Airports for X-Plane

Orsk

Airport details

CountryRussian Federation
StateOrenburg Oblast
RegionUW
AirspaceSamara Ctr
MunicipalityOrsk
Elevation909ft (277m)
TimezoneGMT +5
Coordinates51.07594, 58.59174
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeUWOR
IATA codeOSW
FAA coden/a

Communication

Orsk Orsk-ATIS125.900
Orsk Orsk-Tower122.700
Orsk Samara Control S12128.500

Approach frequencies

ILS-cat-IRW25108.118.00mi
ILS-cat-IRW07109.5518.00mi
3° GSRW07109.5518.00mi
2.6° GSRW25108.118.00mi
Nearby Points of Interest:

Runway info

Runway 01 / 19
 length623m (2044ft)
 bearing27° / 207°
 width49m (160ft)
 surfacegrass
Runway 16 / 34
 length572m (1877ft)
 bearing166° / 346°
 width52m (170ft)
 surfacegrass
Runway 07R / 25L
 length1767m (5797ft)
 bearing81° / 261°
 width80m (262ft)
 surfacegrass
Runway 07 / 25
 length2897m (9505ft)
 bearing82° / 262°
 width42m (138ft)
 surfaceasphalt

Airport layout - parking location 8


Taxiway locations

 A
Parking locations

 1  10  1A  2  3  4  4A  5
 6  8  9  GA

Nearby beacons

codeidentifierdistbearingfrequency
NWORSK NDB0.3131°385
SORSK NDB1.3255°780
OORSK NDB1.487°780
ORORSK NDB2.985°385
SFORSK NDB2.9259°385

Departure and arrival routes

Transition altitude2877ft
SID end pointsdistanceoutbound heading
RW07
 OKRO5L, OKRO5C, OKRO5B, OKRO5A29mi72°
 URUS5C, URUS5B, URUS5A27mi136°
 ALGA5C, ALGA5A, ALGA5B, ALGA5N, ALGA5M24mi232°
 LALE5A, LALE5B, LALE5C28mi286°
 GITA5C, GITA5A, GITA5B, GITA5L28mi331°
RW25
 OKRO5R, OKRO5J, OKRO5D29mi72°
 URUS5J, URUS5D, URUS5R27mi136°
 ALGA5R, ALGA5J, ALGA5D24mi232°
 LALE5J, LALE5R, LALE5D28mi286°
 GITA5R, GITA5J, GITA5D28mi331°

STAR starting pointsdistanceinbound heading
RW07
 ALGA5E, ALGA5G, ALGA5P23.552°
 LALE5P, LALE5G, LALE5E28.3106°
 GITA5P, GITA5G, GITA5E28.2151°
 OKRO5P, OKRO5G, OKRO5E28.6252°
 URUS5E, URUS5G, URUS5P26.7316°
RW25
 ALGA5Q, ALGA5H, ALGA5F23.552°
 LALE5Q, LALE5K, LALE5H, LALE5F28.3106°
 GITA5Q, GITA5K, GITA5H, GITA5F28.2151°
 OKRO5F, OKRO5H, OKRO5Q28.6252°
 URUS5Q, URUS5H, URUS5F26.7316°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW07OR006 (100°)OR006 2700ft
OR009 (6mi, 159°) 2500ft
RW07OR008 (59°)OR008 2700ft
OR009 (6mi, 339°) 2500ft
 RNAVOR009 2500ft
OR010 (5mi, 81°) 2500ft
UWOR (6mi, 80°) 963ft
(4257mi, 229°) 1400ft
OR007 (4253mi, 49°)
OR006 (5mi, 261°) 2700ft
RW25OR001 (242°)OR001 2700ft
OR004 (6mi, 160°) 2500ft
RW25OR002 (262°)OR002 2700ft
OR004 (6mi, 262°) 2500ft
RW25OR003 (280°)OR003 2700ft
OR004 (6mi, 340°) 2500ft
 RNAVOR004 2500ft
OR005 (5mi, 262°) 2500ft
UWOR (6mi, 263°) 922ft
(4257mi, 229°) 1500ft
OR011 (4262mi, 49°)
OR003 (5mi, 82°) 2700ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ALGA5ESFFIXleft246 (66)°> 2500ft1.0min timed190
ALGA5FORFIXleft66 (246)°> 2300ft1.0min timedICAO rules
ALGA5HOR003VHFright156 (336)°3000ft - 13000ft1.0min timed190
ALGA5PSFIXleft74 (254)°1.0min timedICAO rules
ALGA5QOFIXright179 (359)°2300ft - 17000ft1.0min timedICAO rules
GITA5ESFFIXleft246 (66)°> 2500ft1.0min timed190
GITA5FORFIXleft66 (246)°> 2300ft1.0min timedICAO rules
GITA5GOR006VHFright356 (176)°3000ft - 13000ft1.0min timed210
GITA5KOR001VHFleft320 (140)°3000ft - 13000ft1.0min timed190
GITA5PSFIXleft74 (254)°1.0min timedICAO rules
GITA5QOFIXright179 (359)°2300ft - 17000ft1.0min timedICAO rules
LALE5ESFFIXleft246 (66)°> 2500ft1.0min timed190
LALE5FORFIXleft66 (246)°> 2300ft1.0min timedICAO rules
LALE5GOR006VHFright356 (176)°3000ft - 13000ft1.0min timed210
LALE5HOR003VHFright156 (336)°3000ft - 13000ft1.0min timed190
LALE5KOR001VHFleft320 (140)°3000ft - 13000ft1.0min timed190
LALE5PSFIXleft74 (254)°1.0min timedICAO rules
LALE5QOFIXright179 (359)°2300ft - 17000ft1.0min timedICAO rules
OKRO5ESFFIXleft246 (66)°> 2500ft1.0min timed190
OKRO5FORFIXleft66 (246)°> 2300ft1.0min timedICAO rules
OKRO5GOR006VHFright356 (176)°3000ft - 13000ft1.0min timed210
OKRO5PSFIXleft74 (254)°1.0min timedICAO rules
OKRO5QOFIXright179 (359)°2300ft - 17000ft1.0min timedICAO rules
URUS5ESFFIXleft246 (66)°> 2500ft1.0min timed190
URUS5FORFIXleft66 (246)°> 2300ft1.0min timedICAO rules
URUS5HOR003VHFright156 (336)°3000ft - 13000ft1.0min timed190
URUS5PSFIXleft74 (254)°1.0min timedICAO rules
URUS5QOFIXright179 (359)°2300ft - 17000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
