Airports for X-Plane

Norilsk

Airport details

CountryRussian Federation
StateKrasnoyarsk Krai
RegionUO
AirspaceKrasnoyarsk Ctr
Municipalityгородской округ Норильск
Elevation595ft (181m)
TimezoneGMT +7
Coordinates69.31111, 87.33195
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeUOOO
IATA codeNSK
FAA coden/a

Communication

Norilsk Norilsk ATIS126.800
Norilsk Norilsk Taxiing121.700
Norilsk Norilsk Start118.300
Norilsk Norilsk Podhod124.000

Approach frequencies

ILS-cat-IIRW19110.318.00mi
ILS-cat-IRW01109.518.00mi
3° GSRW01109.518.00mi
3° GSRW19110.318.00mi

Runway info

Runway 01 / 19
 length2810m (9219ft)
 bearing61° / 241°
 width45m (148ft)
 surfaceconcrete
 blast zone65m (213ft) / 54m (177ft)

Airport layout


Taxiway locations

 B  C  STAND10
Parking locations

 G1  G10  G11  G12  G13  G14  G15  G2
 G3  G4  G5  G6  G7  G8  G9

Nearby beacons

codeidentifierdistbearingfrequency
NORNORILSK VOR/DME0.7254°114.20
BALYKEL (NORILSK) NDB1.161°260
AALYKEL (NORILSK) NDB1.5241°260
BFALYKEL (NORILSK) NDB2.961°535
APALYKEL (NORILSK) NDB3241°535

Departure and arrival routes

Transition altitude4531ft
SID end pointsdistanceoutbound heading
RW01
 LORD1L, LORD1C, LORD1A22mi75°
 TEKO1L, TEKO1A, TEKO1C22mi88°
 ANES1L, ANES1C, ANES1A21mi92°
 OLUR1L, OLUR1C, OLUR1A26mi172°
 GIND1L, GIND1C, GIND1A27mi204°
 SUBO1A, SUBO1C, SUBO1L26mi250°
 ROLG1L, ROLG1A, ROLG1C23mi260°
 MEDU1C, MEDU1L, MEDU1A31mi306°
RW19
 LORD1M, LORD1D, LORD1B22mi75°
 TEKO1D, TEKO1B, TEKO1M22mi88°
 ANES1B, ANES1M, ANES1D21mi92°
 OLUR1B, OLUR1M, OLUR1D26mi172°
 GIND1M, GIND1B, GIND1D27mi204°
 SUBO1M, SUBO1D, SUBO1B26mi250°
 ROLG1M, ROLG1B, ROLG1D23mi260°
 MEDU1B, MEDU1M, MEDU1D31mi306°

STAR starting pointsdistanceinbound heading
RW01
 GIND1J, GIND1E, GIND1G, GIND1N26.524°
 SUBO1N, SUBO1G, SUBO1E, SUBO1J25.870°
 ROLG1E, ROLG1G, ROLG1J, ROLG1N23.280°
 MEDU1E, MEDU1G, MEDU1J, MEDU1N31.3126°
 LORD1E, LORD1G, LORD1J, LORD1N21.5255°
 TEKO1J, TEKO1E, TEKO1G, TEKO1N21.5268°
 ANES1J, ANES1G, ANES1E, ANES1N20.9272°
 OLUR1J, OLUR1N, OLUR1E, OLUR1G25.9352°
RW19
 GIND1P, GIND1K, GIND1H, GIND1F26.524°
 SUBO1H, SUBO1F, SUBO1P, SUBO1K25.870°
 ROLG1F, ROLG1P, ROLG1K, ROLG1H23.280°
 MEDU1P, MEDU1K, MEDU1H, MEDU1F31.3126°
 LORD1P, LORD1K, LORD1H, LORD1F21.5255°
 TEKO1P, TEKO1K, TEKO1H, TEKO1F21.5268°
 ANES1K, ANES1F, ANES1H20.9272°
 OLUR1K, OLUR1F, OLUR1H, OLUR1P25.9352°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW01OO008 (80°)OO008
OO011 (6mi, 103°) 2510ft
RW01OO009 (61°)OO009
OO011 (6mi, 61°) 2510ft
RW01OO010 (4°)OO010
OO011 (6mi, 283°) 2510ft
 RNAVOO011 2510ft
OO012 (5mi, 61°) 1860ft
UOOO (5mi, 61°) 592ft
(5349mi, 232°) 1000ft
OO013 (5350mi, 52°)
OO014 (10mi, 263°)
OO008 (5mi, 241°) 2510ft
RW19OO002 (180°)OO002
OO004 (6mi, 103°) 2570ft
RW19OO003 (261°)OO003
OO004 (6mi, 283°) 2570ft
 RNAVOO004 2570ft
OO005 (5mi, 241°) 1910ft
UOOO (5mi, 241°) 653ft
(5349mi, 232°) 1000ft
OO006 (5347mi, 52°)
OO007 (10mi, 343°)
OO002 (5mi, 61°) 2570ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ANES1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
ANES1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
ANES1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
ANES1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
ANES1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
ANES1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
BI1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
BI1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
BI2EOO008VHFright341 (161)°2680ft - 6000ft1.0min timed190
BI2FOO002VHFleft283 (103)°2080ft - 8000ft1.0min timed255
BI2GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
BI2HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
BI2NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
BI2PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
GIND1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
GIND1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
GIND1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
GIND1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
GIND1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
GIND1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
LORD1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
LORD1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
LORD1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
LORD1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
LORD1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
LORD1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
MEDU1EOO008VHFright341 (161)°2680ft - 6000ft1.0min timed190
MEDU1FOO002VHFleft283 (103)°2080ft - 8000ft1.0min timed255
MEDU1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
MEDU1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
MEDU1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
MEDU1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
MEDU1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
MEDU1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
OLUR1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
OLUR1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
OLUR1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
OLUR1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
OLUR1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
OLUR1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
ROLG1EOO008VHFright341 (161)°2680ft - 6000ft1.0min timed190
ROLG1FOO002VHFleft283 (103)°2080ft - 8000ft1.0min timed255
ROLG1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
ROLG1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
ROLG1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
ROLG1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
ROLG1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
ROLG1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
SUBO1FOO002VHFleft283 (103)°2080ft - 8000ft1.0min timed255
SUBO1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
SUBO1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
SUBO1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
SUBO1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
SUBO1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
SUBO1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
TEKO1GAPFIXleft193 (13)°2180ft - 9000ft1.0min timed255
TEKO1HBFFIXright13 (193)°2240ft - 9000ft1.0min timed220
TEKO1JNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
TEKO1KNORNDBleft178 (358)°2350ft - 9000ft1.0min timed280
TEKO1NAFIXright59 (239)°5000ft - 19000ft1.0min timedICAO rules
TEKO1PBFIXleft289 (109)°> 4000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
