Airports for X-Plane

Bangkok - Bangkok Suvarnabhumi Intl

Airport details

CountryThailand
StateSamut Prakan Province
RegionVT
AirspaceBangkok Ctr
MunicipalityNong Prue Subdistrict
Elevation0ft (0m)
TimezoneGMT +7
Coordinates13.68583, 100.74889
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeVTBS
IATA codeBKK
FAA coden/a

Communication

Bangkok Suvarnabhumi Intl SUVARNABHUMI AIRPORT127.800
Bangkok Suvarnabhumi Intl Ground Control121.950
Bangkok Suvarnabhumi Intl Ground Control121.650
Bangkok Suvarnabhumi Intl Ground Control121.750
Bangkok Suvarnabhumi Intl Tower118.200
Bangkok Suvarnabhumi Intl Tower119.000
Bangkok Suvarnabhumi Intl BANGKOK Approach CTL122.350
Bangkok Suvarnabhumi Intl BANGKOK Approach CTL124.350
Bangkok Suvarnabhumi Intl SUVARNABHUMI ARR124.700

Approach frequencies

ILS-cat-IIRW19L110.518.00mi
ILS-cat-IIRW01R110.118.00mi
ILS-cat-IIRW19R109.518.00mi
ILS-cat-IIRW01L109.118.00mi
3° GSRW19L110.518.00mi
3° GSRW01R110.118.00mi
3° GSRW19R109.518.00mi
3° GSRW01L109.118.00mi
Nearby Points of Interest:
Wat Sangkharacha
-
Wat Bang Na Nai
-
Wat Thep Lila
-
Wat Bueng Thonglang
-
Wat Klang Worawihan
-
Wat Uthaitharam
-
Wat Khlong Toei Nai
-
Wat Chong Nonsi
-
Wat Chong Lom
-
Embassy of the United Kingdom, Bangkok
-
Wat Thong Bon
-
Wat Phai Ngoen Chotanaram
-
Wat Bang Phueng
-
Chaliam La 56 bridge
-
Neilson Hays Library
-
Wat Sai
-
Wat Borom Sathon
-
Wat Son
-
Wat Suan Phlu
-
Wat Bang Khlo Nok
-
Phitthaya Sathian Bridge
-
Customs House, Bangkok
-
Chit Lada Station
-
Saphan Saowani
-
Wat Chom Sudaram

Runway info

Runway 01R / 19L
 length4018m (13182ft)
 bearing15° / 195°
 width61m (200ft)
 surfaceasphalt
 blast zone122m (400ft) / 122m (400ft)
Runway 01L / 19R
 length3717m (12195ft)
 bearing15° / 195°
 width61m (200ft)
 surfaceasphalt
 blast zone122m (400ft) / 122m (400ft)

Airport layout


Parking locations

 102  103  104  105  106  107  108  109
 110  111  112  113  114  115  116  117
 118  119  120  121  122  123  124  125
 126  127  128  129  130  131  132  133
 134  201  202  203  301  302  303  304
 305  306  307  308  401  402  403  501
 502  503  504  505  506  507  508  509
 510  511  512  513  514  515  516  517
 518  519  520  521  522  523  524  525
 A1  A2  A3  A4  A5  A6  B1  B2
 B4  B5  B6  C1  C10  C2  C3  C4
 C5  C6  C7  C8  C9  D1  D2  D3
 D4  D5  D6  D7  D8  E1  E10  E2
 E3  E4  E5  E6  E7  E8  E9  F1
 F2  F3  F4  F5  F6  G1  G2  G3
 G4  G5

Nearby beacons

codeidentifierdistbearingfrequency
SVBSUVARNABHUMI (BANGKOK) VOR/DME1.9213°111.40
BKKBANGKOK VOR/DME15.3324°117.70
PBPRACHIN BURI NDB44.655°201
KPSKAMPHAENG SAEN (NAKHON PATHOM) NDB54.5301°251
UTU-TAPHAO INTL (RAYONG) NDB60.9166°234

