Manta - Manta - Eloy Alfaro
Airport details
| Country | Ecuador |
| State | Manabí |
| Region | SE |
| Airspace | Guayaquil Ctr |
| Municipality | Manta |
| Elevation | 45ft (14m) |
| Timezone | GMT -5 |
| Coordinates | -0.94611, -80.67889 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.32 |
| ICAO code | SEMT |
| IATA code | MEC |
| FAA code | n/a |
Communication
| Manta - Eloy Alfaro RDO | 126.900 |
| Manta - Eloy Alfaro Ground Control | 121.900 |
| Manta - Eloy Alfaro Tower | 118.700 |
| Manta - Eloy Alfaro Approach | 122.700 |
Approach frequencies
| ILS-cat-I | RW24 | 110.1 | 18.00mi |
| 3° GS | RW24 | 110.1 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| MNV | MANTA VOR/DME | 1.2 | 56° | 113.90 |
| MNT | MANTA NDB | 1.3 | 56° | 205 |
| PTN | PORTOVIEJO NDB | 13.6 | 114° | 390 |
| BCN | BAHIA (SAN VICENTE) NDB | 26.3 | 38° | 316 |
Departure and arrival routes
| Transition altitude | 4000ft |
| Transition level | 4000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW06 | |||
| ATOVI3, ATOV1B | 21mi | 30° | |
| ANLI1B, ANLIR3 | 21mi | 67° | |
| ANSEX3, ANSE1B | 21mi | 88° | |
| ASDE1B, ASDEL3 | 20mi | 143° | |
| BIXU1B, BIXUT3 | 19mi | 191° | |
| EGBO1B | 19mi | 272° | |
| KIKI1B, KIKIS3 | 20mi | 318° | |
| RW24 | |||
| ATOV3A, ATOV1C | 21mi | 30° | |
| ANLI1C, ANLI3A | 21mi | 67° | |
| ANSE1C, ANSE3A | 21mi | 88° | |
| ASDE3A, ASDE1C | 20mi | 143° | |
| BIXU1C, BIXU3A | 19mi | 191° | |
| EGBO1C | 19mi | 272° | |
| KIKI1C, KIKI3A | 20mi | 318° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW24 | |||
| ASBEX1 | 49.8 | 13° | |
| SIDIK1 | 56.8 | 91° | |
| MIBAR1 | 67.0 | 136° | |
| ORETA1 | 97.8 | 247° | |
| MUMIL1 | 49.4 | 269° | |
| RENAR1 | 45.9 | 325° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW24 | MT001 (210°) | MT001 3500ft MT004 (5mi, 146°) 2500ft |
| RW24 | MT002 (235°) | MT002 3500ft MT004 (5mi, 236°) 2500ft |
| RW24 | MT003 (261°) | MT003 3500ft MT004 (5mi, 326°) 2500ft |
| RNAV | MT004 2500ft MT005 (4mi, 236°) 1950ft SEMT (7mi, 235°) 98ft (4845mi, 89°) 1600ft MT001 (4839mi, 269°) 4000ft MT001 (turn) 4000ft |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| ASBEX1 | MT003 | VHF | right | 148 (328)° | > 4000ft | 1.0min timed | ICAO rules |
| MIBAR1 | MT001 | VHF | right | 328 (148)° | > 4000ft | 1.0min timed | ICAO rules |
| MUMIL1 | MT003 | VHF | right | 148 (328)° | > 4000ft | 1.0min timed | ICAO rules |
| ORETA1 | MT002 | VHF | right | 58 (238)° | > 4000ft | 1.0min timed | ICAO rules |
| RENAR1 | MT003 | VHF | right | 148 (328)° | > 4000ft | 1.0min timed | ICAO rules |
| SIDIK1 | MT001 | VHF | right | 328 (148)° | > 4000ft | 1.0min timed | ICAO rules |
| *) magnetic outbound (inbound) holding course | |||||||
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
