Airports for X-Plane

Elista

Airport details

CountryRussian Federation
StateRepublic of Kalmykia
RegionUR
AirspaceRostov-na-donu Ctr
Municipalityгородской округ Элиста
Elevation500ft (152m)
TimezoneGMT +3
Coordinates46.37472, 44.32389
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeURWI
IATA codeESL
FAA coden/a

Communication

Elista ATIS126.400
Elista Tower124.200

Approach frequencies

ILS-cat-IIRW09108.518.00mi
2.7° GSRW09108.518.00mi
Nearby Points of Interest:
Krasnaya shkola

Runway info

Runway 09L / 27R
 length2297m (7536ft)
 bearing96° / 276°
 width80m (262ft)
 surfacegrass
Runway 09 / 27
 length3190m (10466ft)
 bearing95° / 275°
 width45m (148ft)
 surfaceasphalt
 blast zone50m (164ft) / 45m (148ft)

Airport layout - parking location 18


Taxiway locations

 A
Parking locations

 1  17  18  19  20  21  22

Nearby beacons

codeidentifierdistbearingfrequency
ELIELISTA VOR/DME1.295°117.65
SAELISTA NDB2.2275°311

Departure and arrival routes

Transition altitude2480ft
Transition level5000ft
SID end pointsdistanceoutbound heading
RW09
 BAGO1J, BAGO1F, BAGO1B34mi3°
 BURU1F, BURU1J, BURU1B30mi27°
 LUTI1F, LUTI1B, LUTI1J36mi116°
 AKTU1J, AKTU1F, AKTU1B49mi143°
 SORE1J, SORE1B, SORE1F31mi215°
 KISE1F, KISE1B, KISE1J35mi240°
 GUBT1J, GUBT1F, GUBT1B40mi257°
 BAKA1B, BAKA1J, BAKA1F45mi309°
 BEFO1B, BEFO1J, BEFO1F39mi333°
RW27
 BAGO1C, BAGO1G, BAGO1H34mi3°
 BURU1H, BURU1G, BURU1C30mi27°
 LUTI1C, LUTI1G, LUTI1H36mi116°
 AKTU1H, AKTU1C, AKTU1G49mi143°
 SORE1C, SORE1H, SORE1G31mi215°
 KISE1G, KISE1C, KISE1H35mi240°
 GUBT1H, GUBT1C, GUBT1G40mi257°
 BAKA1C, BAKA1G, BAKA1H45mi309°
 BEFO1H, BEFO1G, BEFO1C39mi333°

STAR starting pointsdistanceinbound heading
RW09
 SORE1K, SORE1D, SORE1A31.135°
 KISE1A, KISE1D, KISE1K35.160°
 GUBT1D, GUBT1A, GUBT1K39.977°
 TIKN1A, TIKN1K, TIKN1D44.396°
 BEFO1D, BEFO1A, BEFO1K39.3153°
 BAGO1K, BAGO1D, BAGO1A34.0183°
 BURU1K, BURU1A, BURU1D29.8207°
 SUFO1A, SUFO1D, SUFO1K48.4268°
 LUTI1K, LUTI1D, LUTI1A36.1296°
 AKTU1D, AKTU1A, AKTU1K49.0323°
RW27
 SORE1A, SORE1D, SORE1E31.135°
 KISE1E, KISE1D, KISE1A35.160°
 GUBT1A, GUBT1E, GUBT1D39.977°
 TIKN1A, TIKN1E, TIKN1D44.396°
 BEFO1A, BEFO1E, BEFO1D39.3153°
 BAGO1A, BAGO1D, BAGO1E34.0183°
 BURU1E, BURU1A, BURU1D29.8207°
 SUFO1D, SUFO1E, SUFO1A48.4268°
 LUTI1A, LUTI1E, LUTI1D36.1296°
 AKTU1E, AKTU1D, AKTU1A49.0323°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09WI003 (95°)WI003 3000ft
WI002 (6mi, 95°) 2100ft
RW09WI004 (74°)WI004 3000ft
WI002 (6mi, 11°) 2100ft
RW09WI005 (118°)WI005 3000ft
WI002 (6mi, 191°) 2100ft
 RNAVWI002 2100ft
WI001 (5mi, 95°) 1800ft
URWI (5mi, 95°) 535ft
(3629mi, 224°) 1500ft
WI006 (3630mi, 44°)
WI005 (5mi, 275°) 3000ft
RW27WI203 (275°)WI203 3000ft
WI202 (6mi, 275°) 2100ft
RW27WI204 (298°)WI204 3000ft
WI202 (6mi, 11°) 2100ft
RW27WI205 (254°)WI205 3000ft
WI202 (6mi, 191°) 2100ft
 RNAVWI202 2100ft
WI201 (5mi, 275°) 1800ft
URWI (5mi, 275°) 533ft
(3629mi, 224°) 1500ft
WI206 (3637mi, 44°)
WI205 (5mi, 95°) 3000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
AKTU1AELINDBright88 (268)°> 2200ft1.0min timed230
AKTU1DSAFIXleft270 (90)°> 2200ft1.0min timed230
BAGO1AELINDBright88 (268)°> 2200ft1.0min timed230
BAGO1DSAFIXleft270 (90)°> 2200ft1.0min timed230
BAGO1EWI205VHFleft360 (180)°> 1600ft1.0min timed230
BAGO1KWI005VHFright360 (180)°> 1900ft1.0min timed230
BEFO1AELINDBright88 (268)°> 2200ft1.0min timed230
BEFO1DSAFIXleft270 (90)°> 2200ft1.0min timed230
BEFO1EWI205VHFleft360 (180)°> 1600ft1.0min timed230
BEFO1KWI005VHFright360 (180)°> 1900ft1.0min timed230
BURU1AELINDBright88 (268)°> 2200ft1.0min timed230
BURU1DSAFIXleft270 (90)°> 2200ft1.0min timed230
BURU1EWI205VHFleft360 (180)°> 1600ft1.0min timed230
BURU1KWI005VHFright360 (180)°> 1900ft1.0min timed230
GUBT1AELINDBright88 (268)°> 2200ft1.0min timed230
GUBT1DSAFIXleft270 (90)°> 2200ft1.0min timed230
KISE1AELINDBright88 (268)°> 2200ft1.0min timed230
KISE1DSAFIXleft270 (90)°> 2200ft1.0min timed230
LUTI1AELINDBright88 (268)°> 2200ft1.0min timed230
LUTI1DSAFIXleft270 (90)°> 2200ft1.0min timed230
SORE1AELINDBright88 (268)°> 2200ft1.0min timed230
SORE1DSAFIXleft270 (90)°> 2200ft1.0min timed230
SUFO1AELINDBright88 (268)°> 2200ft1.0min timed230
SUFO1DSAFIXleft270 (90)°> 2200ft1.0min timed230
SUFO1KWI005VHFright360 (180)°> 1900ft1.0min timed230
TIKN1AELINDBright88 (268)°> 2200ft1.0min timed230
TIKN1DSAFIXleft270 (90)°> 2200ft1.0min timed230
*) magnetic outbound (inbound) holding course
