 (5mi, 282°) 2500ft |
RNAV | GS240 2500ft GEMDU (4mi, 212°) 1490ft SEGS (5mi, 143°) 195ft GS963 (1mi, 143°) GS965 (6mi, 58°) GS242 (5mi, 334°) 3000ft GS242 (turn) 3000ft | |
RW32-Z | GS105 (305°) | GS105 3000ft GS103 (5mi, 296°) 2000ft GS101 (5mi, 296°) 1900ft |
RW32-Z | GS224 (269°) | GS224 8000ft GS222 (17mi, 257°) 3000ft GS220 (9mi, 257°) 1900ft GS101 (2mi, 277°) 1900ft |
RNAV | GS101 1900ft MIMAB (1mi, 310°) 1490ft SEGS (5mi, 324°) 257ft GS991 (2mi, 324°) GS993 (5mi, 29°) GS242 (3mi, 95°) 2983ft GS242 (turn) 3000ft |
