Airports for X-Plane

Kyzylorda

Airport details

CountryKazakhstan
StateKyzylorda Region
RegionUA
AirspaceShymkent Ctr
MunicipalityKyzylorda
Elevation433ft (132m)
TimezoneGMT +6
Coordinates44.70639, 65.59084
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeUAOO
IATA codeKZO
FAA coden/a

Communication

Kyzylorda Kyzylorda ATIS134.900
Kyzylorda Kyzylorda Tower120.900
Kyzylorda Kyzylorda Dep120.900

Approach frequencies

ILS-cat-IRW05111.118.00mi
3° GSRW05111.118.00mi

Runway info

Runway 05 / 23
 length2695m (8842ft)
 bearing69° / 249°
 width45m (148ft)
 surfaceasphalt
 blast zone120m (394ft) / 120m (394ft)

Airport layout - parking location 7


Taxiway locations

 A  B
Parking locations

 1  10  2  3  4  5  6  7
 8  9

Nearby beacons

codeidentifierdistbearingfrequency
OKYZYLORDA NDB1.269°985
KZOKYZYLORDA VOR/DME1.3249°112.70

Departure and arrival routes

Transition altitude2073ft
Transition level4000ft
SID end pointsdistanceoutbound heading
RW05
 AMRE5C43mi35°
 DIKA5C43mi95°
 RINE5C43mi102°
 GITI5C43mi116°
 ERME5C43mi124°
 DILN5C43mi239°
 BADA5C46mi251°
 NATU5C43mi279°
 AGMU5C43mi289°
RW23
 AMRE5D43mi35°
 DIKA5D43mi95°
 RINE5D43mi102°
 GITI5D43mi116°
 ERME5D43mi124°
 DILN5D43mi239°
 BADA5D46mi251°
 NATU5D43mi279°
 AGMU5D43mi289°

STAR starting pointsdistanceinbound heading
RW05
 DILN5A, DILN4F43.059°
 BADA4F, BADA5A46.371°
 NATU4F, NATU5A42.799°
 AGMU4F, AGMU5A42.7109°
 AMRE5A, AMRE4F43.2215°
 DIKA4F, DIKA5A43.4275°
 RINE5A, RINE4F43.4282°
 GITI5A, GITI4F43.4296°
 ERME5A, ERME4F43.4304°
RW23
 DILN5B, DILN4L43.059°
 BADA4L, BADA5B46.371°
 NATU4L, NATU5B42.799°
 AGMU5B, AGMU4L42.7109°
 AMRE4L, AMRE5B43.2215°
 DIKA4L, DIKA5B43.4275°
 RINE5B, RINE4L43.4282°
 GITI5B, GITI4L43.4296°
 ERME5B, ERME4L43.4304°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
AGMU4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
AGMU4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
AGMU5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
AGMU5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
AMRE4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
AMRE4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
AMRE5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
AMRE5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
BADA4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
BADA4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
BADA5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
BADA5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
DIKA4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
DIKA4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
DIKA5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
DIKA5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
DILN4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
DILN4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
DILN5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
DILN5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
ERME4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
ERME4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
ERME5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
ERME5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
GITI4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
GITI4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
GITI5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
GITI5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
NATU4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
NATU4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
NATU5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
NATU5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
RINE4FONDBright234 (54)°> 4000ft1.0min timedICAO rules
RINE4LONDBright234 (54)°> 4000ft1.0min timedICAO rules
RINE5AKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
RINE5BKZONDBright234 (54)°> 4000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
