Country | Georgia |
State | Tbilisi |
Region | UG |
Airspace | Tbilisi Ctr |
Elevation | 1578ft (481m) |
Timezone | GMT +4 |
Coordinates | 41.67505, 44.95113 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | UGTB |
IATA code | TBS |
FAA code | n/a |
Shota Rustaveli Tbilisi Intl ATIS | 132.800 |
Shota Rustaveli Tbilisi Intl Ground Control | 131.700 |
Shota Rustaveli Tbilisi Intl Tower | 128.000 |
Shota Rustaveli Tbilisi Intl Tower | 119.000 |
Shota Rustaveli Tbilisi Intl ApproachR | 134.600 |
Shota Rustaveli Tbilisi Intl Departure | 128.000 |
ILS-cat-I | RW31L | 108.9 | 18.00mi |
ILS-cat-I | RW13R | 110.3 | 18.00mi |
3.5° GS | RW13R | 110.3 | 18.00mi |
3° GS | RW31L | 108.9 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
TBS | TBILISI VOR/DME | 0.3 | 223° | 113.70 |
DF | MUKHRANI NDB | 22.5 | 302° | 520 |
GUD | DME | 53 | 331° | 110.80 |
Transition altitude | 7600ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW13R | |||
KUFA1E | 62mi | 78° | |
DISK1E | 20mi | 122° | |
TAVR1E | 35mi | 223° | |
PALLE1 | 33mi | 262° | |
LAPT1E | 67mi | 321° | |
RW31L | |||
KUFA1D | 62mi | 78° | |
DISK1D | 20mi | 122° | |
TAVR1D | 35mi | 223° | |
ZAGOT1 | 37mi | 278° | |
LAPT1D | 67mi | 321° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW13R | |||
TISO1B | 24.6 | 9° | |
LAGA1B | 32.9 | 82° | |
GIMU1B | 41.9 | 113° | |
LAMU1B | 26.8 | 283° | |
RW31L | |||
TISO1A | 24.6 | 9° | |
LAGA1A | 32.9 | 82° | |
GIMU1A | 41.9 | 113° | |
LAMU1A | 26.8 | 283° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
GIMU1A | BAZIK | VHF | left | 220 (40)° | 5500ft - 9000ft | 1.0min timed | 220 |
GIMU1A | GIMUR | VHF | right | 276 (96)° | 13000ft - 20000ft | 1.0min timed | 280 |
GIMU1B | DANQI | VHF | right | 276 (96)° | 9000ft - 14000ft | 1.0min timed | 230 |
GIMU1B | GIMUR | VHF | right | 276 (96)° | 13000ft - 20000ft | 1.0min timed | 280 |
LAGA1A | BAZIK | VHF | left | 220 (40)° | 5500ft - 9000ft | 1.0min timed | 220 |
LAGA1A | LAGAS | VHF | right | 238 (58)° | 14000ft - 20000ft | 1.0min timed | 280 |
LAGA1B | DANQI | VHF | right | 276 (96)° | 9000ft - 14000ft | 1.0min timed | 230 |
LAGA1B | LAGAS | VHF | right | 238 (58)° | 14000ft - 20000ft | 1.0min timed | 280 |
LAMU1A | LAMUS | VHF | right | 78 (258)° | 9000ft - 20000ft | 1.0min timed | 280 |
LAMU1B | LAMUS | VHF | right | 78 (258)° | 9000ft - 20000ft | 1.0min timed | 280 |
TISO1A | BAZIK | VHF | left | 220 (40)° | 5500ft - 9000ft | 1.0min timed | 220 |
*) magnetic outbound (inbound) holding course |
