Country | Thailand |
State | Ranong Province |
Region | VT |
Airspace | Bangkok Ctr |
Municipality | Ratchakrut |
Elevation | 57ft (17m) |
Timezone | GMT +7 |
Coordinates | 9.77762, 98.58548 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | VTSR |
IATA code | UNN |
FAA code | n/a |
Ranong Tower | 122.250 |
Ranong Approach | 125.100 |
ILS-cat-I | RW02 | 110.5 | 18.00mi |
3° GS | RW02 | 110.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
RAN | RANONG VOR/DME | 0.1 | 304° | 113.40 |
RN | RANONG NDB | 0.4 | 44° | 375 |
KT | KAWTHOUNG NDB | 16.5 | 351° | 290 |
SRT | SURAT THANI TACAN | 50.6 | 140° | 113.20 |
STN | SURAT THANI VOR/DME | 50.7 | 140° | 110.60 |
CPN | CHUMPHON VOR/DME | 72.5 | 40° | 110 |
CP | CHUMPHON NDB | 72.9 | 40° | 279 |
Transition altitude | 11000ft |
Transition level | 13000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW02 | |||
PAYU1A | 73mi | 40° | |
KAOY1A | 101mi | 190° | |
RW20 | |||
CPN1A, PAYU1B | 73mi | 40° | |
KAOY1B, PUT1A | 101mi | 190° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW02 | FASAI (75°) | FASAI 5000ft GAPER (6mi, 136°) 5000ft RUNTA (8mi, 114°) 3400ft |
RW02 | GAYOU (220°) | GAYOU 7000ft MINTA (9mi, 229°) 6000ft KOKAM (24mi, 229°) 6000ft GAPER (5mi, 204°) 5000ft RUNTA (8mi, 114°) 3400ft |
RW02 | KAOYA (10°) | KAOYA 7000ft GOWHA (9mi, 340°) 5400ft RUNTA (5mi, 24°) 3400ft |
RW02 | NEETA (320°) | NEETA 7000ft RAKSA (13mi, 285°) 5600ft RUNTA (10mi, 294°) 3400ft |
RNAV | RUNTA 3400ft UNNSF (6mi, 24°) 2000ft UNNHM (4mi, 24°) 851ft UNDAR (7mi, 11°) 1500ft MANAM (7mi, 281°) 4000ft FASAI (14mi, 225°) 5000ft FASAI (turn) 5000ft |
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
