Yerevan - Zvartnots Intl
Airport details
| Country | Armenia |
| State | Yerevan (capital district) |
| Region | UD |
| Airspace | Yerevan Ctr |
| Municipality | Yerevan |
| Elevation | 2836ft (864m) |
| Timezone | GMT +4 |
| Coordinates | 40.14733, 44.39583 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | UDYZ |
| IATA code | EVN |
| FAA code | n/a |
Communication
| Zvartnots Intl ATIS | 119.500 |
| Zvartnots Intl Ground Control | 119.000 |
| Zvartnots Intl Tower | 120.900 |
| Zvartnots Intl ApproachR | 126.000 |
Approach frequencies
| ILS-cat-II | RW09 | 108.1 | 18.00mi |
| 3° GS | RW09 | 108.1 | 18.00mi |
Nearby Points of Interest:
Saint Sargis church
-Karmir Blur
-Vahagn choking the dragons statue
-Bust of Vissarion Belinsky in Yerevan
-Cathedral and Churches of Echmiatsin and the Archaeological Site of Zvartnots
-Karen Demirchyan Complex
-Anoush and Saro
-Great Bridge of Hrazdan
-Statue of Komitas Vardapet in Etchmiadzin
-Dalma garden canal, Yerevan
-Mother See of Holy Etchmiadzin
-Armenian Genocide memorial, Etchmiadzin
-Shushanik Kurghinyan's grave
-Aghasi Khanjyan mansion
-Haghtanak bridge
-Vakhtang Ananyan's bust
-Red Bridge
-Yerevan Central Covered Market
-Hooshkaparik
-Bust of Vahan Teryan, Yerevan
-Statue The seller of water in Yerevan
-Yeghishe Charents bust
-Hripsime School for Girls
-Yeghishe Charents House-Museum
-Arakel Afrikyan's house
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| ZVR | ZVARTNOTS VOR/DME | 2.6 | 270° | 112.30 |
| Y | EREBUNI (YEREVAN) NDB | 3.5 | 128° | |
| YN | EREBUNI (YEREVAN) NDB | 3.8 | 140° | 580 |
| ER | EREBUNI (YEREVAN) NDB | 3.9 | 91° | 496 |
| FH | EREBUNI (YEREVAN) NDB | 5.2 | 189° | 465 |
| GDR | IGDIR NDB | 25.6 | 251° | 388 |
| AND | ANDRANIK NDB | 33.4 | 118° | |
| GM | SHIRAK (GYUMRI) NDB | 43 | 317° | 668 |
| MAK | MAKU VOR/DME | 62.8 | 150° | 112.40 |
Departure and arrival routes
| Transition altitude | 11500ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW09 | |||
| SEVA3H | 35mi | 55° | |
| GOSI4H | 30mi | 109° | |
| INDU3H | 34mi | 268° | |
| TIBL3H | 27mi | 295° | |
| RW27 | |||
| SEVA3E | 35mi | 55° | |
| GOSI3E | 30mi | 109° | |
| INDU3E | 34mi | 268° | |
| TIBL3E | 27mi | 295° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW09 | |||
| INDU3A | 33.6 | 88° | |
| TIBL3A | 27.1 | 115° | |
| SEVA3A | 34.5 | 235° | |
| GOSI3A | 29.6 | 289° | |
| RW27 | |||
| INDU3B | 33.6 | 88° | |
| TIBL3B | 27.1 | 115° | |
| SEVA3B | 34.5 | 235° | |
| GOSI3B | 29.6 | 289° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW09 | EREVA (90°) | EREVA 7000ft YZ420 (8mi, 240°) 5100ft YZ421 (4mi, 270°) 5100ft YZ400 (5mi, 359°) 5100ft |
| RW09 | OKUDA (90°) | OKUDA 7000ft YZ400 (4mi, 91°) 5100ft |
| RNAV | YZ400 5100ft ARMAV (4mi, 90°) 5100ft UDYZ (8mi, 90°) 2850ft YZ450 (2mi, 90°) 3400ft EREVA (3mi, 270°) 7000ft EREVA (turn) 7000ft | |
| RW27-Y | LUMIK (292°) | LUMIK 9200ft YZ007 (3mi, 1°) 8000ft YZ005 (3mi, 305°) 6800ft YZ001 (2mi, 305°) 5900ft |
| RNAV | YZ001 5900ft AGUGO (2mi, 287°) 5200ft UDYZ (7mi, 270°) 2888ft YZ505 (5mi, 270°) 3800ft LUMIK (19mi, 106°) 9200ft LUMIK (turn) 9200ft | |
| RW27-Z | LUMIK (292°) | LUMIK 9200ft YZ521 (5mi, 90°) 8000ft YZ520 (4mi, 360°) 8000ft YZ515 (4mi, 341°) 8000ft |
| RNAV | YZ515 8000ft BASRU (2mi, 270°) 7900ft UDYZ (14mi, 270°) 2888ft YZ505 (5mi, 270°) 4300ft LUMIK (19mi, 106°) 9200ft LUMIK (turn) 9200ft |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| GOSI3A | EREVA | VHF | left | 265 (85)° | > 7000ft | 1.0min timed | 215 |
| GOSI3B | LUMIK | VHF | left | 265 (85)° | > 9200ft | 1.0min timed | 215 |
| INDU3B | LUMIK | VHF | left | 265 (85)° | > 9200ft | 1.0min timed | 215 |
| SEVA3A | EREVA | VHF | left | 265 (85)° | > 7000ft | 1.0min timed | 215 |
| SEVA3B | LUMIK | VHF | left | 265 (85)° | > 9200ft | 1.0min timed | 215 |
| TIBL3B | LUMIK | VHF | left | 265 (85)° | > 9200ft | 1.0min timed | 215 |
| *) magnetic outbound (inbound) holding course | |||||||