Departure and arrival routes

Transition altitude11000ft
Transition level13000ft
SID end pointsdistanceoutbound heading
RW01L
 ALBO3H66mi15°
 ROBK3H49mi54°
 UPKU3H47mi62°
 DOSB3H64mi80°
 GORS3H37mi106°
 RYN3H77mi134°
 KIGO3H35mi170°
 REGO3H102mi186°
 KASN3H37mi187°
 UKER3H108mi204°
 HHN3H79mi217°
 SABI3H53mi219°
 BONV3H57mi273°
 PAST3H75mi284°
 TARE3H84mi302°
 NUNL3H106mi311°
 TANG3H66mi333°
 SEMB3H78mi338°
 NOBE3H96mi357°
RW01R
 ALBO3K66mi15°
 ROBK3K49mi54°
 UPKU3K47mi62°
 DOSB3K64mi80°
 GORS3K37mi106°
 RYN3K77mi134°
 KIGO3K35mi170°
 REGO3K102mi186°
 KASN3K37mi187°
 UKER3K108mi204°
 HHN3K79mi217°
 SABI3K53mi219°
 BONV3K57mi273°
 PAST3K75mi284°
 TARE3K84mi302°
 NUNL3K106mi311°
 TANG3K66mi333°
 SEMB3K78mi338°
 NOBE3K96mi357°
RW19L
 ALBO3J66mi15°
 ROBK3J49mi54°
 UPKU3J47mi62°
 DOSB3J64mi80°
 GORS3J37mi106°
 RYN3J77mi134°
 KIGO3J35mi170°
 REGO3J102mi186°
 KASN3J37mi187°
 UKER3J108mi204°
 HHN3J79mi217°
 SABI3J53mi219°
 BONV3J57mi273°
 PAST3J75mi284°
 TARE3J84mi302°
 NUNL3J106mi311°
 TANG3J66mi333°
 SEMB3J78mi338°
 NOBE3J96mi357°
RW19R
 ALBO3G66mi15°
 ROBK3G49mi54°
 UPKU3G47mi62°
 DOSB3G64mi80°
 GORS3G37mi106°
 RYN3G77mi134°
 KIGO3G35mi170°
 REGO3G102mi186°
 KASN3G37mi187°
 UKER3G108mi204°
 HHN3G79mi217°
 SABI3G53mi219°
 BONV3G57mi273°
 PAST3G75mi284°
 TARE3G84mi302°
 NUNL3G106mi311°
 TANG3G66mi333°
 SEMB3G78mi338°
 NOBE3G96mi357°

STAR starting pointsdistanceinbound heading
RW01 (ALL)
 LEBI3D39.325°
 WILA3D58.9136°
 NORT3D62.3174°
 EAST3D48.8221°
 DOLN3D34.4312°
RW19 (ALL)
 LEBI3C39.325°
 WILA3C58.9136°
 NORT3C62.3174°
 EAST3C48.8221°
 DOLN3C34.4312°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW01LLACOS (17°)LACOS 3000ft
LONNY (5mi, 15°) 2500ft
 RNAVLONNY 2500ft
BS488 (5mi, 15°) 2000ft
VTBS (7mi, 20°) 55ft
LAINO (8mi, 10°) 3000ft
LAINO (turn) 3000ft
RW01RRISSE (13°)RISSE 3000ft
RAYPA (5mi, 15°) 2500ft
 RNAVRAYPA 2500ft
BS499 (4mi, 15°) 2000ft
BS497 (2mi, 15°) 1300ft
VTBS (6mi, 8°) 55ft
(6032mi, 262°) 1500ft
RENEX (6038mi, 82°) 3000ft
RENEX (turn) 3000ft
RW19LLEMOS (196°)LEMOS 5000ft
LINSY (5mi, 195°) 3500ft
 RNAVLINSY 3500ft
LANCO (5mi, 195°) 2500ft
BS599 (4mi, 195°) 2000ft
VTBS (7mi, 200°) 55ft
(6032mi, 262°) 1500ft
LASON (6037mi, 82°) 3000ft
LASON (turn) 3000ft
RW19RREWCO (193°)REWCO 5000ft
RYAUN (5mi, 195°) 3500ft
 RNAVRYAUN 3500ft
ROMME (5mi, 195°) 2500ft
BS588 (4mi, 195°) 2000ft
VTBS (7mi, 190°) 55ft
(6032mi, 262°) 1500ft
RIPSO (6028mi, 82°) 3000ft
RIPSO (turn) 3000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
DOLN3CDOLNIVHFright115 (295)°> 14000ft1.0min timedICAO rules
DOLN3DDOLNIVHFright115 (295)°> 14000ft1.0min timedICAO rules
EAST3CEASTEVHFleft68 (248)°> 14000ft1.0min timedICAO rules
EAST3CTERIBVHFleft16 (196)°> 7000ft1.0min timedICAO rules
EAST3DEASTEVHFleft68 (248)°> 14000ft1.0min timedICAO rules
LEBI3CLEBIMVHFleft180 (0)°> 14000ft1.0min timedICAO rules
LEBI3DLEBIMVHFleft180 (0)°> 14000ft1.0min timedICAO rules
NORT3CNORTAVHFright360 (180)°> 14000ft1.0min timedICAO rules
NORT3DNORTAVHFright360 (180)°> 14000ft1.0min timedICAO rules
WILA3CWILLAVHFright285 (105)°> 14000ft1.0min timedICAO rules
WILA3DWILLAVHFright285 (105)°> 14000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
