Country | Kazakhstan |
State | North Kazakhstan Region |
Region | UA |
Airspace | Nur-sultan Ctr |
Municipality | Қызылжар ауылдық округі |
Elevation | 458ft (140m) |
Timezone | GMT +6 |
Coordinates | 54.75555, 69.18611 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | UACP |
IATA code | PPK |
FAA code | n/a |
Petropavlovsk Intl ATC Tower | 123.700 |
Petropavlovsk Intl ATC App | 123.700 |
Petropavlovsk Intl ATC Dep | 123.700 |
ILS-cat-I | RW23 | 108.3 | 18.00mi |
3° GS | RW23 | 108.3 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
R | PETROPAVLOVSK NDB | 1.3 | 288° | 733 |
PSK | PETROPAVLOVSK VOR/DME | 2 | 49° | 112.50 |
Transition altitude | 10000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW05 | |||
BARK4D, BARK2F | 63mi | 87° | |
BEDM2F, BEDM4D | 64mi | 109° | |
TETK4D, TETK2F | 46mi | 164° | |
KOKA4D, KOKA2F | 59mi | 256° | |
IKAN4D, IKAN2F | 37mi | 283° | |
LETI2F, LETI4D | 35mi | 304° | |
RW23 | |||
BARK4B, BARK2E | 63mi | 87° | |
BEDM2E, BEDM4B | 64mi | 109° | |
TETK2E, TETK4B | 46mi | 164° | |
KOKA4B, KOKA2E | 59mi | 256° | |
IKAN2E, IKAN4B | 37mi | 283° | |
LETI2E, LETI5B | 35mi | 304° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW05 | |||
KOKA2G, KOKA3A | 58.8 | 76° | |
IKAN2G, IKAN3A | 36.8 | 103° | |
LETI3A, LETI2G | 34.9 | 124° | |
BARK2G, BARK3A | 63.1 | 267° | |
BEDM3A, BEDM2G | 64.0 | 289° | |
TETK2G, TETK3A | 45.7 | 344° | |
RW23 | |||
KOKA2H, KOKA3C | 58.8 | 76° | |
IKAN2H, IKAN3C | 36.8 | 103° | |
LETI2H, LETI3C | 34.9 | 124° | |
BARK3C, BARK2H | 63.1 | 267° | |
BEDM3C, BEDM2H | 64.0 | 289° | |
TETK2H, TETK3C | 45.7 | 344° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BARK2G | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
BARK2H | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
BARK3A | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
BARK3C | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
BEDM2G | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
BEDM2H | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
BEDM3A | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
BEDM3C | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
IKAN2G | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
IKAN2H | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
IKAN3A | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
IKAN3C | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
KOKA2G | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
KOKA2H | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
KOKA3A | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
KOKA3C | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
LETI2G | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
LETI2H | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
LETI3A | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
LETI3C | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
TETK2G | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
TETK2H | PSK | NDB | left | 53 (233)° | > 4000ft | 1.0min timed | ICAO rules |
TETK3A | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
TETK3C | R | NDB | left | 141 (321)° | > 4000ft | 1.0min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
